2014 Citroen C4 AIRCROSS RHD Owner's Manual

279
05

Press the AUDIO
button.
By default the screen displays the stations on FM1.


Selecting an FM station and presetting


Press SEEK TRACK
for a manual search up or
down. The frequency is modifi ed in step of 0.1 MHz.
Press and hold to fi nd a station automatically.
Press " Scan
" to search for stations that can be
received in the current location, until a station is
found.

You can also start a search by type of programme by
pressing " PTY Filter
".
Press " RDS Settings
".

Press " On
" or " Off
" to activate or deactivate the
functions:


- " AF Check
": automatic search for the best
frequency,

- " Reg
": switch to the regional frequencies.



Once the frequency has been selected, a long press
on the station until a "Beep" is heard will preset it.
The name of the station is displayed if it is available.



RDS settings


Press the AUDIO
button.
By default the screen displays the stations on FM1.

Turn the FOLDER / TUNE SOUND
knob to select a
station.

RADIO

280
05

Playing an MP3/WMA CD

When the MP3/WMA CD is inserted in the player,
playing of the tracks is automatic.
The tracks cannot be recorded onto the music server.

You can play CDs with up to 8 levels, 255 folders and
400 fi les maximum. Windows Media and Microsoft Corporation are trademarks
registered in the United States and/or other countries.













General notes on MP3/WMA CDs


What is the MP3/WMA fi le format?

MP3 is the abbreviation of MPEG-1 Audio Layer 3 and MPG is the
abbreviation of Motion Pictures Experts Group, a digital video data
compression standard used on media such as video CDs.
The MP3 compression reduces the number of bytes in a song by
eliminating the long sound waves in the range of frequencies which
are imperceptible to the human ear, so producing high quality audio
fi les with a low volume of data.
This compression divides the size of the content of a conventional
audio CD by approximately 10, which means that the content of
10 audio CDs can be recorded onto a single CD-R or CD-RW.
WMA is the abbreviation of Windows Media Audio, another audio
data compression standard offered by Microsoft.
It can be used to create and save audio fi les at a compression rate
higher than that of the MP3 format.
Acceptance of the fi les

Some blank CDs may not be played by your equipment (quality,
recording speed...).
When you burn a CD-R or CD-RW, select the ISO 9660 level 1.2 or
Joliet burning standard.
To obtain the best acoustic quality possible, select the lowest
burning speed.
The MPEG1 and MPEG2 standards are accepted.
Transmission speeds between 32 and 320 kbits/s and scans
between 16 kHz and 48 kHz are accepted.
To display the title information (the name of the artist, the title of the
album, etc...), the information contained in the ID3 Tags or the WMA
Tags must be included in the MP3/WMA fi les burned onto the disc.

Copyright

Your audio system may allow you to listen to music which is usually
protected by copyright in accordance with current national and
international standards. Please consult these standards and comply
with them.


MUSIC

281
05

Press the MODE button then " CD
", if the player
already contains a CD.
Otherwise, insert a CD in the player, play begins
automatically.


Playing an MP3/WMA CD


You can move by one level at a time.
Press on the name of a folder and at each press the
list of folders of the level below is displayed.

Press these buttons for fast forward or back in the
current track.
Press on " Go Up 1 Level
" to move up a level and/or
select a level.

Press these buttons to select the next or previous
track or return to the beginning of the track currently
being played.

Press " Random
" to play all of the tracks in the
selected folder in random order.
Press " Random
" again to play all of the tracks on the
CD in random order.
Press again to stop.

Press on " Go to ROOT
" to go up to the root level.
Press " Scan
" to play the beginning of each track in
each folder for approximately 10 seconds (scanning).
Press " Scan
" again the play the beginning of each
track in the selected folder in a loop.
Press again to stop or press on the current track
(during the 10 seconds) and play begins.
Press " Repeat
" to play the selected track repeatedly
in a loop.
Press " Repeat
" again to play all of the tracks in the
selected folder repeatedly in a loop.
Press again to stop.
Press this button for access to the secondary menu.

MUSIC

282
05





















Using the USB port


With the vehicle stationary, ignition
switch in the LOCK
position, connect a
suitable cable to the portable player.
The USB port is used to connect a portable device (MP3 player,
Apple
® player, ...). The fi les are sent from the player to your audio
system and heard through the vehicle's speakers.

Then connect the cable to the vehicle's
USB port.
Models supported:
- iPod touch ® : FW version 1.1.1 or later.
- iPod classic ® : FW version 1.0 or later.
- iPod 5 th generation ®
: FW version 1.2.2 or later.
- iPod nano 5 th generation ®
: FW version 1.2 or later.
- iPod nano 2 nd generation ®
: FW version 1.1.2 or later.
- Compatible USB mass storage device: 256 Mb capacity or greater.

File formats: MP3, WMA, AAC, WAV.
Maximum number of levels (including root): 8.
Number of folders: 700.
Number of fi les: 65 535.

Do not connect the portable device directly to the USB port, use a
cable.
To disconnect the cable, the ignition switch must be in the LOCK

position.
Navigation in the fi le base is done via the portable device / iPod
®
.
Take care not to trap the cable when closing the armrest.


MUSIC

283
05

Connecting APPLE ®
players


Connect the Apple ®
player to the USB port using a suitable cable
(not supplied).
Play starts automatically.

Control is via the audio system.

The classifi cations available are those of the portable device
connected (artists / albums / genres / playlists / audiobooks /
podcasts).
The default classifi cation used is by artist. To modify the classifi cation
used, return to the fi rst level of the menu then select the desired
classifi cation (playlists for example) and confi rm to go down through
the menu to the desired track.
The "Shuffl e tracks" mode on an iPod
®
corresponds to the "Random"
mode on the audio system.
The "Shuffl e albums" mode on an iPod
®
corresponds to the "Random
all" on the audio system.
"Shuffl e tracks" is restored by default on each connection.

The version of software in the audio system may not be compatible
with the generation of your Apple
® player.


MUSIC

284
05





















USB player - Playing a track


Press the MODE
button then on " USB/iPod
"; you
can display the sort by category at any time by
pressing " Playlist
".

In USB or AUX mode you can move up a level at the
same time.
Press on the name of a folder and at each press the
list of folders in the level below is displayed.

Press these buttons for fast forward or back in the
current track.
Press " Go Up 1 Level
" to go up one level and/or
select a level.

Press these buttons to select the next or previous
track or return to the beginning of the track currently
being played.

Press " Random
" to play all of the tracks in the
selected folder in random order.
Press " Random
" again to play all of the tracks in
random order.
Press again to stop.

Press " Go to ROOT
" to go up to the root level.
Press " Scan
" to play the beginning of each track in
each folder for approximately 10 seconds (scanning).
Press " Scan
" again to play the beginning of each
track in the selected folder in a loop.
Press again to stop or press on the current track
(during the 10 seconds) and play begins.
Press " Repeat
" to play the selected track repeatedly
in a loop.
Press " Repeat
" again to play all of the tracks in the
selected folder repeatedly in a loop.
Press again to stop.
Press this button for access to the secondary menu.

MUSIC

286
06 SETTINGS


Level 1


Level 2


Level 3
