INSTRUMENT PANEL INDICATORSBriefly appear with each engine start. Red and amber indicators are most critical.
Blue and green indicators are used for general information. See your Owner’s
Manual for more information.
45
Malfunction IndicatorsIf an indicator remains on, there may be a problem; see your dealer
On/Off Indicators
Condition IndicatorsAction is needed by driver
PASSENGERAIRBAG
OFF%''# & & OFF(next to i\bMID)
VSA OFF
FCW off
CRUISE CONTROL on
Exterior lights on
Turn signals/hazards on
ECON on
High beams on
Charging system
Low brake fluid, Brake system
Low oil pressureAnti\bLock Brake System (ABS)
Vehicle Stability Assist®(VSA)
Supplemental Restraint System
(SRS)
Electric Power Steering (EPS)
Low temperature
Transmission (blinking)
Parking brake on:
Release
Low fuel:
Refill
Low tire pressure:
Add air
Immobilizer (blinks):
Use other vehicle key
and see dealer
Malfunction indicator lamp
(check engine light)
Seat belt reminder:
Fasten seat belt(s)
D
Message indicator:
See i MID
Door/Trunk open:
Close door(s) / trunkHigh temperature:
Drive slowly or pull over
Tire Pressure Monitoring System
(TPMS) (blinks and stays on)
CRUISE MAIN on
Smart Entry System
Brake system
Forward Collision
Warning (FCW)
IMA (hybrid) system Lane Departure Warning (LDW)
Auto idle stop (blinks)
14 Civic Hybrid TRG_Base_\AATG_NEW STYLE 1/\b/\A2014 1\f17 PM Page 4\A
\b9
Turning ECON Mode On/Off
3. Check the i\bMID for thesystem status.
4. Press ECON again to turn the system off.
E C O A S S I S TT M
When turned on, performance of the vehicle’s engine, transmission, cruise control, and
air conditioning system are adjusted to maximize fuel efficiency.
2. The ECON mode indicatorcomes on.
Ambient Meter
mphmphmph
High fuel efficiency Moderate fuel efficiency Low fuel efficiency
\f. Press ECON.
Indicates real\btime fuel efficiency using color\bcoded bars.
This feature can be turned off in the Customize Settings\2 Menu. See your Owner’s
Manual for more information.
Driver Feedback
Real time Fuel Efficiency Coach
Driving StyleEco Drive Bar
(on the i MID)Ambient Meter
Background Color ChangesFuel Efficiency
Smooth, steady
acceleration
high fuel efficiency
mph
*()
/6
Smooth, steady
deceleration
high fuel efficiency
Moderate acceleration
mph
"=23@/B32313:3@/B7=<
&/>72/113:3@/B7=<
low fuel efficiency
mph
Rapid deceleration
low fuel efficiency
Goals:
• Keep the Eco Drive bar near the center.
• Keep the Ambient Meter at GREEN.
• Develop a driving style that maximizes fuel efficiency.
Deceleration Acceleration
Inefficient
Braking Zone Efficient
Zones
Inefficient
Driving Zone
