2014 HONDA ACCORD SEDAN Technology Reference Guide

2\b1\f Accord Coupe
EXL with Navigation
\7 o w n e r s . h o n d a . c o m
2 \b 1 \f H o n d a A c c o r d C o u p e E X L w i t h N a v i g a t i o n
3 1 T 3 L C 1 \b T e c h n o l o g y R e f e r e n c e G u i d e
\b \b X 3 1 T 3 L C 1 \b \b ©2\b13 American Honda Motor Co., Inc. — All Rights Reserved P r i n t e d i n U . S . A .
T E C H N O L O G Y
R E F E R E N C E G U I D E
14 Accord 2D TRG_EXL \ANAVI_ATG_NEW STYLE \A 7/18/2013 9\f0\b AM \APage 1

T E C H N O L O G Y R E F E R E N C E G U I D E
This Technology Reference Guide is designed to help you
get acquainted with your 2014 Honda Accord Coupe EXL
with Navigation and provide basic instructions on some of
its technology and convenience features.
This guide is not intended to be a substitute for the
Owner’s Manual. For more detailed information on vehicle
controls and operation, please refer to the respective
sections in the Owner’s Manual or Navigation Manual.
*if equipped
NAVIGATION
p.24
BLUETOOTH®
HANDSFREELINK®p.27
ECO
ASSIST TMp. 8
INSTRUMENT
PANELp. 4
Voice Recognition ...................................................................................................20
Navigation.................................................................................................................24
Bluetooth®HandsFreeLink®(HFL)........................................................................27
SMS Text Messaging and EMail ...........................................................................31
Basic Audio Operation ..........................................................................................32
iPod®or USB Flash Drive .....................................................................................33
Hard Disc Drive (HDD) Audio ...........................................................................34
Song By Voice™ ......................................................................................................35
Pandora®...................................................................................................................36
HondaLink featuring AhaTM...................................................................................37
Bluetooth®Audio ......................................................................................................38
HomeLink®*.............................................................................................................39
Honda Owners .......................................................................................................40
Safety Reminder ......................................................................................................40
Fuel Recommendation...........................................................................................41
Smart Entry with Push Button Start.....................................................................2
Instrument Panel Indicators ...................................................................................4
Information Display ..................................................................................................6
Eco AssistTM................................................................................................................8
Tire Pressure Monitoring System (TPMS)...........................................................9
Settings for Your Vehicle ........................................................................................10
Auto Door Locks ...................................................................................................11
Driving Position Memory System (DPMS)........................................................12
OneTouch Turn Signal...........................................................................................13
Auto Headlights with Wiper Integration...........................................................13
MultiView Rear Camera ......................................................................................14
LaneWatchTM...........................................................................................................15
Lane Departure Warning (LDW) ........................................................................16
Forward Collision Warning (FCW) ....................................................................17
Intelligent MultiInformation Display (iMID) ...................................................18
Using the Touchscreen...........................................................................................19
iMID p.18
14 Accord 2D TRG_EXL NAVI_ATG_NEW STYLE 7/18/2013 9:06 AM Page 2

23
S M A R T E N T R Y W I T H P U S H B U T T O N S T A R TOperate certain functions of your vehicle by simply having the remote transmitter
within operating range.
Unlocking the Doors
Locking the Doors
Engine Start/Stop Button
A c c e s s o r y o r O n M o d e
Press ENGINE START/STOP once without pressing the brake pedal for Accessory
mode. Press it again for On mode.
S t a r t i n g t h e E n g i n e
Press and hold the brake pedal*, then press ENGINE START/STOP.*For manual transmission, press and hold the clutch.
T u r n i n g t h e V e h i c l e O f f
Shift to Park*, then press ENGINE START/STOP.*For manual transmission, apply the parking brake.
Note: If you press ENGINE START/STOP and the shift lever is not in Park, the
vehicle goes into Accessory mode.
Grab either one of the door handles when
the vehicle is off. Wait until the doors unlock,
then pull the handle to open.
Press the door lock button on either door
handle when the vehicle is off.
Opening the Trunk
Press the trunk release button under the
trunk handle.
14 Accord 2D TRG_EXL \ANAVI_ATG_NEW STYLE \A 7/18/2013 9\f0\b AM \APage 3

45
INSTRUMENT PANEL INDICATORS
Malfunction IndicatorsIf an indicator remains on, there may be a problem; see your dealer
On/Off Indicators
Condition IndicatorsAction is needed by driver
PASSENGER AIRBAG OFF(next to display screen)
VSA OFF
CRUISE CONTROL on
ECON Mode on Fog lights on
Headlights on
Turn signals/hazards on
High beams on
Charging system
Low brake fluid Anti\bLock Brake System (ABS)
Malfunction lamp
(check engine light)
Tire Pressure Monitoring System
(TPMS) (blinks and stays on )
Vehicle Stability Assist
®(VSA)
Parking brake on:
Release Seat belt reminder:
Fasten seat belt(s)
Starter system
Brake system
Smart Entry System
Automatic light control
Low oil pressure
Supplemental Restraint System
(SRS)
Electric Power System (EPS)
Forward Collision Warning
(FCW)
Lane Departure Warning
(LDW)
Door/Trunk open:
Close door(s) / trunk Low tire pressure:
\bdd air
Maintenance Minder
TM:
Make dealer appointmentLow fuel:
Refill
LDW (blinks):
Stay in your laneFCW (blinks):
Brake
CRUISE MAIN on
Immobilizer (blinks):
Use other vehicle key
and see dealer
Briefly appear with each engine start. Red and orange indicators are most critical. Blue
and green indicators are used for general information. See your Owner’s Manual for
more information.
14 Accord 2D TRG_EXL \ANAVI_ATG_NEW STYLE \A 7/18/2013 9\f0\b AM \APage 4

67
Accessing the Information Display
Information DisplaysI N F O R M A T I O N D I S P L A Y
Consists of several displays that provide you with useful information.
When you start the engine, the
information display shows your
last active selection from the
previous drive cycle.
To toggle between the different
displays, press and release the
select/reset knob repeatedly.
Instant fuel economy,
Odometer, Trip meter A,
Outside temperature
Oil lifeInstant fuel economy, Range,
Trip meter A, Outside
temperature
Instant fuel economy, Average
fuel economy B, Trip meter B,
Outside temperatureInstant fuel economy, Average
fuel economy A, Trip meter A,
Outside temperature
Automatic transmission shown
14 Accord 2D TRG_EXL \ANAVI_ATG_NEW STYLE \A 7/18/2013 9\f0\b AM \APage 5

\b9
3. Press ECON again to turnthe system off.
2. The ECON mode indicatorcomes on.\f. Press ECON to turn thesystem on.
ECON Button
E C O A S S I S TT M
When turned on, performance of the vehicle’s engine, transmission, cruise control, and
air conditioning system are adjusted to maximize fuel efficiency.
Ambient Meter
High fuel efficiency Moderate fuel efficiency Low fuel efficiency
Indicates real\btime fuel efficiency using color\bcoded bars.
T I R E P R E S S U R E M O N I T O R I N G S Y S T E M ( T P M S )
Monitors the vehicle’s tire pressures.
How It Works
When the tire pressure drops
significantly below recommended
levels, the low tire pressure
indicator comes on.
What to Do
\f. Visually inspect the tires for damage.
2. Use a tire air pressure gauge to check which tire(s) have low pressure.
3. Inflate the tire(s), if necessary, to the recommended pressures listed on the
label on the driver’s doorjamb.
4. Start TPMS calibration.
Any time you inflate, change, or rotate one or more of your tires, you need to
recalibrate the system.
TPMS Calibration
\f. Press SETTINGS. Use the interface dial to make and
enter selections.
2. Select Vehicle Settings.
3. Select TPMS Calibration.
4. Select Calibrate. The low tire pressure indicator blinks, and
calibration begins.
5. Press BACK to exit the menu.
14 Accord 2D TRG_EXL \ANAVI_ATG_NEW STYLE \A 7/18/2013 9\f07 AM \APage \b

1011
Door Locks
D e f a u l t L o c k S e t t i n g
The doors are preset to lock
when your vehicle reaches
about \f0 mph.
D e f a u l t U n l o c k S e t t i n g
All doors are set to unlock
when the driver’s door is
opened.
S E T T I N G S F O R Y O U R V E H I C L E
Change different settings for many features in your vehicle. See your Owner’s Manual
for detailed information on settings and options.
Adjusting Vehicle Settings
Press SETTINGS to select the
settings menu. Use the
interface dial to make and
enter selections.
Choose from the available options:
Navi Settings
Change various settings for
navigation system routing.
Camera Settings
Change camera modes.
Vehicle Settings*
TPMS calibration, meter setup,
door setup, and more.
System Settings
Adjust the display, system
language, and more. Phone Settings
Pair a phone, change call and
text/e\bmail options, and more.
Info Settings
Import wallpaper and select
clock type.
\budio Settings
Change sound options and
various settings for audio modes.
*The vehicle must be in Park (P) to access this menu.
Note: The driver’s and front passenger’s doors can be opened by pulling the inner
front door handle, regardless of the setting.
Changing Settings
Follow the steps below to change your door settings. Make sure you are using the
key you want to change the settings for (Driver \f or Driver 2) and the vehicle is in
ON mode. See your Owner’s Manual for complete setting options.
\f. Press SETTINGS. Use the interface dial to make and
enter selections.
2. Select Vehicle Settings.
3. Select Auto Door Lock or Auto Door Unlock.
4. Select from the options.
5. Press BACK to exit the menu.
A U T O D O O R L O C K S
Program how and when the vehicle doors automatically lock and unlock.
14 Accord 2D TRG_EXL \ANAVI_ATG_NEW STYLE \A 7/18/2013 9\f07 AM \APage 7

1213
D R I V I N G P O S I T I O N M E M O R Y S Y S T E M ( D P M S )
Store driver’s seat positions into memory for each corresponding keyless remote
transmitter (\f or 2).
How It Works
\f. Turn on the vehicle. Make sure the shift lever is in Park (P).3. Press SET. You will hear a beep.
2. Adjust the seat to your preferredposition. 4. Press the memory button
corresponding to the remote
(\f or 2) you are using within 5
seconds. You will hear two beeps.
Note: Once set, stored positions can be recalled by pressing one of the
memory buttons (\f or 2) on the door.
How It Works
O N E T O U C H T U R N S I G N A L
Use this quick and convenient method to signal a lane change.
• Lightly push the turn signal lever up or down for a three\bblink
sequence.
• For a continuous signal, push the lever up or down until it locks
into place.
How It Works
A U T O H E A D L I G H T S W I T H W I P E R I N T E G R A T I O N
For your convenience, your vehicle’s headlights automatically turn on when the
windshield wipers operate.
Make sure your headlights are in
the AUTO position. Turn on your windshield wipers.
The headlights also turn on.
When you turn off the windshield
wipers, the headlights turn off
shortly after.
