Make sure the directional arrows on the crossbars align
with the directional arrows on the side rails. Set the
crossbars into the deployed positions.
Once the crossbars are set into position, tighten the
thumb screws completely.
Stowing The Crossbars
Reverse the procedure to stow the crossbars, again,
taking care to keep hand clear of pivoting joint. Crossbars
are identical and can be stowed in either rail nest. Once
the crossbars are stowed, tighten the thumb screws
completely.Crossbar To Side Rail Installation
Tightening Crossbar
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 303

NOTE:Load should always be secured to crossbars first,
with rail tie down loops used as additional securing
points if needed. Tie loops are intended as supplemen-
tary tie down points only. Do not use ratcheting mecha-
nisms with the tie loops.CAUTION!
• Check deployed crossbars frequently and retighten
thumb screws as necessary.
• To avoid damage to the roof rack and vehicle, do
not exceed the maximum roof rack load capacity of
150 lb (68 kg). Always distribute heavy loads as
evenly as possible and secure the load appropri-
ately.
• To prevent damage to the roof of your vehicle, DO
NOT carry any loads on the roof rack without the
crossbars deployed.
• The load should be secured and placed on top of
the crossbars, not directly on the roof. If it is
necessary to place the load on the roof, place a
blanket or other protective layer between the load
and the roof surface.
(Continued)
Rail Tie Loops
304 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CAUTION!(Continued)
•Long loads which extend over the windshield, such
as wood panels or surfboards, or loads with large
frontal area should be secured to both the front and
rear of the vehicle.
• Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof
rack. Wind forces, due to natural causes or nearby
truck traffic, can add sudden upward lift to a load.
This is especially true on large flat loads and may
result in damage to the cargo or your vehicle.
WARNING!
Cargo must be securely tied before driving your
vehicle. Improperly secured loads can fly off the
vehicle, particularly at high speeds, resulting in per-
sonal injury or property damage. Follow the roof rack
cautions when carrying cargo on your roof rack.
SUN SCREENS — IF EQUIPPED
Sun screens are available for second and third row
seating windows. The screens store in the sill trim panels,
and the tops of the windows are equipped with hooks
that the sun screens attach to when pulled out.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 305

Gently pull up on the tab to raise the sun screen.
Continue pulling the sun screen until the tab is near the
top of the window.
Once the screen is completely to the top of the window,
extend the top bar of the sun screen over the two hooks
attached to the top of the window.To lower the sun screen, gently lift the tab upward to
disengage the hooks, and feed the screen back into the
base sill.
Sun Screen RetractedSun Screen Extended
306 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ..........311
 INSTRUMENT CLUSTER — BASE ..........312
 INSTRUMENT CLUSTER — PREMIUM .......313
 INSTRUMENT CLUSTER DESCRIPTIONS .....314
 ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC) — IF EQUIPPED ..................328
▫ Electronic Vehicle Information Center (EVIC)
Displays............................330
▫ EVIC White Telltale Lights ...............333
▫ EVIC Amber Telltale Lights ..............334▫
EVIC Red Telltale Lights ................334
▫ Oil Change Required ...................337
▫ Fuel Economy ........................338
▫ Vehicle Speed ........................339
▫ Trip Info ...........................339
▫ Units ..............................340
▫ Vehicle Info (Customer Information Features) . .340
▫ Messages # ..........................341
▫ Compass/Temperature Display ...........341
4

▫Customer-Programmable Features
(System Setup) .......................343
 Uconnect® 730N/430/430N CD/DVD/HDD/NAV
— IF EQUIPPED .......................349
▫ Operating Instructions (Voice Command System)
— If Equipped .......................349
▫ Operating Instructions (Uconnect® Phone) — If
Equipped ...........................349
 Uconnect® 130 ........................350
▫ Operating Instructions — Radio Mode ......350
▫ Operation Instructions — CD MODE For CD And
MP3 Audio Play ......................353
▫ Notes On Playing MP3 Files .............355
▫ Operation Instructions — Auxiliary Mode ....358
 Uconnect® 130 WITH SATELLITE RADIO .....359▫
Operating Instructions — Radio Mode .......360
▫ Operation Instructions — CD MODE For CD
And MP3 Audio Play ...................366
▫ NotesOnPlayingMP3Files .............368
▫ LIST Button — CD Mode For MP3 Play ......371
▫ INFO Button — CD Mode For MP3 Play .....371
▫ Uconnect® (Satellite Radio) — If Equipped . . .372
▫ Operating Instructions (Uconnect® Phone) —
If Equipped ..........................376

iPod®/USB/MP3 CONTROL — IF EQUIPPED . .376
▫ Connecting The iPod® Or External USB
Device .............................377
▫ Using This Feature .....................378
308 UNDERSTANDING YOUR INSTRUMENT PANEL

▫Controlling The iPod® Or External USB Device
Using Radio Buttons ...................378
▫ PlayMode ..........................379
▫ List Or Browse Mode ...................380
▫ Bluetooth® Streaming Audio (BTSA) .......382
 Uconnect® MULTIMEDIA — VIDEO
ENTERTAINMENT SYSTEM (VES™) — IF
EQUIPPED ...........................383
▫ Getting Started .......................384
▫ Blu-ray™ Disc Player ...................385
▫ Play Video Games .....................386
▫ Listen To An Audio Source On Channel 2 While A
Video Is Playing On Channel 1 ............389
▫ Dual Video Screen .....................390 ▫
Play A DVD Using The Touchscreen Radio . . .390
▫ Play A DVD Using The VES™ Player — If
Equipped ...........................393
▫ Play A Blu-ray™ Disc Using The Blu-ray™ Player
— If Equipped .......................396
▫ Listen To An Audio Source While A Video Is
Playing.............................398
▫ Important Notes For Dual Video Screen
System .............................400
▫ VES™ Remote Control — If Equipped .......401
▫ Blu-ray™ Player Remote Control — If
Equipped ...........................404
▫ Remote Control Storage .................406
▫ Locking The Remote Control .............407
▫ Replacing The Remote Control Batteries ......407
4
UNDERSTANDING YOUR INSTRUMENT PANEL 309

▫Headphones Operation .................407
▫ Blu-ray™ Headphones Operation ..........408
▫ Controls ............................409
▫ Replacing The Headphone Batteries .........410
▫ Unwired® Stereo Headphone Lifetime Limited
Warranty ............................411
▫ System Information ....................412
 STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED ...........................431
▫ Radio Operation ......................432
▫ CD Player ...........................432
 CD/DVD/Blu-ray™ Disc MAINTENANCE ....433
 RADIO OPERATION AND MOBILE PHONES . .433
CLIMATE CONTROLS ...................434
▫ Manual Heating And Air Conditioning System —
If Equipped .........................434
▫
Rear Manual Climate Control — If Equipped . .439
▫ Automatic Temperature Control (ATC) — If
Equipped ...........................442
▫ Summer Operation ....................452
▫ Winter Operation ......................452
▫ Vacation/Storage .....................452
▫ Window Fogging .....................453
▫ Outside Air Intake .....................453
▫ A/CAirFilter .......................453
▫ Operating Tips Chart ...................454
310 UNDERSTANDING YOUR INSTRUMENT PANEL
