2014 INFINITI QX60 HYBRID display

2. Getting started
2-16
Inputting letters and numbers
1. Touch the letter or number.
2. Touch [Delete] to delete a character.Push and hold [Delete] to delete all of
the characters.
HOW TO INPUT LETTERS AND NUMBERS
CHARACTER (letters and numbers)
INPUT SCREEN
Alphanumeric characters are entered to set
a destination, search for a facility, edit
stored locations, etc.
1. Use the INFINITI controller to highlight a
character on the displayed keyboard.
2. Push . The highlighted charac-
ter is entered.
INFO:
Inputting letters can also be done with the
touch panel operation.
3. Push , or highlight [Delete] and
push to delete the last char-
acter entered.
Push and hold to delete all the
characters entered.
Highlight [Space] and push to
enter a space.

4. After finishing the entry, highlight [List]and push .
INFO:
.
Push on the control panel to return
to the previous screen, but only after
deleting all the characters entered.
.Touch [BACK] on the screen to return to the
previous screen even when characters have
been entered.
.The list screen appears automatically when
text has been entered and the matching list
items have been narrowed down to a
number that will fit on the screen.
Symbol input screen
.Symbol keys are displayed by highlighting
[Symbols] and pushing . Alphabet
keys are displayed by highlighting [A-Z] and
pushing .
NUMBER INPUT SCREEN
A phone number or a street number can
also be entered as a search method to look
for a destination. Perform the following
procedure to enter a number.
INFO:
Only the locations included in the map data
database can be searched for by a phone
number.
1. Use the INFINITI controller to highlight a
number on the displayed keyboard.
2. Push . The highlighted number
is entered.
INFO:
Inputting numbers can also be done with
the touch panel operation.
3. Push , or highlight [Delete] and
push to delete the last number
entered.
Push and hold to delete all the
numbers entered.
2. Getting started
2-17

2. Getting started
2-18
4. After finishing the entry, highlight [List]and push .
INFO:
.
Push on the control panel to return
to the previous screen, but only after
deleting all the numbers entered.
.Touch [BACK] on the screen to return to the
previous screen even when numbers have
been entered.
MAP MENU SCREEN
Push while the current location
map screen or a scrolled map screen is
displayed to display the menu correspond-
ing to that screen.
This menu can be used to access helpful
functions quickly, such as setting a desti-
nation and searching for points of interest
nearby.
There are various methods used to select a
menu item. Use a method described earlier
in this manual.
“Menu screen and operation method”
(page 2-11)
INFO:
With the touch panel operation, the same
screen can be displayed by touching [Map
Menu] located on the map screen.
CURRENT LOCATION MAP SCREEN
If is pushed while the current
location map screen is displayed, the
following options are available.
. [Store Location]:
Stores the current vehicle location in
the Address Book. The stored location
can be retrieved as necessary to set it
as a destination (waypoint).
“Storing location” (page 6-2)
. [Nearby Places]:
Searches for points of interest near the
current vehicle location, such as res-
taurants and gas stations, etc.
“Finding nearby place” (page 4-6)
. [Map View]:
Performs map operations such as the
switching of map type and the setting
of map orientation and scale.

“3. Map settings”
. [Map Icons]:
Displays map icons of certain points of
interest (such as restaurants and gas
stations, etc.) on the map around the
current vehicle location.
“Displaying map icons”
(page 3-18)
. [Store Tracking]:
Stores in the Address Book the route
travelled from the starting point to the
current location.
“Storing tracked route” (page 6-6)
SCROLLED LOCATION MAP SCREEN
If is pushed while a scrolled map
screen is displayed, the following options
are available. .
[New Dest.]:
Sets the destination to the map loca-
tion where was pushed. If a
destination is already set, the location
will be set as the new destination.
“Setting point on map”
(page 4-23)
. [Add to Route]:
Sets the map location where
was pushed as the destination or a
waypoint. This is available only when a
suggested route is already set.
“Setting destination or waypoint”
(page 5-15)
. [Nearby Places]:
Searches for points of interest near the
map location where was
pushed and sets them as a destination
or waypoint.
Use the same search method as the
one for [Places].
“Finding nearby place” (page 4-6)
. [Store Location]:
Store the map location where
was pushed in the Address Book. The
stored location can be retrieved to set it
as a destination or waypoint.
“Storing location” (page 6-2) .
[Delete]:
Deletes a stored location. Available
only when the cross pointer is placed
over a stored location icon.
. [Incident Detail]:
This function can be selected only when
the traffic information icon is dis-
played. Displays the details of the
traffic information icon. Place the cross
pointer over the icon to be checked.
INFO:
Incident details are a feature of Traffic Informa-
tion, and a NavTraffic subscription is required in
order to receive Traffic Information.
2. Getting started
2-19

2. Getting started
2-20
STORING HOME LOCATION/ADDRESS
HOW TO STORE HOME LOCATION
If a home location is already stored in the
Address Book, it can be easily retrieved to
set the route to the stored home location.
The procedure to store the home location is
the same as for storing any other location.
“4. Setting destination”
As an example, the procedure for storing
the home location by searching for a
destination by address is described here.
1. Push .
2. Highlight [Home (Add New)] and push .
3. A confirmation message is displayed.Confirm the message, highlight [Yes]
and push .
4. Highlight [Street Address] and push
. A character input screen is
displayed.
5. Enter the address of the home location,highlight [OK] and push .
“Finding address”(page 4-4)
The map screen is displayed.
6. Adjust the location of your home using the INFINITI controller, if necessary.
7. After adjusting the location, push .

INFO:
It is recommended to move the home
location for security reasons.
8. A message is displayed and the homelocation is stored.
9. Highlight [OK] and push .
10. Push

2. Getting started
2-22
INFO:
The search can also be narrowed down by
selecting [All Categories or Name] or [ZAGAT]
on this screen. By selecting [All Categories
or Name], the area, name of facility, etc. can
be specified. By selecting [ZAGAT], restau-
rants registered in the ZAGAT database can
be searched and sorted by their rating
regarding food, decor, cost, service, etc.
The Zagat Content displayed may not reflect
the most up-to-date Zagat Content available
to the public.
4. Highlight the preferred restaurant fromthe list and push .
INFO:
.The position of the selected location is
displayed in the preview on the right
side of the screen.
.If there is a route already in progress,only places along the current route will
be listed. Turn off [Show Along Route] at
the top of list to display all nearby
places.
5. The entire route is shown on the map. Highlight [Start] after confirming the
location of the displayed destination,
and push .
The system sets the destination to the
selected location and starts calculating
a route.
INFO:
Even after setting a destination, the location
of the destination can be adjusted and the
route can be stored, etc., if necessary.
“Procedures after setting destination”
(page 5-2)
STARTING ROUTE GUIDANCE
After the destination is set and route
calculation is performed, the suggested
route is displayed.
1. Highlight [Start] and push .
2. Once route guidance is started, the
system navigates you through the
guide points using visual and voice
guidance.

3. When approaching a guide point, thesystem automatically changes to the
split screen and shows an enlarged
view of the intersection in the left
screen. Push
