2014 Acura MDX Owner's Manual

408
uuReplacing Light BulbsuFront Turn Signal/Front Side Marker/Parking Light Bulbs
Maintenance
Front Turn Signal/Front Side Marker/Parking Light BulbsWhen replacing, use the following bulbs.
1.Remove the holding clips, and pull the inner
fender back.
2.Turn the socket to the left and remove it.
3.Remove the old bulb and insert a new bulb.Side Turn Signal/Emergency Indicator Light BulbsDoor mirrors have the side turn lights. Have an authorized Acura dealer inspect and
replace the light assembly.Front Turn Signal/Side Marker/Parking Light: 28/8 W
1Front Turn Signal/Front Side Marker/Parking Light Bulbs
Insert a flat-tip screwdriver, lift and remove the center
pin to remove the clip.
Insert the clip with the center pin raised, and push
until it is flat.
Push until the
pin is flat.
Clip
Inner Fender
BulbSocket

409
uuReplacing Light BulbsuBrake Light and Turn Signal Light BulbsContinued
Maintenance
Brake Light and Turn Signal Light BulbsWhen replacing, use the following bulbs.
1.Remove the cover.
uStarting at the bottom, carefully pull the
cover straight out, working upward until
all pins are removed from their the
grommets.
uThe grommets should remain in the
body.
2.Use a Phillip-head screwdriver to remove
the bolts.
3.Pull the light assembly out of the rear pillar.Brake Light: 21 W
Rear Turn Signal Light: 21 W Bolts

410
uuReplacing Light BulbsuTaillight and Rear Side Marker Light Bulbs
Maintenance
4.Turn the socket to the left and remove it.
Remove the old bulb.
5.Insert a new bulb.
6.Slide the light assembly onto the guide on
the body.
7.Align the pins with the body grommets,
then push in until they fully seat.
Taillight and Rear Side Marker Light BulbsTaillight and rear side marker light bulbs are the LED type. Have an authorized Acura
dealer inspect and replace the light assembly.
Bulb Socket

411
uuReplacing Light BulbsuBack-Up Light
Maintenance
Back-Up LightWhen replacing, use the following bulbs.
1.Remove the cover by prying on the edge
using a flat-tip screwdriver.
uWrap the flat-tip screwdriver with a cloth
to prevent scratches.
2.Turn the socket to the left and remove it.
Remove the old bulb.
3.Insert a new bulb.Back-Up Light: 21 W
Bulb
Socket

412
uuReplacing Light BulbsuRear License Plate Light Bulbs
Maintenance
Rear License Plate Light BulbsRear license plate light bulbs are the LED type. Have an authorized Acura dealer
inspect and replace the light assembly.High-Mount Brake Light BulbsHigh-mount brake light bulbs are the LED type. Have an authorized Acura dealer
inspect and replace the light assembly.LED Puddle Light BulbsLED puddle light bulbs are LED type. Have an authorized Acura dealer inspect and
replace the light assembly.

413
Continued
Maintenance
Checking and Maintaining Wiper BladesChecking Wiper BladesIf the wiper blade rubber has deteriorated, it will leave streaks and the metal wiper
arm may scratch the window glass.Changing the Front Wiper Blade Rubber
1.Lift the driver side wiper arm first, then the
passenger side.
2.Place a cloth on the edge of the lock tab.
Push the lock tab up with a flat-tip screw
driver.
3.Slide the blade from the wiper arm.
1Changing the Front Wiper Blade RubberNOTICEAvoid dropping the wiper arm; it may damage the
windshield.
Lock Tab

414
uuChecking and Maintaining Wiper BladesuChanging the Front Wiper Blade Rubber
Maintenance
4.Slide the wiper blade out from its holder by
pulling the tabbed end out.
5.Remove the retainers from the rubber blade
that has been removed, and mount to a
new rubber blade.
uCorrectly align the rubber protrusion and
the retainer grooves.
6.Slide the new wiper blade onto the holder
from the bottom end.
uThe tab on the holder should fit in the
indent of the wiper blade.
7.Slide the wiper blade onto the wiper arm,
then push down the lock tab.
8.Lower the passenger side wiper arm first,
then the driver side.
Blade
Retainer BladeTab
Indent

415
uuChecking and Maintaining Wiper BladesuChanging the Rear Wiper Blade Rubber
Continued
Maintenance
Changing the Rear Wiper Blade Rubber
1.Raise the wiper arm off.
2.Slide the wiper blade out from the end with
the indent.
3.Remove the retainers from wiper blade and
mount to a new rubber blade.
1Changing the Rear Wiper Blade RubberNOTICEAvoid dropping the wiper arm; it may damage the
windshield.
Blade
Retainer
Rubber
