ESC Operating Modes
The ESC system has three available operating modes:
ESC On
This is the normal operating mode for the ESC. When-
ever the vehicle is started, the ESC system will be in this
mode. This mode should be used for most driving
situations. The ESC should only be turned OFF for
specific reasons as noted in the following paragraphs.
Partial Off
The “Partial Off” mode is intended for times when a
more spirited driving experience is desired. It is also
intended for driving in deep snow, sand, or gravel. This
mode disables the TCS portion of the ESC and raises the
threshold for ESC activation, which allows for more
wheel spin than what ESC normally allows.The “ESC Off” switch is located in the switch bank near
the bottom center of the instrument panel. To enter the
“Partial Off” mode, momentarily press the “ESC Off”
switch and the “ESC Activation/Malfunction Indicator
Light” will illuminate. To turn the ESC ON again, mo-
mentarily press the “ESC Off” switch and the “ESC
Activation/Malfunction Indicator Light” will turn off.
NOTE:
To improve the vehicle’s traction when driving
with snow chains, or when starting off in deep snow,
sand, or gravel, it may be desirable to switch to the
“Partial Off” mode by momentarily pressing the “ESC
Off” switch. Once the situation requiring “Partial Off”
mode is overcome, turn the ESC ON again by momen-
tarily pressing the “ESC Off” switch. This may be done
while the vehicle is in motion.
5
STARTING AND OPERATING 405

WARNING!
In the ESC “Full Off” mode, the engine torque
reduction and stability features are disabled. There-
fore, the enhanced vehicle stability offered by ESC is
unavailable. In an emergency evasive maneuver, the
ESC system will not engage to assist in maintaining
stability.ESC Off mode is intended for off-highway
or off-road use only.
NOTE:
When the ESC is switched OFF, a feature of the
system remains active. This feature controls wheel spin
across an axle quite similarly to a limited slip differential. If
one wheel on an axle is spinning faster than the other, the
system will apply the brake of the spinning wheel and
allow more engine torque to be applied to the wheel that is
not spinning. To improve the vehicle’s traction when
driving with tire chains, or when starting off in deep snow,
sand, or gravel, it may be desirable to switch to the “Partial
Off” mode by momentarily pressing the “ESC Off” switch.
Hill Start Assist (HSA)
The HSA system is designed to assist the driver when
starting a vehicle from a stop on a hill. HSA will maintain
the level of brake pressure the driver applied for a short
period of time after the driver takes their foot off of the
brake pedal. If the driver does not apply the throttle
during this short period of time, the system will release
brake pressure and the vehicle will roll down the hill. The
system will release brake pressure in proportion to the
amount of throttle applied as the vehicle starts to move in
the intended direction of travel.
HSA Activation Criteria
The following criteria must be met in order for HSA to
activate:
• Vehicle must be stopped.
• Vehicle must be on a 6% (approximate) grade or
greater hill.
5
STARTING AND OPERATING 407

Always use the lower suggested operating speed if both
the chain manufacturer and vehicle manufacturer sug-
gest a maximum speed. This notice applies to all chain
traction devices, including link and cable (radial) chains.
TIRE ROTATION RECOMMENDATIONS
Tires on the front and rear axles of vehicles operate at
different loads and perform different steering, driving,
and braking functions. For these reasons, they wear at
unequal rates.
These effects can be reduced by timely rotation of tires.
The benefits of rotation are especially worthwhile with
aggressive tread designs such as those on all season type
tires. Rotation will increase tread life, help to maintain
mud, snow, and wet traction levels, and contribute to a
smooth, quiet ride.Refer to the “Maintenance Schedule” for the proper
maintenance intervals. The reasons for any rapid or
unusual wear should be corrected prior to rotation being
performed.
Tire Rotation
The suggested rotation method for vehicles equipped
with all season tires is the “forward-cross” as shown in
the following diagram.
436 STARTING AND OPERATING

Service Contract......................... .559
Service Engine Soon Light (Malfunction Indicator). . .306
Service Manuals ......................... .562
Setting the Clock ......................... .351
Shifting ............................... .377
Automatic Transmission ..................377
Shoulder Belts ............................49
Shoulder Belt Upper Anchorage ................54
Side Airbag ..............................69
Side View Mirror Adjustment .................113
Signals, Turn ........................... .104
Snow Chains (Tire Chains) ...................434
Snow Tires ............................. .427
Spare Tire .............................. .429
Spark Plugs ............................ .535
Specifications Fuel (Gasoline) ........................ .535
Oil................................. .535
Speed Control (Cruise Control) ................217Speedometer
............................ .307
Starting .................................26
Automatic Transmission ..................371
Cold Weather ......................... .374
Engine Fails to Start .....................374
Remote ...............................26
Starting and Operating .....................371
Starting Procedures ....................... .371
Steering Column Controls ...................... .201
Column Lock ..........................211
Power .............................. .396
Tilt Column ...........................211
Wheel, Heated ........................ .213
Wheel, Tilt ............................211
Steering Wheel Audio Controls ...............352
Steering Wheel Mounted Sound System Controls . . .352
Storage ............................... .527
Storage, Vehicle .......................... .364
582 INDEX

Storing Your Vehicle...................... .527
Stuck, Freeing ........................... .475
Sunglasses Storage ....................... .264
Sun Roof .............................. .274
Supplemental Restraint System - Airbag ..........59
Synthetic Engine Oil ...................... .489
System, Remote Starting .....................26
Tachometer ............................. .303
Telescoping Steering Column .................211
Temperature Control, Automatic (ATC) ..........362
Temperature Gauge, Engine Coolant ............312
Tilt Steering Column .......................211
Time Delay, Headlight ..................... .196
Tire and Loading Information Placard ...........418
TIREFIT ............................... .461
Tire Markings ........................... .412
Tires ................................. .104
Aging (Life of Tires) .....................432 Air Pressure
.......................... .423
Chains .............................. .434
Compact Spare ........................ .429
General Information .....................423
High Speed .......................... .426
Inflation Pressures ...................... .424
Life of Tires .......................... .432
Load Capacity ........................ .418
Pressure Monitor System (TPMS) ............437
Pressure Warning Light ...................304
Quality Grading ....................... .563
Radial .............................. .426
Replacement .......................... .433
Rotation ............................. .436
Safety .............................. .412
Sizes ............................... .413
Snow Tires ........................... .427
Spinning ............................ .431
T

read Wear Indicators ....................431
10
INDEX 583
