2014.5 Citroen C ZERO warning

We draw your attention to the following...
keys

afety warning
additional information
contributes to the protection of the environment
refer to the page indicated
Reading the detailed sections is essential to
make the most of your vehicle, in complete
safety.
Your vehicle is fitted with only some of the
equipment described in this document,
depending on the trim level, version and the
specifications for the country in which it is sold.
The fitting of electrical equipment or
accessories which are not recommended
by CITROËN may result in a failure of
your vehicle's electronic system. Contact
a CITROËN dealer for information on the
recommended equipment and accessories.
CITRoËn
has a presence on every continent,
a complete product range,
bringing together technology and a permanent spirit of innovation,
for a modern and creative approach to mobility.
We thank you and congratulate you on your choice.
Happy motoring!
at the wheel of your new vehicle,
getting to know each system,
each control, each setting,
makes your trips, your journeys
more comfortable and more enjoyable.

.
.
Instrument panel 9
I ndicator and warning lamps
1
0
Main battery state of charge indicator

1
8
Energy consumption
/ generation indicator
1
9
Distance recorder

2
0
Trip distance recorder

2
0
Lighting dimmer

2
1
Service indicator

2
1
Range indicator

2
3
Monitoring
ove
r view
Eco-driving
Remote control key 2 4
Doors
2
7
Boot
2

8
Electric windows

2
9
Charging flaps
3

0
access
Front seats 31
Rear seats
3
3
Mirrors
35
I

nterior fittings
3
7
Ventilation
4

0
Heating
4

2
Air conditioning

4
2
Front demist - defrost

4
5
Rear screen demist - defrost

4
5
Comfort
Driving recommendations 46
Starting - stopping the vehicle
4
7
Parking brake

4
8
Drive selector

4
9
Driving
Lighting controls 5 1
Automatic illumination of headlamps
5
3
Headlamp adjustment
5

3
Wiper control

5
4
Courtesy lamp

5
5
Visibility
Contents

.
.
Direction indicators 56
Automatic operation of brake lamps
5
6
Hazard warning lamps

5
6
Horn

5
7
Emergency or assistance call

5
7
Under-inflation detection
5

8
Braking assistance systems

6
2
Trajectory control systems

6
4
Front seat belts

6
5
Airbags
6

8
Safety
Child seats 72
Deactivating the passenger's front airbag
7
5
ISOFIX child seats

8
1
Child lock

8
4
Child safety
Charging the main battery 8 5
Ancillaries battery
9
3
Temporary puncture
repair kit

9
7
Changing a wheel

1
01
Snow chains

1
05
Changing a bulb

1
06
Changing a fuse

1
14
Changing a wiper blade

1
19
Towing the vehicle

1
19
Precautions for washing

1
20
Accessories
1

20
Practical information
Bonnet 123
Front compartment
1
24
Rear compartment

1
25
Checking levels

1
26
Chec ks
12

8
Checks
Motor and main battery 129
Weights
13
0
Dimensions
1

31
Identification markings
1

32
Technical data
Emergency or assistance 133
Audio system / Bluetooth
1
35
Audio and telematics
Visual search
Alphabetical index
Contents

7
Instruments and controls
1. Parking brake.
2. Drive selector.
3.
1

2 V accessory socket.
4.
P

assenger's airbag deactivation.
U

SB port.
5.
G

love box.
6.
C

up holder.
7.
W

indscreen demisting vents.
8.
L

ighting and direction indicator stalk.
9.
A

udio system.
10.
H

azard warning lamps switch.
11.
C

entre vents.
12 .
H

eating / air conditioning controls.
13.
E

mergency or assistance call.
.
Over view

10
Indicator and warning lamps
Visual indicators informing the driver that a
system is in operation, is deactivated or has
a fault.Associated warnings
The illumination of certain warning lamps may
be accompanied by an audible signal.
The warning lamps may come on continuously
(fixed) or flash.
Certain warning lamps may come on in
one of two modes. Only by relating the
type of lighting to the operating status
of the vehicle can it be ascertained
whether the situation is normal or
whether a fault has occurred.
When the ignition is switched on
Certain warning lamps come on for a few seconds
when the vehicle's ignition is switched on.
These same warning lamps go off after a few
seconds.
If you notice one of these warning lamps
remaining on, refer to the information on the
warning lamp in question.
Monitoring

11
Warning / indicator lampSt ateCause Action / Observations
Left-hand
direction
indicato r Flashing with audible
signal.
The lighting stalk is pushed down.
Right-hand
direction
indicator Flashing with audible
signal.
The lighting stalk is pushed up.
Hazard warning
lamps Flashing with audible
signal. The hazard warning lamps switch,
located on the dashboard, has been
operated. The left-hand and right-hand direction indicators and
their associated indicator lamps flash simultaneously.
Sidelamps and/
or dipped beam
headlamps On fixed.
The sidelamps and/or dipped beam
headlamps are on.
Front foglamps On fixed. The front foglamps are switched on. Turn the ring on the stalk rear wards twice to switch off
the front foglamps.
Rear foglamp On fixed. The rear foglamp is switched on. Turn the ring on the stalk rear wards to switch off the
rear foglamp.
Main beam
headlamps
On fixed.
The lighting stalk is pulled towards
you. Pull the stalk to return to dipped beam headlamps.
Operation indicator lamps
If one of the following indicator lamps comes on in the instrument panel, this confirms that the corresponding system has come into operation.
1
Monitoring

12
Warning / indicator lampSt ateCause Action / Observations
Ready
(ready to move
off) On fixed,
accompanied by an
audible signal when it
comes on. The vehicle is ready to move off and
you can press the accelerator.
The illumination period corresponds to the powering-up
of the vehicle.
Parking brake On fixed. The parking brake is applied or not
properly released. Release the parking brake to switch off the warning
lamp, keeping your foot on the brake pedal.
Observe the safety recommendations.
For further information on the parking brake, refer to
the "Driving" section.
Main batter y
charge (normal
or fast) On fixed.
The main battery is on charge. On completion of the charge, the lamp goes off.
Flashing. The charging cable is connected to
the vehicle but the main battery is not
yet charging. Check the connection of the charging cable.
Monitoring

13
Deactivation indicator lamps
Warning / indicator lampSt ateCause Action / Observations
Passenger's
airbag system On fixed, on the
centre console. The control switch, located on
the centre console, is set to the
OFF
p

osition.
The passenger's front airbag is
deactivated. Set the control switch to the ON
position to activate
the passenger's front airbag. In this case, do not fit a
child seat in the rear ward facing position.
Remember to check the position of the control switch
before starting your vehicle.
ESP/ASR On fixed. The ESP/ASR off switch, located
in the dashboard (driver's side) is
activated.
The ESP/ASR is deactivated.
ESP: electronic stability programme
ASR: anti-slip regulation. Press the button to activate the ESP/ASR.
The ESP/ASR system is automatically activated on
starting the vehicle.
If one of the following indicator lamps comes on, this confirms that the corresponding system has been switched off intentionally.
This is may be accompanied by an audible signal.
1
Monitoring
