2014 FIAT 500L Owners Manual

2. Fold the seatback forward.3. Locate the seatback recline lever on the outboard side
of the seat and lift upward on the lever.
Seatback Folded
Seatback Recline Lever
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103

4. Slowly flip the entire seat forward.
5. Slowly flip the entire seat rearward and firmly lock theseat into position.
6. Raise the rear seatback and firmly lock the seatback into position.Rear Armrest — If equipped
To use the armrest, lower it downward.
Folding Rear Seat
Folding Rear Seat Armrest
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

HEAD RESTRAINTS
Head restraints are designed to reduce the risk of injury
by restricting head movement in the event of a rear-
impact. Head restraints should be adjusted so that the top
of the head restraint is located above the top of your ear.
WARNING!
The head restraints for all occupants must be prop-
erly adjusted prior to operating the vehicle or occu-
pying a seat. Head restraints should never be ad-
justed while the vehicle is in motion. Driving a
vehicle with the head restraints improperly adjusted
or removed could cause serious injury or death in the
event of a collision.
Armrest Cupholder
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105

Front Head Restraints
To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, press the adjust-
ment button, located on the base of the head restraint,
and push downward on the head restraint.
Rear Head Restraints — If Equipped
The rear seats are equipped with adjustable head re-
straints, the outboard head restraints have two adjustable
positions and the center head restraint can be stowed
when the seat is not in use. When the center seat is being
occupied the head restraint should be in the raised
position which can be done by pulling upward on the
head restraint.
To raise the head restraints, pull upward on the head
restraint. To lower the head restraints, press the push
button, located at the base of the head restraint, and push
downward on the head restraint.
Adjustment Button
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
The head restraints for all occupants must be prop-
erly adjusted before operating the vehicle or occupy-
ing a seat. Head restraints should never be adjusted
while the vehicle is in motion. Driving a vehicle with
the head restraints improperly adjusted or removed
could cause serious injury or death in the event of an
accident.
Push Buttons
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107

OPENING AND CLOSING THE HOOD
To open the hood, two latches must be released to open
the hood.
1. Pull the hood release lever located under the left sideof the instrument panel. 2. Move to the outside of the vehicle and push the red
safety catch lever to the left and raise the hood. The
safety catch lever is located under the center front
edge of the hood.
Hood Release Lever
Safety Catch Lever
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!
To prevent possible damage, do not slam the hood to
close it. Lower the hood until it is open approxi-
mately 6 in (15 cm), and then drop it. This should
secure both latches. Never drive your vehicle unless
the hood is fully closed, with both latches engaged.
WARNING!
Be sure the hood is fully latched before driving your
vehicle. If the hood is not fully latched, it could open
when the vehicle is in motion and block your vision.
Failure to follow this warning could result in serious
injury or death.
LIGHTS
Multifunction Lever
The multifunction lever, located on the left side of the
steering wheel, controls the operation of the headlights,
headlight beam selection, passing light and turn signals.
NOTE:The external lights can only be turned on with
the ignition in the ON/RUN position.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109

Headlights
Rotate the end of the multifunction lever up-
ward to the first detent for headlight operation.NOTE:
When the headlights are turned on, the Daytime
Running Lights will be deactivated.
Multifunction LeverHeadlight Operation
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
