2014 Acura MDX buttons

429
Continued
Maintenance
Remote Control and Wireless Headphone Care
*
Replacing the BatteryIf it takes several pushes on the remote control buttons to operate the rear
entertainment system, replace the battery.
1.Remove the cover.
2.Make sure to replace the battery with the
correct polarity.■Remote ControlModels with Rear Entertainment System
1Replacing the BatteryNOTICEAn improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.
Replacement batteries are commercially available or
at a dealer.
Battery type: BR3032
* Not available on all models

458
uuEngine Does Not StartuIf the Keyless Access Remote Battery is Weak
Handling the Unexpected
If the Keyless Access Remote Battery is WeakIf the beeper sounds, the To Start, Hold Remote Near Start Button message
appears on the MID, the indicator on the ENGINE START/STOP button flashes, and
the engine won’t start, start the engine as follows.
1.Touch the center of the ENGINE START/
STOP button with the A logo on the keyless
access remote while the indicator on the
ENGINE START/STOP button is flashing.
The buttons on the keyless access remote
should be facing you.
uThe indicator flashes for about 30
seconds.
2.Depress the brake pedal and press the
ENGINE START/STOP button within 10
seconds after the beeper sounds and the
indicator changes from flashing to on.
uIf you don’t depress the pedal, the mode
will change to ACCESSORY.

462Handling the Unexpected
Shift Lever Does Not MoveFollow the procedure below if you cannot move the shift lever out of the
(P
position.
1.Set the parking brake.
2.Remove the built-in key from the keyless
access remote.
3.Wrap a cloth around the tip of a small flat-
tip screwdriver. Place it at the back of the
release lock cover, and remove the cover.
4.Insert the key into the shift lock release slot.
5.While pushing the key down, press the shift
lever release button and place the shift lever
into
(N.
uThe lock is now released. Have the shift
lever checked by a dealer as soon as
possible.
■Releasing the Lock
Cover
SlotRelease ButtonShift Lock Release Slot

494Index
Fuel...................................................... 16, 383
Economy ................................................. 385
Gauge ....................................................... 97
Instant Fuel Economy ............................... 101
Low Fuel Indicator ..................................... 73
Range ...................................................... 101
Recommendation .................................... 383
Refueling ................................................. 383
Fuel Economy............................................ 385
Fuel Fill Cap......................................... 16, 384
Message .................................................. 466
Fuel Fill Door....................................... 16, 384
Unable to Unlock ..................................... 476
Fuses.......................................................... 469
Inspecting and Changing ......................... 474
Locations ......................... 469, 471, 472, 473GGasoline (Fuel)
Economy ................................................. 385
Gauge ....................................................... 97
Information ............................................. 383
Low Fuel Indicator ..................................... 73
Refueling ................................................. 383
Gauges......................................................... 97
Gear Shift Lever Positions
Automatic Transmission ........................... 329
Glass (care)................................................ 435
Glove Box.................................................. 174
HHandling the Unexpected........................ 437
HandsFreeLink® (HFL)............................... 268
Auto Answer ........................................... 282
Automatic Import of Cellular Phonebook
and Call History ..................................... 284
Automatic Transferring............................ 282
Displaying Messages................................ 297
Editing User Name................................... 281
HFL Buttons............................................. 268
HFL Menus .............................................. 270
HFL Status Display ................................... 269
Limitations for Manual Operation ............ 269
Making a Call .......................................... 288
Options During a Call .............................. 294
Phone Setup............................................ 274
Receiving a Call ....................................... 293
Receiving a Text Message/E-mail.............. 295
Ring Tone................................................ 283
Selecting a Mail Account ......................... 296
Speed Dial ............................................... 285
To Create a Security PIN .......................... 280
To Set Up a Text Message/E-mail
Options ................................................. 279
Use Contact Photo .................................. 283
Hazard Warning Button.............................. 2
HDMI Jack..................................................... 5
Head Restraints........................ 164, 165, 166
Headlight Washers................................... 152
Headlights................................................. 145
Aiming .................................................... 407Automatic Operation .............................. 146
Dimming......................................... 145, 148
Operating ............................................... 145
Heated Door Mirrors............................... 154
Heated Steering Wheel........................... 181
Heated Windshield Button...................... 154
Heater (Steering Wheel).......................... 181
Heaters (Seat)................................... 182, 183
HFL (HandsFreeLink®).............................. 268
High Beam Indicator.................................. 76
Hill Start Assist System............................. 326
HomeLink® Universal Transceiver........... 266
IIdentification Numbers............................ 482
Engine and Transmission ......................... 482
Vehicle Identification............................... 482
IDS (Integrated Dynamics System).......... 333
IDS Button................................................ 333
Illumination Control................................ 153
Button .................................................... 153
Immobilizer System.................................. 135
Indicator ................................................... 77
Indicators.................................................... 70
Adaptive Cruise Control (ACC) with
Low Speed Follow (LSF) ................... 82, 337
Anti-lock Brake System (ABS) .................... 74
Blind Spot Information (BSI) .............. 83, 362
Brake System ............................................ 70
Charging System............................... 71, 465
