2014 Citroen C4 AIRCROSS RHD display

275
Level 1
Level 2
Level 3

Comments



RDS Settings AF Check
The name of the station is displayed while RDS data is received. If the
name is not transmitted, the frequency is displayed.
Reg
List of stations To display in the screen the list of stations received. PTY (programme
type) is displayed if the RDS data received is displayed, to display
in the screen programmes by type, e.g.: sport, rock, classical,
information, ... Press PTY again to quit.
Scan To search for stations that can be received in the current location,
until a station is found.
TP Standby Activate or deactivate traffi c announcements.

278
05

What is RDS?

The Radio Data System (RDS) function on the FM waveband permits:


- automatic retuning to alternative frequencies carrying the same
station while travelling through different regions (if the transmitters
of this station cover the area through which you are travelling),

- temporary tuning to traffi c information announcements,

- display of the name of the station, etc...

Most FM stations use RDS.
These stations transmit non-audible data in addition to their programmes.
The data transmitted in this way allows you access to various functions,
mainly displaying of the name of the station, temporary tuning to
traffi c information announcements or automatic retuning to alternative
frequencies.
RDS allows you to continue listening to the same station automatically by
means of alternative frequencies. However, alternative frequencies may not
be provided throughout the country. Radio stations do not cover the whole
country, which explains the loss of reception of the station during a journey.










RDS, AF, TP, PTY


RDS alternative frequencies


Your radio automatically checks and selects the best frequency for the radio station
to which it is tuned (if the station broadcasts on several transmitters or frequencies).
The frequency of a radio station covers approximately 30 miles (50 km). The
change from one frequency to another explains the loss of reception during a
journey.
If the station to which you are listening does not have several frequencies in the
region in which you are currently located, you can deactivate automatic alternative
frequencies.


Traffi c information function

The Traffic Programme (TP) function permits automatic and
temporary switching to an FM station broadcasting traffi c
information.
The radio station or the source that you are listening to at this point
is placed on hold.
Once the traffi c information has ended, the system switches back to
the radio station or the source that you were listening to initially.

Programme types

Some stations offer the option of listening to a themed type of
programme as a priority, selected from the list available below:
NEWS, AFFAIRS, INFOS, SPORT, EDUCATE, DRAMA, CULTURE,
SCIENCE, VARIED, POP M, ROCK M, EASY M, LIGHT M,
CLASSICS, OTHER M, WEATHER, FINANCE, CHILDREN,
SOCIAL, RELIGION, PHONE IN, TRAVEL, LEISURE, JAZZ,
COUNTRY, NATION M, OLDIES, FOLK M, DOCUMENT.


RADIO

279
05

Press the AUDIO
button.
By default the screen displays the stations on FM1.


Selecting an FM station and presetting


Press SEEK TRACK
for a manual search up or
down. The frequency is modifi ed in step of 0.1 MHz.
Press and hold to fi nd a station automatically.
Press " Scan
" to search for stations that can be
received in the current location, until a station is
found.

You can also start a search by type of programme by
pressing " PTY Filter
".
Press " RDS Settings
".

Press " On
" or " Off
" to activate or deactivate the
functions:


- " AF Check
": automatic search for the best
frequency,

- " Reg
": switch to the regional frequencies.



Once the frequency has been selected, a long press
on the station until a "Beep" is heard will preset it.
The name of the station is displayed if it is available.



RDS settings


Press the AUDIO
button.
By default the screen displays the stations on FM1.

Turn the FOLDER / TUNE SOUND
knob to select a
station.

RADIO

280
05

Playing an MP3/WMA CD

When the MP3/WMA CD is inserted in the player,
playing of the tracks is automatic.
The tracks cannot be recorded onto the music server.

You can play CDs with up to 8 levels, 255 folders and
400 fi les maximum. Windows Media and Microsoft Corporation are trademarks
registered in the United States and/or other countries.













General notes on MP3/WMA CDs


What is the MP3/WMA fi le format?

MP3 is the abbreviation of MPEG-1 Audio Layer 3 and MPG is the
abbreviation of Motion Pictures Experts Group, a digital video data
compression standard used on media such as video CDs.
The MP3 compression reduces the number of bytes in a song by
eliminating the long sound waves in the range of frequencies which
are imperceptible to the human ear, so producing high quality audio
fi les with a low volume of data.
This compression divides the size of the content of a conventional
audio CD by approximately 10, which means that the content of
10 audio CDs can be recorded onto a single CD-R or CD-RW.
WMA is the abbreviation of Windows Media Audio, another audio
data compression standard offered by Microsoft.
It can be used to create and save audio fi les at a compression rate
higher than that of the MP3 format.
Acceptance of the fi les

Some blank CDs may not be played by your equipment (quality,
recording speed...).
When you burn a CD-R or CD-RW, select the ISO 9660 level 1.2 or
Joliet burning standard.
To obtain the best acoustic quality possible, select the lowest
burning speed.
The MPEG1 and MPEG2 standards are accepted.
Transmission speeds between 32 and 320 kbits/s and scans
between 16 kHz and 48 kHz are accepted.
To display the title information (the name of the artist, the title of the
album, etc...), the information contained in the ID3 Tags or the WMA
Tags must be included in the MP3/WMA fi les burned onto the disc.

Copyright

Your audio system may allow you to listen to music which is usually
protected by copyright in accordance with current national and
international standards. Please consult these standards and comply
with them.


MUSIC

281
05

Press the MODE button then " CD
", if the player
already contains a CD.
Otherwise, insert a CD in the player, play begins
automatically.


Playing an MP3/WMA CD


You can move by one level at a time.
Press on the name of a folder and at each press the
list of folders of the level below is displayed.

Press these buttons for fast forward or back in the
current track.
Press on " Go Up 1 Level
" to move up a level and/or
select a level.

Press these buttons to select the next or previous
track or return to the beginning of the track currently
being played.

Press " Random
" to play all of the tracks in the
selected folder in random order.
Press " Random
" again to play all of the tracks on the
CD in random order.
Press again to stop.

Press on " Go to ROOT
" to go up to the root level.
Press " Scan
" to play the beginning of each track in
each folder for approximately 10 seconds (scanning).
Press " Scan
" again the play the beginning of each
track in the selected folder in a loop.
Press again to stop or press on the current track
(during the 10 seconds) and play begins.
Press " Repeat
" to play the selected track repeatedly
in a loop.
Press " Repeat
" again to play all of the tracks in the
selected folder repeatedly in a loop.
Press again to stop.
Press this button for access to the secondary menu.

MUSIC

284
05





















USB player - Playing a track


Press the MODE
button then on " USB/iPod
"; you
can display the sort by category at any time by
pressing " Playlist
".

In USB or AUX mode you can move up a level at the
same time.
Press on the name of a folder and at each press the
list of folders in the level below is displayed.

Press these buttons for fast forward or back in the
current track.
Press " Go Up 1 Level
" to go up one level and/or
select a level.

Press these buttons to select the next or previous
track or return to the beginning of the track currently
being played.

Press " Random
" to play all of the tracks in the
selected folder in random order.
Press " Random
" again to play all of the tracks in
random order.
Press again to stop.

Press " Go to ROOT
" to go up to the root level.
Press " Scan
" to play the beginning of each track in
each folder for approximately 10 seconds (scanning).
Press " Scan
" again to play the beginning of each
track in the selected folder in a loop.
Press again to stop or press on the current track
(during the 10 seconds) and play begins.
Press " Repeat
" to play the selected track repeatedly
in a loop.
Press " Repeat
" again to play all of the tracks in the
selected folder repeatedly in a loop.
Press again to stop.
Press this button for access to the secondary menu.

MUSIC

287

Level 1


Level 2


Level 3


Comments



Display Off Choose to switch off the screen.
To switch it back on, touch the screen or press any button.
System Time Choose adjustment of the time by the RDS signal, time zone, summer
time.
Language Select the language (English, Français, Deutsch, Nederlands, Português,
Español, Svenska, Italiano, Dansk, Vlaams, Polski, Norsk).
Pairing Select an authorisation "Select Device to Connect", "Register Device",
"Set Passkey: Fixed", "Set Passcode".
Units Select the units for the calculation of distances (km or miles and °C
or °F).
Keyboard Layout Select the type of input keyboard (alphabet or PC).
Reset all Restore factory settings.
After reinitialisation, restart the system.
TP Standby Select the traffi c information (TP) setting: on or off.
Picture Control Brightness
Adjust the image settings for: brightness, contrast, black level.
Contrast
Black Level
Clock Screen

291

Level 1


Level 2


Level 3


Comments



Map Reg. Code Display the registration code for the navigation system.
Mobile Phone Make and receive telephone calls.
Version Info. View the software version and mapping data version.
