2014 HONDA RIDGELINE lock

CONT INUED
Loosen each wheel nut 1/2 turn
with the wheel nut wrench.Place the jack under the jacking
point nearest the tire you need
to change.Turn the dial at the bottom of the
jack clockwise until the top of the
jack contacts the jacking point.
Make sure the jacking point tab is
restinginthejacknotch.
8.
9.10.
Changing a Flat Tire
361
JACKING POINT DIAL
12/08/09 16:46:42 31SJC670_368
T aking Care of t he Unexpect ed

Attach the stay to the extension,
then attach the wheel nut wrench
to the end of the extension.Turn the jack dial (wheel nut
wrench) clockwise as shown to
raise the vehicle until the f lat tire
is of f the ground.
Make sure the stay, the extension,
and the wheel nut wrench are
securely attached. Insert the hook at the end of the
stay into the opening on the dial at
the bottom of the jack.
11.
12.13.
Changing a Flat Tire
362
EXTENSION
DIAL
CONNECTOR BUTTON
HOOK
STAY WHEEL NUT WRENCH
CONNECTOR BUTTON
12/08/09 16:46:48 31SJC670_369
T aking Care of t he Unexpect ed

Diagnosing why the engine won’t
start f alls into two areas, depending
on what you hear when you turn the
ignition switch to the START (III)
position:Check the transmission
interlock. The transmission must
be in Park or neutral or the
starter will not operate.
Turn the ignition switch to the ON
(II) position. Turn on the
headlights, and check their
brightness. If the headlights are
very dim or do not come on at all,
the battery is discharged. See
on page . If the headlights dim noticeably or
go out when you try to start the
engine, either the battery is
discharged or the connections are
corroded. Check the condition of
the battery and terminal connec-
tions (see page ). You can
then try jump starting the vehicle
from a booster battery (see
page ).
In this case, the starter motor’s
speed sounds normal, or even f aster
than normal, when you turn the
ignition switch to the START (III)
position, but the engine does not run. Are you using a properly coded
key? An improperly coded key will
cause the immobilizer system
indicator in the instrument panel
to blink rapidly (see page ).
Turn the ignition switch to the
START (III) position. If the
headlights do not dim, check the
condition of the f uses. If the f uses
areOK,thereisprobably
something wrong with the
electrical circuit for the ignition
switch or starter motor. You will
need a qualif ied technician to
determine the problem. See
on page .
Check these things:
When you turn the ignition switch to
the START (III) position, you do not
hear the normal noise of the engine
trying to start. You may hear a
clicking sound, a series of clicks, or
nothing at all. You can hear the starter motor
operating normally, or the starter
motor sounds like it is spinning
f aster than normal, but the engine
does not start up and run. You hear nothing, or almost
nothing. The engine’s starter
motor does not operate at all, or
operates very slowly.
101
368
381 353
368
CONT INUED
Jump Starting T he Starter Operates Normally
Emergency T owing
Nothing Happens or the Starter
Motor Operates Very Slowly
If theEngineWon’tStart
367
12/08/09 16:47:27 31SJC670_374
T aking Care of t he Unexpect ed

If the temperature gauge stays at
the red mark, turn of f the engine.
Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (seeon page ).
Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (seeon page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back
on tightly.
If you do not f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the tempera-
ture gauge, or lower, bef ore check-
ing the radiator.
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without
pushing down, to the first stop.
After the pressure releases,
push down on the cap, and turn it
until it comes off.Start the engine, and set the
temperature to maximum heat
(climate control to AUTO at ‘‘
’’). Add coolant to the radiator
up to the base of the filler neck.
If you do not have the proper
coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and refilled with
the proper mixture
as soon as you can.
4.
5.
6.
7. 8.9.
10.
11.
381
381
Emergency
Towing
Emergency
Towing
If theEngineOverheats
371
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
12/08/09 16:47:59 31SJC670_378
T aking Care of t he Unexpect ed

Check the smaller f uses in the
under-hood f use boxes and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the primary
under-hood f use box.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Check each of the large f uses in
the primary under-hood f use box
by looking through the side
window at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.
R emove the cover f rom
the fusebox. 4.
3.
1.
2.
CONT INUED
Fuses
377
BLOWN
FUSE PULLER
BLOWN
FUSE
12/08/09 16:48:45 31SJC670_384
T aking Care of t he Unexpect ed

µ
µ
µ
ÎÎ
Î
Î
No. No.
No. Amps.
Amps. Amps.
Circuits Protected
Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
If equipped
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1 7.5 A
7.5 A
15 A
10 A
15 A
20 A
10 A
7.5 A 20 A
10 A
7.5 A 30 A
(10 A)
(20 A)
(20 A) 15 A
15 A
7.5 A
7.5 A 10 A
7.5 A 20 A
20 A
20 A
20 A
20 A
7.5 A 10 A
7.5 A
7.5 A
(7.5 A) STS
Bed Lights
IG Coil
Daytime Running Light
LAF
Radio
Interior Lights
Back Up
Door Lock
Rear Accessory Socket
IG OPDS IG Wiper
Not Used
Driver’s Power Seat Lumbar
Driver’s Power Seat Sliding
Not Used
Driver’s Power Seat Reclining
Not Used
IG ACG
IG Fuel Pump
IG Washer
IG Meter
IG SRS
IGP
Left Rear Window
Right Rear Window
Passenger’s Window
Back Window
Driver’s Window
VBSOL2
IG HAC
IG VSA/ABS
ACC
Not Used
:
Fuse Locations
380
INTERIOR FUSE BOX UPPER AREA
INTERIOR FUSE BOX
Driver’s Side
12/08/09 16:49:11 31SJC670_387
T aking Care of t he Unexpect ed

The engine number is stamped into
the engine block. It is on the f ront.
The transmission number is on a
label on top of the transmission.
Identif ication Numbers
Technical Inf ormation
385
ENGINE NUMBERAUTOMATIC TRANSMISSION NUMBER
12/08/09 16:49:34 31SJC670_392

CONT INUED
Back Window.......................................
Indicator .75
...........................
Operation .128, 129
Battery Charging System ...........................
Indicator .63, 372
............................
Jump Starting .368
..............................
Maintenance .353
............................
Specif ications .387 Bed Lights
.......................................
Indicator .74
...................................
Operation .144
..............................
Bef ore Driving .243
....................................
Belts,Seat .8,20
.........................
Beverage Holders .137
........
HandsFreeLink. 217
..................................
Booster Seats .52
Brakes ...........
Anti-lock System (ABS) . 287
.............
Break-in, New Linings . 244
...........................................
Fluid .331
............
Bulb Replacement . 337,338
.......................................
Parking .132
.................
System Indicator . 65, 374
........................
Wear Indicators .286
.............................
Braking System .286
.................
Break-in, New Vehicle . 244
..
Brightness Control, Instruments . 98
...
Accessories and Modif ications . 255
ACCESSORY (Ignition Key .....................................
Position) .102
............
Accessory Power Sockets . 139
...........................
AC Power Outlet .141
................
Active Head Restraints . 124
....................
Additives, Engine Oil . 325
........
Adjusting the Steering wheel . 99
...........................
Advanced Airbags .27
...............................
Airbag (SRS) .9, 23
..............
Air Conditioning System . 146
.................................
Usage .147, 153
.......................
Air Outlets (Vents) .157
.......................
Air Pressure, Tires .347
......................................
Antif reeze .327
Anti-lock Brakes (ABS) ...............................
Indicator .66, 287
...................................
Operation .287
..............
Anti-thef t, Audio System . 205
Anti-thef t Steering Column ............................................
Lock .102
........................................
Armrests .122
................
Audio System . 159,167, 174
...
Auto Door Locking/Unlocking . 104Automatic Heated Wiper
..............................
Zone .95, 150, 156
...
Automatic Seat Belt Tensioners . 22
.............
Automatic Speed Control . 210
..............
Automatic Transmission . 269
..........................
Capacity, Fluid .386
...............
Checking Fluid Level . 329
.......................................
Shif ting .269
Shif t Lever Position ...............................
Indicators .269
................
Shif t Lever Positions . 270
....................
Shif t Lock Release . 273
......................
Auxiliary Input Jack .205Bluetooth
A
B
I
