2014 FIAT 500L audio

unbuckled while traveling at speeds greater than 6 mph
(10 km/h), BeltAlert® will provide both audio and visual
notification.
The front passenger seat BeltAlert® is not active when
the front passenger seat is unoccupied. BeltAlert® may
be triggered when an animal or heavy object is on thefront passenger seat or when the seat is folded flat (if
equipped). It is recommended that pets be restrained in
the rear seat in pet harnesses or pet carriers that are
secured by seat belts, and cargo is properly stowed.
BeltAlert® can be enabled or disabled by your autho-
rized dealer. FIAT Group Automobiles does not recom-
mend deactivating BeltAlert®. BeltAlert® can also be
enabled through the “Electronic Vehicle Information Cen-
ter (EVIC) Setup Menu”.
NOTE:
Although BeltAlert® has been deactivated, the
Seat Belt Reminder Light will continue to illuminate
while the driver ’s or front passenger (if equipped with
BeltAlert®) seat belt remains unfastened.
Seat Belts And Pregnant Women
We recommend that pregnant women use the seat belts
throughout their pregnancy. Keeping the mother safe is
the best way to keep the baby safe.
Seat Belt Reminder Light
2
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41

While audible signals are emitted, the audio system is not
muted.
The audible signal is turned off immediately if the
distance increases. The tone cycle remains constant if the
distance measured by the inner sensors is constant. If this
condition occurs for the external sensors, the signal is
turned off after 3 seconds (stopping warnings during
maneuvers parallel to walls).
Failure Indications
A malfunction of the Rear Park Assist sensors or system
is indicated, during REVERSE gear engagement, by the
instrument panel warning icon and message displayed
on the Electronic Vehicle Information Center (EVIC)
display.The warning icon is illuminated and a message
is displayed on the EVIC display (if equipped). Refer to
Electronic Vehicle Information Center (EVIC) in
“Understanding Your Instrument Panel” for further
information.
The sensors and wiring are tested continuously when the
ignition is in the ON/RUN position. Failures are indi-
cated immediately if they occur when the system is ON.
Even if the system is able to identify that a specific sensor
is in failure condition, the EVIC shall indicate that the
Rear Park Assist system is unavailable, without reference
to the sensor in failure condition. If even a single sensor
fails, the entire system must be disabled. The system is
turned off automatically.
Cleaning The Rear Park Assist System
Clean the Rear Park Assist sensors with water, car wash
soap and a soft cloth. Do not use rough or hard cloths. In
washing stations, clean sensors quickly keeping the vapor
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........155
 INSTRUMENT CLUSTER .................156
 INSTRUMENT CLUSTER DESCRIPTIONS .....157
 ELECTRONIC VEHICLE INFORMATION
CENTER (EVIC) ...................... .168
▫ EVIC Screen ........................ .169
▫ EVIC Control Buttons ..................169
▫ Electronic Vehicle Information Center (EVIC)
Setup Menu ........................ .170
▫ Change Engine Oil Indicator System ........171▫
Trip Computer ...................... .172
▫ Trip Button ......................... .172
▫ Trip Functions ....................... .174
▫ Values Displayed ..................... .174
▫ Personal Settings (Customer-Programmable
Features) ........................... .175
 Uconnect® RADIOS .....................183
 iPod®/USB/SD CARD/MEDIA PLAYER
CONTROL .......................... .183
 STEERING WHEEL AUDIO CONTROLS ......184
4

INSTRUMENT PANEL FEATURES
1 — Side Vent7 — Fixed Upper Air Vent13 — Climate Controls
2 — Radio Controls Behind The Steering Wheel 8 — Passenger Advanced Front Air Bag 14 — USB Port/SD Card/AUX Socket
3 — Multifunction Lever – Light Control 9 — Upper Glove Compartment 15 — Uconnect® Audio System
4 — Instrument Cluster And Warning Lights 10 — Storage Compartment 16 — Ignition Switch
5 — Windshield Wiper, Washer, Trip Computer 11 — Lower Glove Compartment 17 — Driver Advanced Front Air Bag / Horn
6 — Central Air Vents 12 — Upper Switch Bank18 — Electronic Cruise Control Located
On Steering Wheel
4
UNDERSTANDING YOUR INSTRUMENT PANEL 155

STEERING WHEEL AUDIO CONTROLS
The remote sound system controls are located on the rear
surface of the steering wheel. Reach behind the wheel to
access the switches.The right-hand control is a rocker-type switch with a
pushbutton in the center and controls the volume and
mode of the sound system. Pressing the top of the rocker
switch will increase the volume, and pressing the bottom
of the rocker switch will decrease the volume.
Pressing the center button will make the radio switch
between the various modes available (AM/FM/SAT/
AUX/Media Player, etc.) and can also be used to select/
enter an item while scrolling through menu.
The left-hand control is a rocker-type switch with a
pushbutton in the center. The function of the left-hand
control is different depending on which mode you are in.
The following describes the left-hand control operation in
each mode.
Remote Sound System Controls (Back View Of Steering
Wheel)
184 UNDERSTANDING YOUR INSTRUMENT PANEL

SteeringTilt Column .......................... .120
Wheel, Tilt ........................... .120
Steering Wheel Audio Controls ...............184
Steering Wheel Mounted Sound System Controls . . .184
Storage ............................... .363
Storage, Vehicle .......................... .363
Storing Your Vehicle ...................... .363
Stuck, Freeing ........................... .313
Sun Roof .............................. .141
Sun Visor Extension ........................94
Supplemental Restraint System - Airbag ..........42
Tachometer ............................. .161
Telescoping Steering Column .................120
Temperature Gauge, Engine Coolant ............159
Tilt Steering Column ...................... .120
Tire and Loading Information Placard ...........253
TIREFIT ............................... .290Tire Markings
........................... .247
Tires...................................85 Aging (Life of Tires) .....................266
Air Pressure .......................... .258
Chains .............................. .269
Changing ............................ .301
Compact Spare ........................ .263
General Information .....................258
High Speed .......................... .260
Inflation Pressures ...................... .259
Jacking .............................. .301
Life of Tires .......................... .266
Load Capacity ........................ .253
Pressure Monitor System (TPMS) ............271
Pressure Warning Light ...................164
Quality Grading ....................... .387
Radial .............................. .261
Replacement .......................... .267
Rotation ............................. .270
10
INDEX 403
