2014 INFINITI QX70 lights

5
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock or
unlock your vehicle, open your liftgate and start the engine.
It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent Key is within

31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle request

switch
01 once or press the
button
02 on the key fob.
To unlock the vehicle, perform one of the following procedures:

•
Push either door handle request switch 01 once; the

corresponding door will unlock. Push the door handle
request switch
01 again within 1 minute; all other

doors will unlock, or
•
Press the button
03 on the key fob to unlock the driver’s

side door. Press the
button again; all other doors will

unlock.
To open the liftgate, press the button 04 for more than 1 second.

The Intelligent Key can also be used to activate the panic alarm by pres\
sing and holding the

button 05 for more than 1 second. Once activated, the panic alarm and headlights w\
ill stay on
for a period of time.
INFINITI INTELLIGENT KEY BATTERY DISCHARGE
If the battery in the Intelligent Key is almost discharged,

the guide light
06 of the Intelligent Key port blinks and

the Intelligent Key insertion indicator 07 is displayed in

the vehicle information display.
To start the engine under these circumstances, insert

the Intelligent Key into the key port with the keyring
side facing backward until it latches into place. Then
push the ignition switch to start the engine.
To remove the Intelligent Key from the port, push the

ignition switch to turn the engine off and then pull the
Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent

Key battery. If you see the Intelligent Key warning light

08 , replace the battery in the Intelligent Key.

Do not insert the mechanical key or other objects into
the key port because it will damage the key port.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)”, “Starting and driving (section 5)” and the “Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
first drive features
01
02
03
04
05
06
F E
07
08
1354681_14a_Infiniti_QX70_QRG_052813.indd 55/28/13 11:59 AM

8
first drive features
Starting/Stopping the Engine
It is important to make sure the INFINITI Intelligent Key



is with you (that is, in your pocket or purse).
Depress the brake pedal.

• If the brake pedal is not depressed, pushing the




ignition switch once enters the
ACC mode.
• If
the ignition switch is pushed a second time, the




vehicle will enter the
ON mode.
Move the shift lever to
P (PARK).
Push the ignition switch to start the engine.
TURNING THE ENGINE OFF
Move the shift lever to the
P (PARK) position and apply the parking brake.
Press the ignition switch
START/STOP button to turn the engine off.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
Headlight Control Switch
Turn the headlight control switch to the position

01 to turn on the front parking, side marker, tail,

license plate and instrument panel lights. Turn the



switch to the position
02 to turn on the headlights.

AUTOLIGHT SYSTEM
The autolight system will automatically turn the headlights on when it i\
s dark and off when it is




light. The system will keep the headlights on for a period of time after\
you turn the ignition off




and all doors are closed.
To activate the autolight system, turn the headlight control switch to t\
he
AUTO position
03
t
hen push the ignition switch to ON. To deactivate the autolight system, turn the headlight



control switch to the

OFF,
01 or
position
02.
HIGH BEAM SELECT
Push the headlight control switch forward
04 to
select the high beam function. The blue indicator
light illuminates in the instrument panel. Pull



the headlight switch back to the original position to




select the low beam. The blue indicator light goes off.
Pull and release the headlight control switch
05 to
flash the headlight high beams on and off.
03
04
05
01
02
1354681_14a_Infiniti_QX70_QRG_052813.indd 85/28/13 12:00 PM

9
FOG LIGHT SWITCH

The headlights must be on and the low beams

selected for the fog lights to operate.
Turn the switch (inside collar) to the position
06
to turn the fog lights on.
Turn the switch (inside collar)
to the
OFF position to



turn the fog lights off.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
Windshield Wiper and Washer Switch
Move the lever to the following positions to operate

the windshield wipers:
01 Mist (MIST) - One sweep operation of the
front wipers.
02 Move the lever down to the (INT) position and
then rotate the control ring
03 away from you to

decrease the wiper delay.
04 Low (LO) - Front wipers operate at a continuous
low-speed.
05 High ( h I) - Front wipers operate at a continuous
high-speed.
06 Front washer - Pull the lever toward you to

activate the front washer. The front wipers will
operate several times.

REAR WINDSHIELD WIPER AND WASHER
07 Intermittent (INT) - Rear wiper operates
intermittently.
08 Low (ON) - Rear wiper operates at a continuous
low-speed.
09 Rear washer - Push the lever forward to

activate the rear washer. The rear wiper will
operate several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
06
INT
ON
MIST OFF
INT
LO
h

I01
02
04
05
03
06
09
07
08
1354681_14a_Infiniti_QX70_QRG_052813.indd 95/28/13 12:00 PM

14
Intelligent Cruise Control (ICC) System (if so equipped)
vEHICLE-TO-vEHICLE DISTANCE CONTROL MODE
To set v ehicle-To- v ehicle Distance Control mode,



press the
CRUISE ON/OFF button
01 for less

than 1.5 seconds. The
CRUISE indicator light
02
will illuminate.
Accelerate to the desired speed.
Push down on the COAST/SET switch
03 and release
it. Cruise control will be set to the desired speed.
Press the distance button 04 repeatedly to change
the set distance between long, middle, and short.
When a vehicle is not detected ahead of you in the



lane, the set distance and set vehicle speed indicator




lights will illuminate 05 in set mode.
When a vehicle is detected ahead of you in the lane,




the vehicle ahead detection, set distance,
and set



vehicle speed indicator lights will illuminate 06 in set mode.
To reset at a faster cruising speed, push and hold the
ACCEL/RES
switch
07. When the vehicle attains the desired speed, release



the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch
03. Release



the switch when the vehicle slows to the desired speed.
To cancel the preset speed, push the CANCEL switch
08 or tap the brake pedal. The set
vehicle speed indicator 05 will go out.
To turn off cruise control, press the
CRUISE ON/OFF button
01. The CRUISE indicator light

02 , in the instrument panel, will turn off.
To set conventional (fixed speed) cruise control mode:
While cruise control is off, press the CRUISE ON/OFF
button
01 and hold it down for more
than 1.5 seconds. The
CRUISE indicator light will illuminate.
Accelerate to the desired speed.
Push down on the COAST/SET switch and release it. The SET indicator light will illuminate.



Cruise control should be set to the desired speed.
To switch between the two cruise control modes:
When one of the two cruise modes is in use, you must turn the system off\
, and then turn it on



again to select the other cruise control mode.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
first drive features
0807
0304
01
0205
06
1354681_14a_Infiniti_QX70_QRG_052813.indd 145/28/13 12:00 PM

23
HOMELINK®
HomeLink® Universal Transceiver
The HomeLink® system can learn and consolidate the functions of up to three different\

hand-held transmitters, operating items such as garage doors, property g\
ates, outdoor
and indoor lights or alarm systems.
To program the Homelink® Universal Transceiver:
•
Position


the

handheld

transceiver 1-3 in (26-76 mm) away from the Homelink
®
surface, keeping the Homelink® indicator light in view.
•
Press


and

hold

the

desired

Homelink
® button and the handheld transmitter button
simultaneously until the Homelink® indicator light flashes slowly and then rapidly.
•
Both


buttons

may

be

released

when the indicator light flashes rapidly.
To verify the programing is complete, press and hold the Homelink® and observe the
indicator light:
•
A


solid

continuous

light

indicates

the

programing

is

complete

and the Homelink
®
button will activate your device.
•
A


blinking

light

that

turns

to

a

solid

continuous

light

after

2

seconds

indicates

additional steps are required to complete the programing.
An additional person may make the remaining steps easier. To complete th\
e
programing process:
•
At

the receiver of the device that you are programing to the Homelink
®, press and
release the “learn” or “smart” button (the name may vary by\
manufacturer but it is
usually located near where the hanging antenna wire is attached to the u\
nit). You
have approximately 30 seconds to initiate the following step.
•
Press


and

hold

the

programmed

Homelink
® button for 2 seconds and release.
Repeat the previous 2 steps up to 3 times to complete the programming pr\
ocess.
Homelink® should now activate your device.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual, the HomeLink® website
at www.homelink.com or call 1-800-355-3515.
