216
Checks
When the symbol begins to flash
rapidly
(approximately twice per
second), there is not much fuel
remaining in your tank (approximately
5 litres).
You must fill the tank to avoid running
out of fuel.
Fuel tank
Capacity of the tank: approximately 60 litres.
Low fuel level
Filling
A label, affixed on the inside of the flap,
reminds you of the type of fuel to be used
according to your engine.
More than 5 litres of fuel must be added in
order to be registered by the fuel gauge.
Location of the cap
When the low fuel level is reached,
this indication appears in the
instrument panel screen. When it first
comes on, you have approximately
10 litres of fuel remaining.
1.
Opening the filler flap.
2.
Removing the filler cap.
3.
Hooking the filler cap.
To fill the tank safely:
)
the engine must be switched off,
)
pull the control A
located at the bottom left
of the driver's seat to release the fuel filler
flap,
)
open the fuel filler flap B
,
)
turn the filler cap C
to the left,
)
remove the filler cap C
,
)
fill the tank, but do not continue after
the 3
rd cut- off of the nozzle
; this could
cause malfunctions.
When you have filled the tank:
)
refit the filler cap, inserting the upper part
first,
)
screw in the filler cap to the right,
)
close the flap.
Ensure that the fuel filler flap is closed
correctly. This symbol indicates that the fuel
tank cap is located on the left-hand
side of the vehicle.
Opening the cap may cause an inrush of air.
This vacuum, which is completely normal, is
caused by the sealing of the fuel system. The symbol flashes slowly
(approximately
once per second).
Page 219 of 368
217
8
Checks
Quality of the fuel used for
petrol engines
The petrol engines are per fectly compatible
with E10 or E24 type petrol biofuels
(containing 10 % or 24 % ethanol), conforming
to European standards EN 228 and EN 15376.
E85 type fuels (containing up to 85 % ethanol)
are reserved exclusively for vehicles marketed
for the use of this type of fuel (BioFlex
vehicles). The quality of the ethanol must
comply with European standard EN 15293.
For Brazil only, special vehicles are marketed
to run on fuels containing up to 100 % ethanol
(E100 type).
Quality of the fuel used for
Diesel engines
The Diesel engines are per fectly compatible
with biofuels which conform to current and
future European standards (Diesel fuel
which complies with standard EN 590 mixed
with a biofuel which complies with standard
EN 14214) available at the pumps (containing
up to 7 % Fatty Acid Methyl Ester).
The B30 biofuel can be used in certain Diesel
engines; however, this use is subject to strict
application of the special ser vicing conditions.
Contact a CITROËN dealer or a qualified
workshop.
The use of any other type of (bio)fuel
(vegetable or animal oils, pure or diluted,
domestic fuel...) is strictly prohibited (risk of
damage to the engine and fuel system).
1.6 litre petrol engines, even though they have
been designed to operate on 95 RON petrol,
can accept 90 RON petrol without engine
adjustments, but with a slight deterioration in
performance.
2.0 litre petrol engines can accept 90 RON or
higher petrol.
Page 220 of 368
218
Checks
Running out of fuel (Diesel)
On vehicles fitted with the 1.6 litre HDi 110
engine, the fuel system must be manually
primed if you run out of fuel; refer to the
corresponding Diesel engine compartment
view.
1.6 litre HDi engine
)
Fill the fuel tank with at least five litres of
diesel.
)
Open the bonnet.
)
If necessary, unclip the styling cover for
access to the priming pump.
)
Squeeze and release the priming pump
repeatedly until resistance is felt (there
may be resistance at the first press).
)
Operate the starter until the engine starts
(if the engine does not start at the first
attempt, wait around 15 seconds before
trying again).
)
If the engine does not start after a few
attempts, operate the priming pump again
then start the engine.
)
Clip the styling cover back in place.
)
Close the bonnet.
Page 221 of 368
219
8
Checks
Checking levels
Take care when working under the bonnet, as certain areas of the engine may be extremely hot (risk of burns) and the cooling fan could start at
any time (even with the ignition off).
Oil level
The check of the the level is done
out with the dipstick, located under
the bonnet. Refer to the description
of your engine compartment for the
position of the dipstick.
Engine oil change
Refer to the maintenance and warranty guide
for details of the inter val for this operation.
In order to maintain the reliability of the engine
and emission control system, the use of
additives in the engine oil is prohibited.
Oil specifi cation
The oil must be the correct grade for your
engine and conform to the manufacturer's
recommendations.
Check all of these levels regularly, in line with the maintenance and warranty guide. Top them up if necessary, unless other wise indicated.
If a level drops significantly, have the corresponding system checked by a CITROËN dealer or a qualified workshop.
Dipstick
There are two marks on the dipstick:
A
= maximum
If the level is above this
mark, contact a CITROËN
dealer or a qualified
workshop.
B
= minimum
Top up the level through the
oil filler orifice, using the
correct grade of oil for your
engine. The level must never
be below this mark.
This check will only be correct if the vehicle is
on level ground and the engine has been off for
more than 30 minutes.
It is normal to top up the oil level between
two ser vices (or oil changes). CITROËN
recommends that you check the level, and top
up if necessary, every 3 000 miles (5 000 km).
After topping up the oil, the check when
switching on the ignition with the oil level
indicator in the instrument panel is not valid
during the 30 minutes after topping up.
Page 222 of 368
220
Checks
Coolant level
The coolant level should be between
the two marks. In addition, as the cooling system is
pressurised, wait at least one hour after
switching off the engine before carrying out any
work.
To avoid any risk of scalding, unscrew the cap
by two turns to allow the pressure to drop.
When the pressure has dropped, remove the
cap and top up the level.
Fluid specifi cation
The coolant must conform to the
manufacturer's recommendations.
The brake fluid level should be close
to the "MA X" mark. If it is not, check
the brake pad wear.
Brake fluid level
Changing the fl uid
Refer to the maintenance and warranty guide
for details of the inter val for this operation.
Fluid specifi cation
The brake fluid must conform to the
manufacturer's recommendations and meet
the DOT3 or DOT4 standard.
The cooling fan may star t after switching
off the engine: take care with ar ticles and
clothing that might become caught by the
fan blades.
When the engine is warm, the temperature of
the coolant is regulated by the fan.
Page 223 of 368
221
8
Checks
Avoid prolonged contact of used oil or
fluids with the skin.
Most of these fluids are harmful to
health or indeed very corrosive.
Do not discard used oil or fluids into
sewers or onto the ground.
Take used oil to a CITROËN dealer or
a qualified workshop (France) or to an
authorised waste disposal site.
Used products
Topping up
The reser voir must be topped up without delay
by a CITROËN dealer or a qualified workshop.
Additive level
(1.6 HDi 110 Diesel versions
with particle emissions filter)
The additive reser voir low level is indicated by
the display of this message.
Fluid specifi cation
For optimum cleaning, this fluid must not be
topped up with or replaced with plain water.
Screenwash and headlamp
wash fluid
To check or top up the fluid, stop the
vehicle, apply the parking brake and
switch off the engine.
)
Open the bonnet and secure it with the
stay.
)
Open the filler cap for the screenwash
reservoir.
)
Check the level using the gauge, then
top-up if necessary.
)
Refit the cap on the reser voir and close the
bonnet.
In wintry conditions, the use of fluid with
an ethyl alcohol or methanol base is
recommended.
Page 224 of 368
222
Checks
Checks
12 V battery
Electrolyte level
For access to the battery, refer to the
"12V battery" section.
Refer to the maintenance and
warranty guide for details of the
replacement inter vals for these
components.
Air filter and passenger compartment filter
Replace the oil filter each time the
engine oil is changed.
Refer to the maintenance and
warranty guide for details of the
replacement inter val for this
component.
Oil filter
If necessary, top up using distilled water,
removing the battery cap from each cell.
Check the electrolyte level at least once
a month.
When carrying out work on the battery, refer
to "12V battery" section for details of the
precautions to be taken before disconnecting
the battery and following its reconnection.
Unless other wise indicated, check these components in accordance with the maintenance and warranty guide and according to your engine.
Other wise, have them checked by a CITROËN dealer or a qualified workshop.
The electrolyte level must be between the
"LOWER LEVEL" and "UPPER LEVEL" marks. Depending on the environment (e.g. dusty
atmosphere) and the use of the vehicle
(e.g. city driving), replace them twice as often
if necessary
.
A clogged passenger compartment filter may
have an adverse effect on the per formance
of the air conditioning system and generate
undesirable odours.
Page 225 of 368
223
8
Checks
Manual gearbox
Refer to the maintenance and
warranty guide for ser vicing of the
gearbox.
"CVT" gearbox
Refer to the maintenance and
warranty guide for ser vicing of the
"CVT" gearbox.
Particle emissions filter (Diesel)
The start of saturation of the particle filter is
indicated by the temporary illumination of this
warning lamp accompanied by a message in
the instrument panel screen. As soon as the traffic conditions permit,
regenerate the filter by driving at a
speed of at least 25 mph (40 km/h) for
about 20 minutes (with the 1.6 litre HDi
engine the minimum speed is 36 mph
(60 km/h)).
If the warning lamp stays on, this
indicates a low additive level.
On a new vehicle, the first particle
filter regeneration operations may be
accompanied by a "burning" smell,
which is per fectly normal.
Following prolonged operation of the
vehicle at very low speed or at idle,
you may, in exceptional circumstances,
notice the emission of water vapour at
the exhaust on acceleration. This does
not affect the behaviour of the vehicle
or the environment.
