2014 INFINITI QX70 Quick Reference Guide

2014 Infiniti QX70Quick Reference Guide
1354681_14a_Infiniti_QX70_QRG_052813.indd 35/28/13 11:59 AM

*See your Owner’s Manual for information.
01 INSTRUMENT BRIGHTNESS CONTROL*
02 TRIP COMPUTER SWITCHES
03 LOW TIRE PRESSURE WARNING LIGHT
04 PADDLE SHIFTERS*
05 HEADLIGHT AND TURN SIGNAL CONTROL
06 WINDSHIELD WIPER AND WASHER
SWITCH
07 TRIP A/B RESET SWITCH*
08 STEERING WHEEL SWITCHES FOR AUDIO* / BLUETOOTH® / NAvIGATION
09 INTELLIGENT CRUISE CONTROL
10 OUTSIDE MIRROR CONTROL SWITCH
11 INTELLIGENT BRAKE ASSIST (IBA) OFF SWITCH*
01
0404
0605
07
22
23161718
19
20
111213
14
02
03
21
12 POWER LIFTGATE SWITCH
13 POWER LIFTGATE MAIN SWITCH
14 DYNAMIC DRIv ER ASSISTANCE SWITCH*
15 TILT / TELESCOPIC STEERING WHEEL SWITCH*
16 WARNING SYSTEMS SWITCH*
17 vEHICLE DYNAMIC CONTROL (vDC) OFF SWITCH*
18 INTELLIGENT KEY PORT*
19 HOOD RELEASE*
20 CONTROL PANEL DISPLAY SCREEN*
21 AUDIO SYSTEM
22 AUTOMATIC CLIMATE CONTROLS
23 FRONT PASSENGER AIR BAG STATUS LIGHT*
10
09Behind
steering wheel
Behind
steering wheel
On steering column Behind
steering wheel
15
08
1354681_14a_Infiniti_QX70_QRG_052813.indd 45/28/13 11:59 AM

• A cellular telephone should not be used for any purpose while
driving so full attention may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
•

Children 12 and under should always ride in the rear seat

properly secured in child restraints or seat belts according to their
age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and
supplemental restraint system (section 1)”, “Monitor, climate,
audio, phone and voice recognition systems (section 4)” and the
“Starting and driving (section 5)” of your Owner’s Manual.
table of contents
new system features Around v iew® Monitor (AvM) with Moving Object Detection (MOD) (if so equipped)
................................................2 Garage Mode System............................................3



essential information Tire Pressure Monitoring System (TPMS) ............................4 Loose Fuel Cap.................................................4

Front Armrest/Center Console Storage Box

..........................
4


first drive features INFINITI Intelligent Key System...................................5 Power Liftgate..................................................6

Power Seat Adjustments

.........................................
6

Automatic Drive Positioner (if so equipped)

.........................
7

Outside Mirror Control Switch.....................................7


Starting/Stopping the Engine

.....................................
8

Headlight Control Switch.........................................8


Windshield Wiper and Washer Switch

..............................
9

Automatic Climate Controls......................................10


FM/AM/SiriusXM Satellite Radio with CD/D

v D Player
(with Navigation System – if so equipped)

.........................
12



USB/iPod
® Interface ...........................................13 Conventional (Fixed Speed) Cruise Control .........................13

Intelligent Cruise Control (ICC) System (if so equipped) ..............14


Power Outlets.................................................15


Fuel-Filler Door ................................................15



system guide Trip Computer ................................................16
Bluetooth® Hands-free Phone System .............................16
System Operating Tips .......................................16


Bluetooth
® System with Navigation (if so equipped)...............17


Bluetooth® System without Navigation (if so equipped) ............19 Navigation System (if so equipped)
...............................21 D

v
D Player (if so equipped)
......................................22



HomeLink
® Universal Transceiver.................................23
To view detailed
instructional videos, go to
www.infinitiownersinfo.mobi/2014/qx70 or snap this barcode with an
appropriate barcode reader.
Additional information about your vehicle is also available in

your Owner’s Manual, Navigation System Owner’s Manual and
at www.InfinitiUSA.com.
1354681_14a_Infiniti_QX70_QRG_052813.indd 55/28/13 11:59 AM

2
Around View® Monitor (AVM) with Moving
Object Detection (MOD) (if so equipped)
With the ignition switch in the ON position, the Around


v iew Monitor is activated by pressing the CAMERA
button
01 , located on the control panel, or by moving
the shift lever to the R (REVERSE) position. The control



panel displays various views of the position of




the vehicle. When the shift lever is in the P (PARK), N (NEUTRAL)
or D (DRIVE)

position and the CAMERA button
01 is
pressed, the following views will display in order:
new system features
When the shift lever is in the R (REVERSE) position and the CAMERA button
01 is pressed,

the following views will display in order:
Start from any Control Panel screen
Press
Press Press
Press
01
Rear view & bird’s-eye view
Press
Press
Press Rear view & front-side view
Rear wide view
Front wide view Front view & bird’s-eye viewFront view & front-side view
1354681_14a_Infiniti_QX70_QRG_052813.indd 25/28/13 11:59 AM

3
02
03
For information regarding how to access additional viewing cycles, pleas\
e see your
Owner’s Manual.
The colored guide lines on the display screen indicate vehicle width and\
approximate distances




to objects with reference to the vehicle body line.


• Red 1.5 ft (0.5 m); Yellow 3 ft (1 m); Green 7 ft (2 m) and 10 ft (3 m).
There are some areas where the system will not show objects.
•
When
in the front or the rear view display, an

object below the bumper or on the ground may


not be viewed
02.
•
When


in

the

bird’s-eye view, a tall object near

the seam of the camera viewing areas
03
will not appear in the monitor.
The distance between objects viewed on the
A v M differs from the actual distance.
Objects in the bird’s-eye view will appear further
than the actual distance.
MO
v ING OBJECT DETECTION (MOD)
If the MOD system detects moving objects surrounding



the vehicle, a yellow frame 01 will be displayed on the
camera image and a chime sounds.
In the bird’s-eye view, a yellow frame is displayed on



those camera images (front, rear, right, left) where




moving objects are detected.
When the following are displayed:

•
Blue MOD

icon
02 : the system is operative in this view.
•
Gray MOD

icon
03 : the system is not operative in this view.
•
No MOD

icon: the system is off. The indicator will also be off if all of the w\
arning systems are
deactivated using the camera settings menu.
To temporarily turn the system on or off, touch the 04 key.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your Owner’s Manual.
04
01
03
Garage Mode System
Your vehicle’s power liftgate operation can be set to stop opening at\
a user selected



position in order to help avoid damaging the liftgate or overhead object\
s.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
02
04
1354681_14a_Infiniti_QX70_QRG_052813.indd 35/28/13 11:59 AM

4
Tire Pressure Monitoring System (TPMS)
A Ch
ECK TIRE PRESSURE warning message will
appear in the vehicle information display
01 and

the low tire pressure warning light 02 will illuminate

when one or more tires are low on pressure and air
is needed.
•
The


tire

pressures

should

be

checked when the tires

are cold. The tires are considered cold after the


vehicle has been parked for 3 hours or more or
driven less than 1 mi (1.6 km) at moderate speeds.
After tire pressures are adjusted, drive the vehicle at speeds above 16 \
MPH (25 km/h). The
C
h ECK TIRE PRESSURE warning message and low tire pressure light will disappear.
When the low tire pressure warning light flashes for 1 minute and then r\
emains on, the TPMS
is not functioning properly. Have the system checked by an INFINITI reta\
iler.
Tire pressure rises and falls depending on the heat caused by the vehicl\
e’s operation and the
outside temperature. Low outside temperature can lower the temperature o\
f the air inside
the tire, which can cause a lower tire inflation pressure. This may caus\
e the low tire pressure
warning light to illuminate. If the warning light illuminates, check the\
tire pressure in your tires.
•
Check

the tire pressure (including the spare tire) often and always prior to long

distance trips.
The Tire and Loading Information label contains valuable information. Pl\
ease refer to
section 9, “Technical and consumer information”, in your Owner’\
s Manual for the location of
the Tire and Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“ Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
essential information
Loose Fuel Cap
A LOOSE FUEL CAP
warning message will appear in
the vehicle information display
01 when the fuel-
filler cap is not tightened correctly.
To tighten, turn the cap clockwise until a single click
is heard.
The warning message will disappear when the vehicle
detects the fuel-filler cap is properly tightened and
the reset button
02 is pressed.
If the cap is not properly tightened, the Malfunction

Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and the “Pre-driving checks and adjustments (section 3)”
of your Owner’s Manual.
01
02
01
02
Front Armrest/Center Console Storage Box
To access the bottom storage bin, pull up on the
driver’s side lever 01.
To access the top storage bin, pull up on the
passenger’s side lever 02.For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
0201
1354681_14a_Infiniti_QX70_QRG_052813.indd 45/28/13 11:59 AM

5
INFINITI Intelligent Key System
The INFINITI Intelligent Key system allows you to lock or
unlock your vehicle, open your liftgate and start the engine.
It is important to make sure the Intelligent Key is
with you (that is, in your pocket or purse).
The operating range of the Intelligent Key is within

31.5 in (80 cm) from each request switch.
To lock the vehicle, push either door handle request

switch
01 once or press the
button
02 on the key fob.
To unlock the vehicle, perform one of the following procedures:

•
Push either door handle request switch 01 once; the

corresponding door will unlock. Push the door handle
request switch
01 again within 1 minute; all other

doors will unlock, or
•
Press the button
03 on the key fob to unlock the driver’s

side door. Press the
button again; all other doors will

unlock.
To open the liftgate, press the button 04 for more than 1 second.

The Intelligent Key can also be used to activate the panic alarm by pres\
sing and holding the

button 05 for more than 1 second. Once activated, the panic alarm and headlights w\
ill stay on
for a period of time.
INFINITI INTELLIGENT KEY BATTERY DISCHARGE
If the battery in the Intelligent Key is almost discharged,

the guide light
06 of the Intelligent Key port blinks and

the Intelligent Key insertion indicator 07 is displayed in

the vehicle information display.
To start the engine under these circumstances, insert

the Intelligent Key into the key port with the keyring
side facing backward until it latches into place. Then
push the ignition switch to start the engine.
To remove the Intelligent Key from the port, push the

ignition switch to turn the engine off and then pull the
Intelligent Key out of the port.
The Intelligent Key port does not charge the Intelligent

Key battery. If you see the Intelligent Key warning light

08 , replace the battery in the Intelligent Key.

Do not insert the mechanical key or other objects into
the key port because it will damage the key port.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)”, “Starting and driving (section 5)” and the “Maintenance and do-it yourself (section 8)” of your Owner’s Manual.
first drive features
01
02
03
04
05
06
F E
07
08
1354681_14a_Infiniti_QX70_QRG_052813.indd 55/28/13 11:59 AM

6
first drive features
Power Liftgate
When the liftgate is closed and locked, the liftgate
will open automatically by:
•
Pushing the power liftgate switch 01 on the
instrument panel.
•
Pushing the liftgate opener switch 02, the liftgate
must be unlocked, or you must have the Intelligent
Key with you (in your pocket or purse).
•


Pressing the
button
03 on the
INFINITI Intelligent Key for a period
of time.
The power liftgate operation can be turned on or
off by the power liftgate main switch
04 on the
instrument panel.
• When the power liftgate main switch is pushed


to the OFF position, power operation is not
available using the power liftgate switch on
the liftgate
05 or the liftgate opener
switch 02.
For more information, refer to the “Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
Power Seat Adjustments
To slide the seat forward or backward, push the control

switch 01 forward or backward.

To recline the seatback, push the switch
02
forward or backward.
SEAT LIFTER
To raise or lower the front portion or height of the seat,


push the front or back end of the switch 01
up or down.
POWER LUMBAR SUPPORT


To adjust the seat lumbar support, push the front or back end of the swi\
tch 03.
For more information, refer to the “Safety —— seats, seat belts and supplemental restraint system (section 1)”\
of your
Owner’s Manual.
01
02
010203
0305
04
1354681_14a_Infiniti_QX70_QRG_052813.indd 65/28/13 11:59 AM
