Indicator Light (MIL)” is functioning and is not on when
the engine is running, and that the OBD II system is
ready for testing.
Normally, the OBD II system will be ready. The OBD II
system maynotbe ready if your vehicle was recently
serviced, recently had a dead battery or a battery replace-
ment. If the OBD II system should be determined not
ready for the I/M test, your vehicle may fail the test.
Your vehicle has a simple ignition actuated test, which
you can use prior to going to the test station. To check if
your vehicle’s OBD II system is ready, you must do the
following:
1. Cycle the ignition switch to the ON position, but do not crank or start the engine.
NOTE: If you crank or start the engine, you will have to
start this test over. 2. As soon as you cycle the ignition switch to the ON
position, you will see the MIL symbol come on as part
of a normal bulb check.
3. Approximately 15 seconds later, one of two things will happen:
• The MIL will flash for about 10 seconds and then
return to being fully illuminated until you turn OFF
the ignition or start the engine. This means that your
vehicle’s OBD II system is not readyand you should
not proceed to the I/M station.
• The MIL will not flash at all and will remain fully
illuminated until you turn OFF the ignition or start the
engine. This means that your vehicle’s OBD II system
is ready and you can proceed to the I/M station.
If your OBD II system is not ready,you should see your
authorized dealer or repair facility. If your vehicle was
recently serviced or had a battery failure or replacement,
7
MAINTAINING YOUR VEHICLE 485

REPLACEMENT BULBS
All of the interior bulbs are glass wedge base or glass
cartridge types. Aluminum base bulbs are not approved
and should not be used for replacement.
Interior Bulbs
Bulb Number
Rear Courtesy/Reading
Lamps W5W
Rear Compartment
(Trunk) Lamp 562
Overhead Console Read-
ing Lamps 578
Visor Vanity Lamps A6220
Glove Box Lamp – If
Equipped 194
Door Courtesy 562
Bulb Number
Shift Indicator Lamp JKLE14140
Optional Door Map
Pocket/Cupholder LED (Serviced at
Authorized Dealer)
For lighted switches, see your authorized dealer for
replacement instructions.
Exterior Bulbs
Bulb Number
Low Beam/High Beam
(Bi-Halogen Headlamp) HIR2LL
Low Beam/High Beam
(Bi-Xenon Headlamp) D3S (Serviced at
Authorized Dealer)
Front Turn Signal Lamp PSY24WSV
Front Park Lamp LED (Serviced at Authorized Dealer)
528 MAINTAINING YOUR VEHICLE

MAINTENANCE SCHEDULE
The Scheduled Maintenance services listed in this
manual must be done at the times or mileages specified
to protect your vehicle warranty and ensure the best
vehicle performance and reliability. More frequent main-
tenance may be needed for vehicles in severe operating
conditions, such as dusty areas and very short trip
driving. Inspection and service should also be done
anytime a malfunction is suspected.
The oil change indicator system will remind you that it is
time to take your vehicle in for scheduled maintenance.
On Electronic Vehicle Information Center (EVIC)
equipped vehicles, “Oil Change Required” will be dis-
played in the EVIC and a single chime will sound,
indicating that an oil change is necessary.Based on engine operation conditions, the oil change
indicator message will illuminate. This means that ser-
vice is required for your vehicle. Have your vehicle
serviced as soon as possible, within the next 500 miles
(805 km).
NOTE:
•
The oil change indicator message will not monitor the
time since the last oil change. Change your vehicle’s oil
if it has been six months since your last oil change,
even if the oil change indicator message is NOT
illuminated.
• Change your engine oil more often if you drive your
vehicle off-road for an extended period of time.
• Under no circumstances should oil change intervals
exceed 6,000 miles (10,000 km) or six months, which-
ever comes first.
8
M A I
N T
E
N
A
N
C E
S
C
H E
D
U L
E
S538 MAINTENANCE SCHEDULES

Brake Warning........................ .309
Bulb Replacement ...................... .529
Daytime Running ...................... .199
Dimmer Switch, Headlight .................201
Exterior ............................. .104
Fog ................................ .199
Hazard Warning Flasher ..................458
Headlights ........................... .195
Headlights On Reminder ..................199
Headlights On With Wipers ................196
Headlight Switch ...................... .195
High Beam ........................... .202
High Beam Indicator .....................303
High Beam/Low Beam Select ...............202
Illuminated Entry ........................21
Instrument Cluster ..................... .195
Intensity Control ....................... .204
Interior ............................. .204
License ............................. .532Lights On Reminder
.....................199
Low Fuel ............................ .318
Malfunction Indicator (Check Engine) .........306
Map Reading ......................... .202
Parade Mode (Daytime Brightness) ...........206
Passing ............................. .202
Reading ............................. .202
Seat Belt Reminder ..................... .312
Security Alarm ........................ .309
Service .............................. .528
Service Engine Soon (Malfunction Indicator) . . . .306
Tire Pressure Monitoring (TPMS) ............304
Traction Control ....................... .410
Turn Signal .......................... .104
Vanity Mirror ..........................116
Warning (Instrument Cluster Description) ......303
Loading Vehicle ......................... .453
Capacities ........................... .455
T

ires ............................... .418
576 INDEX

Locks..................................29
Automatic Door .........................32
Auto Unlock ...........................32
Child Protection .........................33
Door .................................29
Power Door ............................31
Low Tire Pressure System ...................437
Lubrication, Body ........................ .495
Lug Nuts .............................. .459
Maintenance Free Battery ....................490
Maintenance Procedures ....................487
Maintenance Schedule ..................... .538
Malfunction Indicator Light (Check Engine) .......306
Manual, Service ......................... .562
Master Cylinder (Brakes) ....................506
Memory Feature (Memory Seat) ...............189
Memory Seat ........................... .189
Memory Seats and Radio ....................189 Methanol
.............................. .446
Mini-Trip Computer ...................... .327
Mirrors ................................112
Electric Powered ........................115
Electric Remote .........................115
Exterior Folding ........................113
Heated ...............................116
Outside ..............................113
Vanity ...............................116
Mode Fuel Saver ........................... .324
Modifications/Alterations, Vehicle ...............7
Monitor, Tire Pressure System ................437
Mopar Parts ............................ .486
MTBE/ETBE ........................... .446
Multi-Function Control Lever .................201
New Vehicle Break-In Period ..................99
10
INDEX 577

Service Contract......................... .559
Service Engine Soon Light (Malfunction Indicator). . .306
Service Manuals ......................... .562
Setting the Clock ......................... .351
Shifting ............................... .377
Automatic Transmission ..................377
Shoulder Belts ............................49
Shoulder Belt Upper Anchorage ................54
Side Airbag ..............................69
Side View Mirror Adjustment .................113
Signals, Turn ........................... .104
Snow Chains (Tire Chains) ...................434
Snow Tires ............................. .427
Spare Tire .............................. .429
Spark Plugs ............................ .535
Specifications Fuel (Gasoline) ........................ .535
Oil................................. .535
Speed Control (Cruise Control) ................217Speedometer
............................ .307
Starting .................................26
Automatic Transmission ..................371
Cold Weather ......................... .374
Engine Fails to Start .....................374
Remote ...............................26
Starting and Operating .....................371
Starting Procedures ....................... .371
Steering Column Controls ...................... .201
Column Lock ..........................211
Power .............................. .396
Tilt Column ...........................211
Wheel, Heated ........................ .213
Wheel, Tilt ............................211
Steering Wheel Audio Controls ...............352
Steering Wheel Mounted Sound System Controls . . .352
Storage ............................... .527
Storage, Vehicle .......................... .364
582 INDEX

Tire Safety Information.....................412
To Open Hood .......................... .193
Towing ............................... .455
Behind a Motorhome .....................455
Recreational .......................... .455
Towing Vehicle Behind a Motorhome ...........455
Traction ............................... .392
Traction Control ......................... .402
Trailer Towing .......................... .455
Transmission Automatic ........................... .377
Fluid ............................... .508
Maintenance .......................... .508
Shifting ............................. .377
Transmitter Battery Service (Remote Keyless Entry). . .24
Transmitter Programming (Remote Keyless Entry) . . .21
Transmitter, Remote Keyless Entry (RKE) .........21
Tread Wear Indicators ..................... .431
Trip Odometer .......................... .303Trunk Lid (Deck Lid)
.......................43
Trunk Release, Emergency ....................44
Trunk Release Remote Control .................43
Turn Signals ............................ .201
UCI Connector .......................... .351
Uconnect® Advanced Phone Connectivity ..............152
Customer Programmable Features ...........344
Operation ............................ .130
Phone Call Features .....................142
Phone Features ........................ .147
Screen Activated Features .................332
Things You Should Know About Your
Uconnect® Phone ...................... .153
Uconnect® Settings .......................23
Uconnect® Phone ........................ .127
Uconnect® Settings .........................22
Customer Programmable Features ............34
584 INDEX
