1. Lighting and direction indicator control
stalk.
2.

Instrument panel with screen.
3.


Wiper
, screenwash, trip computer
control stalk.
4.

Ignition switch.
5.


Audio controls.
6.


Driver's front airbag, horn.
7.


Steering wheel height and reach
adjustment.
8.


Cruise control, speed limiter controls.
9.


Switch panel: parking sensors,
headlamp beam adjustment, DSC,
Stop

& Start.
10.

Bonnet release lever
.
11 .
Electric door mirror adjustment.
12.


Front electric window switches.
13.


Switch panel: hazard warning
lamps, central locking (passenger
compartment, load space).
14.


Cigarette lighter
.
15.

Heating-ventilation controls.
16.


Storage compartment.
17.


Electronic gearbox control or Grip
control button.
18.


Audio system.
19.


Screen.
20.


Emergency or assistance call.
Presentation

131. Lighting and direction indicator control
stalk.
2.

Instrument panel with screen.
3.


Wiper
, screenwash, trip computer
control stalk.
4.

Ignition switch.
5.


Audio controls.
6.


Driver's front airbag, horn.
7.


Steering wheel height and reach
adjustment.
8.


Cruise control, speed limiter controls.
9.


Switch panel: parking sensors,
headlamp beam adjustment, DSC,
Stop

& Start, alarm.
10.

Bonnet release lever
.
11 .
Electric door mirror adjustment.
12.


Front electric window switches.
13.


Switch panel: hazard warning
lamps, central locking (passenger
compartment, load space).
14.


Cigarette lighter
.
15.

Heating-ventilation controls.
16.


Storage compartment.
17.


Electronic gearbox control or Grip
control button.
18.


Audio system.
19.


Screen.
20.


Emergency or assistance call.
INSTRUMENTS AND CONTROLS
1
OVERVIEW
Presentation

+
ABS
33
Berlingo-2-VU_en_Chap03_Pret-a-partir_ed02-2014
Warning lamp isindicatesSolution - action
Power
steering on. a fault with the
system.The vehicle retains conventional steering without
assistance. Have it checked by a CITROËN
dealer or a qualified workshop.
Door open
detection on and accompanied
by a message in the
screen. that a door is not
closed correctly.
Check that all of the doors are closed.
ABS remaining on. a fault with the anti-
lock braking system.The vehicle retains conventional braking.
Have it checked by a CITROËN dealer or a
qualified workshop.
ESC flashing.
triggering of the ASR
or DSC regulation.The system optimises traction and improves the
directional stability of the vehicle.
Chapter 5, "Driving safety" section.
remaining on. a fault with the
system. E.g.: under-
inflation of the tyres.E.g.: check the pressure of the tyres. (Wheel
speed sensor, hydraulic block, ...). Have it
checked by a CITROËN dealer or a qualified
workshop.
Under-
inflation on.
The tyre pressure is
too low in or more
wheels.Check the tyre pressure as soon as possible.
This check should preferably be done with the
tyres cold.
flashing then
remaining on,
accompanied by the
Service warning
lamp, and depending
on equipment, the
display of a message. The tyre pressure
monitoring system
has a fault or one of
the wheels does not
have a sensor.
Detection of under-inflation is no longer assured.
have it checked by a CITROËN dealer or a
qualified workshop.
Particle filter on. a problem with the
particle filter (fuel
additive level, risk of
blockage, ...).Have the filter checked by a CITROËN dealer or
a qualified workshop.
Chapter 7, "Levels" section.
Instruments and controls
READY TO GO
3

39
Berlingo-2-VU_en_Chap03_Pret-a-partir_ed02-2014
UNDER-INFLATION DETECTIONEMISSIONS CONTROLS
System which
automatically checks the
pressures of the tyres
while driving.
E
obd
(European
o
n
Board

Diagnosis) is a
diagnostics system which
complies with, among
others,

the standards
concerning authorised emissions of:
-

CO (carbon monoxide),
-


HC (unburnt hydrocarbons),
-


NOx (nitrous oxides) or particles,
detected by oxygen sensors placed
upstream and downstream of the
catalytic converters.
The

driver is warned of any malfunction
of this emission control system by the
illumination of this specific warning
lamp in the instrument panel.
There is a risk of damage to the
catalytic converter. Have it checked
by a CITROËN dealer or a qualified
workshop. The system continuously monitors the
pressures of the four tyres, as soon as
the vehicle is moving.
A pressure sensor is located in the
valve of each tyre (except the spare
wheel).
The system triggers an alert if a drop
in pressure is detected in one or more
tyres.
The tyre under-inflation detection
system is an aid to driving which
does not replace the need for
vigilance on the part of the driver

.This system does not avoid the
need to check the tyre pressures
regularly (including the spare
wheel) and before a long journey.
Driving with under-inflated tyres
adversely affects road holding,
extends braking distances and causes
premature tyre wear, particularly under
arduous conditions (vehicle loaded,
high speed, long journey).
Driving with under-inflated tyres
increases fuel consumption.
The tyre pressures for your vehicle
can be found on the tyre pressure
label.
Refer to chapter 9, "Identification
markings" section.
The tyre pressures must be checked
when the tyres cold (vehicle stopped
for 1 hour or after driving for less then
6 miles (10 km) at moderate speed).
Otherwise, add 0.3 bar to the values
indicated on the label.
Instruments and controls
READY TO GO
3
