2014 INFINITI Q50 HYBRID remote control

JVC0425X
1. Coat hooks (P.2-53)
2. Rear personal light (P.2-59)
3. Sun visors (P.3-25)
4. Map light (P.2-58)—SOS call switch (if so equipped)*
5. Moonroof switch (P.2-56) 6. Sunglasses holder (P.2-51)
7. Power window switch (P.2-54)/Out-
side mirror remote control switch
(P.3-26)
8. Automatic drive positioner switch (if so equipped) (P.3-28) 9. Inside mirror
—Operation (P.3-25)
— HomeLink
®universal transceiver
(P.2-61)
— Compass (if so equipped) (P.2-9)
10. Rear armrest (P.1-5)
11. Rear cup holders (P.2-49)
12. Rear ashtray (if so equipped) (P.2-49)
13. Console box (P.2-52) —Power outlet (P.2-48)
— Media hub*
14. Front cup holders (P.2-49)
15. Front passenger air bag status light (P.1-44)
*: Refer to the Infiniti InTouch Owner’s Manual.
Illustrated table of contents0-5
PASSENGER COMPARTMENT

JVI0655X
Sunshade
The sunshade will open automatically
when the moonroof is opened. However,
it must be closed manually.
Tilting the moonroof
To tilt up, first close the moonroof, then
push the switch to the tilt up position
*1
and release it; it need not be held. To tilt
down the moonroof, push the switch to the
tilt down position
*2.
Sliding the moonroof
To fully open or close the moonroof, push
the switch to the open
*2or close*1
position and release it; it need not be held.
The roof will automatically open or close all
the way. To stop the roof, push the switch
once more while it is opening or closing.
Operating moonroof with Intelligent
Key (if so equipped)
The moonroof can be opened by pushing
the UNLOCK button on the Intelligent Key.
This function will not operate while the
moonroof timer is activated or when the
moonroof need to be initialized. For details
about the Intelligent Key button usage, see
“How to use remote keyless entry system”
(P.3-15).
Opening:
To open the sunroof, push the UNLOCK
button on the Intelligent Key for about 3
seconds after the door is unlocked.
To stop opening, release the
button.
Auto reverse function
WARNING
There are some small distances immediately
before the closed position which cannot be
detected. Make sure that all passengers
have their hands, etc., inside the vehicle
before closing the moonroof.
If the control unit detects something
caught in the moonroof when it is closing,
the moonroof will be immediately opened.
The auto reverse function can be activated
when the moonroof is closed by automatic
operation when the ignition switch is in the
ON position or for about 45 seconds after
the ignition switch is pushed to the OFF
position.
If the moonroof cannot be closed auto-
matically when the auto reverse function
activates due to a malfunction, push and
hold the moonroof switch to the close
position
*1.
Depending on the environment or driving
conditions, the auto reverse function may
be activated if an impact or load similar to
something being caught in the moonroof
Instruments and controls2-57

3-4Pre-driving checks and adjustments
WARNING
.Always have the doors locked while
driving. Along with the use of seat belts,
this provides greater safety in the event
of an accident by helping to prevent
persons from being thrown from the
vehicle. This also helps keep children
and others from unintentionally opening
the doors, and will help keep out
intruders.
. Before opening any door, always look for
and avoid oncoming traffic.
. Do not leave children unattended inside
the vehicle. They could unknowingly
activate switches or controls. Unat-
tended children could become involved
in serious accidents.
JVP0231X
LOCKING WITH MECHANICAL KEY
The power door lock system allows you to
lock or unlock all doors simultaneously
using the mechanical key.
.Turning the driver’s door key cylinder to
the front of the vehicle
*1will lock all
doors.
. Turning the driver’s door key cylinder
once to the rear of the vehicle
*2will
unlock the driver’s door. After returning
the key to the neutral position
*3,
turning it to the rear again within 60
seconds will unlock all doors. .
You can switch the lock system to the
mode that allows you to open all the
doors when the key is turned once.
(See the Infiniti InTouch Owner’s Man-
ual for details.)
OPENING AND CLOSING WINDOWS
WITH MECHANICAL KEY
The driver’s door key operation also allows
you to open and close the window that is
equipped with the automatic open/close
function. (See “Power windows” (P.2-54).)
To open the window, turn the driver’s door
key cylinder to the rear of the vehicle for
longer than 1 second. The door is unlocked
and the window keeps opening while
turning the key.
This function can also be performed by
pushing and holding the UNLOCK button
on the Intelligent Key. (See “Remote key-
less entry system” (P.3-14).)
To close the window, turn the driver’s door
key cylinder to the front of the vehicle for
longer than 1 second. The door is locked
and the window keeps closing while turn-
ing the key.
DOORS

3-6Pre-driving checks and adjustments
3. Within 20 seconds of performing Step2, push and hold the power door lock
switch to the
position (UNLOCK) for
more than 5 seconds.
4. When activated, the hazard indicator will flash twice. When deactivated, the
hazard indicator will flash once.
5. The ignition switch must be placed in the OFF and ON position again between
each setting change.
When the automatic door unlock system is
deactivated, the doors do not unlock when
the ignition switch is placed in the OFF
position. To unlock the door manually, use
the inside lock knob or the power door lock
switch (driver’s or front passenger’s side).
The automatic door unlock function can be
changed on the lower display. (See the
Infiniti InTouch Owner’s Manual.)
SPA2536
CHILD SAFETY REAR DOOR LOCK
The child safety rear door lock helps
prevent doors from being opened acciden-
tally, especially when small children are in
the vehicle.
When the levers are in the lock position
*1, the rear doors can be opened only
from the outside.
To disengage, move the levers to the
unlock position
*2.
WARNING
. Radio waves could adversely affect
electric medical equipment. Those who
use a pacemaker should contact the
electric medical equipment manufacturer
for the possible influences before use.
. The Intelligent Key transmits radio
waves when the buttons are pushed.
The FAA advises that the radio waves
may affect aircraft navigation and com-
munication systems. Do not operate the
Intelligent Key while on an airplane.
Make sure the buttons are not operated
unintentionally when the unit is stored
during a flight.
The Intelligent Key system can operate all
the doors and the trunk lid using the
remote controller function, using one touch
unlock function or pushing the request
switch on the vehicle without taking the
key out from a pocket or purse. The
operating environment and/or conditions
may affect the Intelligent Key system
operation.
Be sure to read the following before using
the Intelligent Key system.
INTELLIGENT KEY SYSTEM

CAUTION
.Be sure to carry the Intelligent Key with
you when operating the vehicle.
. Never leave the Intelligent Key in the
vehicle when you leave the vehicle.
The Intelligent Key is always communicat-
ing with the vehicle as it receives radio
waves. The Intelligent Key system trans-
mits weak radio waves. Environmental
conditions may interfere with the operation
of the Intelligent Key system under the
following operating conditions.
.When operating near a location where
strong radio waves are transmitted,
such as a TV tower, power station and
broadcasting station.
. When in possession of wireless equip-
ment, such as a cellular telephone,
transceiver, and CB radio.
. When the Intelligent Key is in contact
with or covered by metallic materials.
. When any type of radio wave remote
control is used nearby.
. When the Intelligent Key is placed near
an electric appliance such as a perso- nal computer.
. When the vehicle is parked near a
parking meter.
In such cases, correct the operating condi-
tions before using the Intelligent Key
function or use the mechanical key.
Although the life of the battery varies
depending on the operating conditions,
the battery’s life is approximately 2 years.
If the battery is discharged, replace it with
a new one.
When the Intelligent Key battery is almost
discharged, see “Intelligent Key battery
discharge” (P.5-13) to start the hybrid
system.
Since the Intelligent Key is continuously
receiving radio waves, if the key is left near
equipment which transmits strong radio
waves, such as signals from a TV and
personal computer, the battery life may
become shorter.
For information regarding replacement of a
battery, see “Intelligent Key battery repla-
cement” (P.8-25).
As many as 4 Intelligent Keys can be
registered and used with one vehicle. For
information about the purchase and use of
additional Intelligent Keys, contact an INFINITI retailer.
CAUTION
.
Do not allow the Intelligent Key, which
contains electrical components, to come
into contact with water or salt water.
This could affect the system function.
. Do not drop the Intelligent Key.
. Do not strike the Intelligent Key sharply
against another object.
. Do not change or modify the Intelligent
Key.
. Wetting may damage the Intelligent Key.
If the Intelligent Key gets wet, immedi-
ately wipe until it is completely dry.
. Do not place the Intelligent Key for an
extended period in an area where
temperatures exceed 1408F (608C).
. If the outside temperature is below 148F
(−108C), the battery of the Intelligent
Key may not function properly.
. Do not attach the Intelligent Key with a
key holder that contains a magnet.
. Do not place the Intelligent Key near
equipment that produces a magnetic
field, such as a TV, audio equipment
Pre-driving checks and adjustments3-7

3-14Pre-driving checks and adjustments
LOG-IN FUNCTION
After setting up the user information, the
system will automatically recognize the
user upon turning on the vehicle.
There will be a personalized welcome
greeting and screen prompt to log-in.
This feature allows 4 drivers to use their
own registration, drive mode, driving posi-
tion, air conditioner, and auto settings and
memorizes these custom settings.
The log-in user can be changed on the
welcome greeting screen or the User List
screen. For more details, see the Infiniti
InTouch Owner’s Manual.
The log-in function is linked to the follow-
ing items:
.Meter
. Audio
. Navigation system display (if so
equipped)
. Navigation settings (if so equipped)
. Air conditioner
. Automatic drive positioner (if so
equipped)
. Engine·Transmission
. Steering .
Active trace control
. Driver assistance (if so equipped)WARNING
The Intelligent Key transmits radio waves
when the buttons are pushed. The FAA
advises that the radio waves may affect
aircraft navigation and communication sys-
tems. Do not operate the Intelligent Key
while on an airplane. Make sure the buttons
are not operated unintentionally when the
unit is stored during a flight.
It is possible to lock/unlock all doors and
fuel-filler door, open the trunk lid, activate
the panic alarm and open the windows by
pushing the buttons on the Intelligent Key
from outside the vehicle.
Before locking the doors, make sure the
Intelligent Key is not left in the vehicle.
The remote keyless entry function can
operate at a distance of approximately 33
ft (10 m) from the vehicle. (The effective
distance depends upon the conditions
around the vehicle.)
As many as 4 Intelligent Keys can be used
with one vehicle. For information concern-
ing the purchase and use of additional
Intelligent Keys, contact an INFINITI retai-
ler.
REMOTE KEYLESS ENTRY SYSTEM

10-4
Indicator lights ................................................. 2-18
INFINITI Direct Response
Hybrid
®System .............................. Hybrid System-2
Before starting the INFINITI Direct Response
Hybrid
®System ........................................... 5-13
Starting the INFINITI Direct Response
Hybrid
®System ........................................... 5-14
INFINITI Drive Mode Selector ............................. 5-21
Infiniti InTouch Owner’s Manual .......................... 4-2
INFINITI Vehicle Immobilizer System .................. 2-37 Engine start ................................................. 2-37
Inside mirror ..................................................... 3-25
Inspection/maintenance (I/M) test .................... 9-22
Instrument brightness control ........................... 2-46
Instrument panel ................................................ 2-5
Intelligent All-Wheel Drive (AWD) ..................... 5-101
Intelligent Cruise Control (ICC) system ............... 5-58
Intelligent Cruise Control (ICC) system
ON indicator ..................................................... 2-28
Intelligent Key ..................................................... 3-2
Intelligent Key system ......................................... 3-6 Battery replacement ..................................... 8-25
Key operating range ....................................... 3-8
Key operation ................................................ 3-9
Warning signals ........................................... 3-12
Interior light control switch ............................... 2-59
Interior light replacement .................................. 8-28
Interior lights .................................................... 2-58
Interior trunk lid release ................................... 3-21
Inverter cooling system ..................................... 8-11
ISOFIX child restraint ........................................ 1-21
J
Jump starting ...................................................... 6-5
K
Keyless entry (See remote keyless
entry system) .................................................... 3-14
Keys ................................................................... 3-2 For Intelligent Key system .............................. 3-6
L
LabelsAir bag warning labels ................................. 1-50
Air conditioner specification label ................ 9-13
Emission control information label ............... 9-12
Engine serial number ................................... 9-12
F.M.V.S.S./C.M.V.S.S. certification label ........ 9-12
Tire and Loading information label ...... 8-31, 9-13
Vehicle identification number (VIN) .............. 9-11
Lane Departure Prevention (LDP) system ........... 5-33
Lane Departure Warning (LDW) system .............. 5-31
Lane Departure Warning (LDW) system/Lane
Departure Prevention (LDP) system ................... 5-30
LATCH system ................................................... 1-21
License plate Installing front license plate ......................... 9-14
Light Air bag warning light ................................... 1-50
Bulb replacement ......................................... 8-27 Fog light switch ........................................... 2-47
Headlight switch .......................................... 2-41
Indicator lights ............................................ 2-18
Interior light control switch .......................... 2-59
Interior lights ............................................... 2-58
Map lights ................................................... 2-58
Personal lights ............................................. 2-59
Replacement ................................................ 8-27
Trunk light ................................................... 2-60
Vanity mirror lights ...................................... 2-60
Warning/indicator lights and
audible reminders ........................................ 2-12
Lights
Exterior and interior light replacement ......... 8-28
Lithium-ion (Li-ion) battery .............. Hybrid System-2
Loading information (See vehicle
loading information) ......................................... 9-16
Lock Automatic door locks ..................................... 3-5
Door locks ..................................................... 3-4
Power door lock ............................................. 3-4
Trunk lid ...................................................... 3-19
Locking with mechanical key ............................... 3-4
Log-in function .................................................. 3-14
Loose Fuel Cap warning ........................... 2-25, 3-23
Low fuel warning light ...................................... 2-15
Low outside temperature warning ..................... 2-27
Low tire pressure warning light ......................... 2-15
Low tire pressure warning system (See Tire Pressure
Monitoring System (TPMS)) ................. 5-4, 6-3, 8-30

Ignition switch ............................................. 5-14
Power door lock switch .................................. 3-5
Rear window and outside mirror
defroster switch ........................................... 2-41
Turn signal switch ........................................ 2-47
Vehicle Dynamic Control (VDC) off switch ..... 2-48
T
Tachometer ......................................................... 2-8
TemperatureEngine coolant temperature gauge ............... 2-33
Theft (INFINITI Vehicle Immobilizer System)
Engine start ................................................. 2-37
Thigh extension .................................................. 1-5
Three-way catalyst .............................................. 5-4
Tilt/telescopic steering ...................................... 3-24
Tire Flat Tire - Visit dealer warning ..................... 2-26
Run-flat tires .................................................. 6-4
Tire replacement indicator ............................ 2-29
Tire rotation ................................................. 8-38
Tire pressure Low tire pressure warning light .................... 2-15
Tire Pressure Low - Add Air warning .................. 2-25
Tires Flat tire .......................................................... 6-3
Low tire pressure warning system ... 5-4, 6-3, 8-30
Run-flat tires ................................................ 8-36
Tire and Loading information label ...... 8-31, 9-13
Tire chains ................................................... 8-37
Tire dressing .................................................. 7-4 Tire pressure................................................ 8-30
Tire Pressure Monitoring
System (TPMS) .............................. 5-4, 6-3, 8-30
Types of tires ............................................... 8-35
Uniform tire quality grading ......................... 9-19
Wheel/tire size .............................................. 9-9
Wheels and tires .......................................... 8-30
Towing Flat towing ................................................... 9-19
Tow truck towing ............................................ 6-8
Towing a trailer ............................................ 9-19
TPMS Tire Pressure Monitoring System ... 5-4, 6-3, 8-30
TPMS, Tire pressure monitoring system TPMS with Tire Inflation Indicator................... 5-7
Trailer towing .................................................... 9-19
Transceiver HomeLink
®Universal Transceiver ................. 2-61
Transmission
Automatic transmission fluid (ATF) ............... 8-15
Driving with automatic transmission ............ 5-14
Transmission shift lever lock release ............ 5-18
Transmitter (See remote keyless entry system) ... 3-14
Traveling or registering your vehicle in
another country ................................................ 9-11
Trip computer ................................................... 2-31
Trip odometer ................................................... 2-33
Trunk Interior trunk lid release .............................. 3-21
Light ............................................................ 2-60
Trunk hooks ................................................. 2-53 Trunk lid ...................................................... 3-19
Trunk lid release switch ............................... 3-19
Trunk open request switch ........................... 3-19
Trunk release power cancel switch ............... 3-20
Turn signal switch ............................................. 2-47
U
Underbody cleaning ............................................ 7-3
Uniform tire quality grading .............................. 9-19
V
Vanity mirror ..................................................... 3-28
Vanity mirror lights ........................................... 2-60
Vehicle Dimensions .................................................. 9-10
Recovery (freeing a stuck vehicle) ................ 6-11
Vehicle Dynamic Control (VDC) off switch ..... 2-48
Vehicle Dynamic Control (VDC) system ....... 5-108
Vehicle Dynamic Control (VDC)
warning light ............................................... 2-18
Vehicle identification number (VIN) ................... 9-11
Vehicle information display ............................... 2-21
Vehicle loading information .............................. 9-16
Vehicle security system ..................................... 2-35
Ventilators .......................................................... 4-2
W
Warning Blind Spot Warning (BSW) system ................ 5-38
10-7
