2014 DODGE AVENGER clock

Uconnect® 130
NOTE:
• Your radio has many features that add to the comfort and convenience for you and yourpassengers.
• Some of these radio features should not be used when driving because they take your eyes from the road or your attention from driving.
Clock Setting
1. Press and hold the TIME button until the hours blink.
2. Turn the TUNE/SCROLL control knob to set the hours.
3. Press the TUNE/SCROLL control knob until the minutes begin to blink.
4. Turn the TUNE/SCROLL control knob to set the minutes.
5. Press the TUNE/SCROLL control knob to save the changes.
6. Press any button/knob or wait five seconds to exit.
ELECTRONICS
32

Uconnect® 130 WITH SiriusXM SATELLITE RADIO
NOTE:
• Your radio may not be equipped with the Uconnect® Voice Command and Uconnect®Phone features. To determine if your radio has these features, press the Voice Command
button on the radio. You will hear a voice prompt if you have the feature, or see a message
on the radio stating “Uconnect Phone not available” if you do not.
• Your radio has many features that add to the comfort and convenience of you and your passengers. Some of these radio features should not be used when driving because they
take your eyes from the road or your attention from driving.
Clock Setting
1. Press and hold the TIME button until the hours blink.
2. Turn the TUNE/SCROLL control knob to set the hours.
3. Press the TUNE/SCROLL control knob until the minutes begin to blink.
4. Turn the TUNE/SCROLL control knob to set the minutes.
5. Press the TUNE/SCROLL control knob to save the changes.
6. Press any button/knob or wait five seconds to exit.
ELECTRONICS
34

Uconnect® 430/430N
NOTE:
• Your radio may not be equipped with the Uconnect® Voice Command and Uconnect®Phone features. To determine if your radio has these features, press the Voice Command
button on the radio. You will hear a voice prompt if you have the feature, or see a message
on the radio stating “Uconnect Phone not available” if you do not.
• Your radio has many features that add to the comfort and convenience of you and your passengers. Some of these radio features should not be used when driving because they
take your eyes from the road or your attention from driving.
Clock Setting
1. Turn the radio on, then touch the screen where the time is displayed.
2. Touch the “User Clock” soft-key (Navigation radio only).
3. To adjust the hours, touch either the “Hour Forward” or “Hour Backward” soft-key.
4. To adjust the minutes, touch either the “Minute Forward” or “Minute Backward” soft-key.
5. To save the new time setting, touch the screen where the word “Save” is displayed.
ELECTRONICS
37

Uconnect® 730N
NOTE:
Your radio has many features that add to the comfort and convenience of you and your
passengers. Some of these radio features should not be used when driving because they
take your eyes from the road or your attention from driving.
Clock Setting
1. Turn the radio on, then touch the screen where the time is displayed.
2. Touch the “User Clock” soft-key.
3. To adjust the hours, touch either the “Hour Forward” or “Hour Backward” soft-key.
4. To adjust the minutes, touch either the “Minute Forward” or “Minute Backward” soft-key.
5. To save the new time setting, touch the screen where the word “Save” is displayed.
Menu
• Press the MENU hard-key to access the System Setup menu and the My Files menu.
• Press the MENU hard-key in an active mode (SAT, CD, AUX, etc.) to change mode specificsettings.
ELECTRONICS
46

3. Align the valve notch in the wheel cover with the valve stem on the wheel. Install thecover by hand, snapping the cover over the two lug nuts. Do not use a hammer or
excessive force to install the cover.
4. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the lug nuts.
5. Lower the vehicle to the ground by turning the jack handle counterclockwise.
6. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for increased leverage. Tighten the lug nuts in a star pattern until each nut has been
tightened twice. The correct tightness of each lug nut is 100 ft/lbs (135 N·m). If in doubt
about the correct tightness, have them checked with a torque wrench by your authorized
dealer or service station.
7. After 25 miles (40 km) check the lug nut torque with a torque wrench to ensure that all lug nuts are properly seated against the wheel.
Vehicles Without Wheel Covers
1. Mount the road tire on the axle.
2. Install the remaining lug nuts with the cone shaped end of the nut toward the wheel. Lightly tighten the lug nuts.
3. Lower the vehicle to the ground by turning the jack handle counterclockwise.
4. Finish tightening the lug nuts. Push down on the wrench while at the end of the handle for increased leverage. Tighten the lug nuts in a star pattern until each nut has been
tightened twice. The correct tightness of each lug nut is 100 ft/lbs (135 N·m). If in doubt
about the correct tightness, have them checked with a torque wrench by your authorized
dealer or service station.
5. After 25 miles (40 km) check the lug nut torque with a torque wrench to ensure that all lug nuts are properly seated against the wheel.
CAUTION!
• Do not attempt to raise the vehicle by jacking on locations other than those indicated in the Jacking Instructions for this vehicle.
• Be sure to mount the spare tire with the valve stem facing outward. The vehicle could
be damaged if the spare tire is mounted incorrectly.
WHAT TO DO IN EMERGENCIES
85

FUSES
Integrated Power Module (fuses)
• The Integrated Power Module (fuses) is located in the engine compartment near the aircleaner assembly. This center contains cartridge fuses and mini fuses.
Cavity Cartridge Fuse Mini Fuse Description
1 40 Amp Green — Power Top Module – If Equipped
2 — 20 Amp Yellow Brake Vacuum Pump
3 —10 Amp Red Center High Mounted Stop Light
(CHMSL)/Brake Switch
4 —10 Amp Red Ignition Switch
5 — 20 Amp Yellow Trailer Tow – If Equipped
6 —10 Amp Red Power Mirror Switch/Climate Controls
7 — 30 Amp Green Ignition Off Draw (IOD) Sense 1
8 — 30 Amp Green Ignition Off Draw (IOD) Sense 2
9 40 Amp Green Battery Feed – Power Seats – If Equipped
10 — 20 Amp Yellow Instrument Panel/Power Locks/Interior
Lights
11 — 15 Amp Lt Blue Selectable Power Outlet (Inside Center
Arm Rest)
12 — 20 Amp Yellow Spare
13 — 20 Amp Yellow Ignition/Cigar Lighter
14 —10 Amp Red Instrument Panel
15 40 Amp Green — Radiator Fan Relay 16 — 15 Amp Lt. Blue Sunroof – If Equipped
17 —10 Amp Red Wireless Control Module (WCM)/Clock/
Steering Control Module (SCM)
MAINTAINING YOUR VEHICLE
104

Airbag...................11
Airbag Light...............80
Air Conditioning .............26
Air Recirculation .............26
Alarm,Panic................8
Alarm (Security Alarm) ..........10
Anti-Lock Warning Light .........79
Arming System (Security Alarm) .....10
Audio Jack ............33,36,41
Audio Settings ............33,35
Audio Systems (Radio) ..........32
Automatic Headlights ..........20
Automatic Temperature Control (ATC). . .26
Automatic Transmission Fluid Type ...............97
AxleFluid.................97
Battery Location ...............87
Belts, Seat .................11
BrakeFluid................97
Brake System Master Cylinder ...........98
Break-In Recommendations, New Vehicle .................20
Calibration, Compass ...........69
CD (Compact Disc) Player ......33,36
Change Oil Indicator ...........80
Changing A Flat Tire ...........81
Charging System Light ..........78
Child Restraint ..............12
ChildSeat.................14
ClimateControl..............25
Clock Setting ...........32,34,37
Compass Calibration ...........69
Cooling System Coolant Capacity ...........97
Cruise Control (Speed Control) ......23
Cruise Light ................23
Customer Assistance ..........108
Deck Lid, Emergency Release ......10
Deck Lid, Power Release ..........9
Defects, Reporting ............109
Dimmer Control ..............21
Dimmer Switch, Headlight ........21
Disarming, Security System .......10DoorLocks.................8
Electronics
Your Vehicle's Sound System . . .30, 31
Electronic Speed Control (Cruise Control) ............23
Electronic Stability Control (ESC) .....76
Electronic Stability Control (ESC) OFF Indicator ................76
Electronic Throttle Control Warning Light ..................79
Electronic Vehicle Information Center (EVIC)...............68,69
Emergency Deck Lid Release .......10
Emergency, In Case of Brake Warning Light .........78
Jacking ................81
Jump Starting ............87
Overheating .............80
Emergency Trunk Release ........10
Engine Break-In Recommendations .....20
Compartment ............95
Coolant (Antifreeze) .........97
Jump Starting ............87
Oil...................97
Oil Filter ................97
Oil Selection .............97
Overheating .............80
Temperature Warning Light .....78
EventDataRecorder...........93
FAQ....................114
Flash-To-Pass ...............21
Fluid, Brake ................
98
Fluid Capacities ..............97
Fluids ...................97
FogLights...............20,21
Folding Rear Seat .............18
Freeing A Stuck Vehicle .........92
Frequently Asked Questions .......114
Front Heated Seats ............18
Fuel Filler Cap (Gas Cap) .........80
Gasoline ...............97
Specifications ............97
Garage Door Opener (HomeLink®) ....70
INDEX
111

FAQ’s
GETTING STARTED
• How do I install my LATCH Equipped Child Seat? pg. 12
• How do I fold down my rear seat? pg. 18
ELECTRONICS
• Which radio is in my vehicle?• Uconnect® 130 pg. 32
• Uconnect® 130 WITH SiriusXM pg. 34
• Uconnect® 430/430N pg. 37
• Uconnect® 730N pg. 46
• How do I activate the Audio Jack?
• Uconnect® 130 pg. 36
• Uconnect® 130 WITH SiriusXM pg. 36
• Uconnect® 430/430N pg. 41
• Uconnect® 730N pg. 50
• How do I set the clock on my radio?
• Uconnect® 130 pg. 34
• Uconnect® 130 WITH SiriusXM pg. 34
• Uconnect® 430/430N pg. 37
• Uconnect® 730N pg. 46
• How do I use the Navigation feature?
• Uconnect® 430/430N pg. 43
• Uconnect® 730N pg. 53
• How do I pair my cell phone via Bluetooth® with the Uconnect® Hands-Free Voice Activation System? pg. 63
• How do I use my iPod®? pg. 61
• How do I use my USB port to listen to audio through my touch-screen radio? pg. 61
• How do I configure my Universal Garage Door Opener ((HomeLink®)? pg. 70
FREQUENTLY ASKED QUESTIONS
114
