OPEnInG tHE BOnnEt
Bonnet stay
Secure the stay in its location,
identified  by   a   sticker   on   the   right-hand
side of the vehicle, to hold the bonnet
open.
Before closing the bonnet, put the stay
back

  in   its   clip   without   using   excessive
force.
On the outside
Raise the bonnet slightly by reaching
in  a   flat   hand,   palm   down,   to   make
access

  to   the   lever   easier.
With this hand, push the safety catch
to
  the   left.   Raise   the   bonnet.
On the inside
Pull the lever below the dashboard
towards  you.  The   bonnet   is   released.
to close
Lower the bonnet and release it at the
end  of   its   travel.   Check   that   the   bonnet
is

  secure.
avoid opening the bonnet in strong
winds.
opening the bonnet

Berlingo_2_VP_en_Chap07_Verification_ed02-2014
145
cHEcKS
c
arbon filter and passenger compartment filterParticle filter (
d iesel)
Maintenance of the particle filter must be  carried   out   by   a   CITROËN   dealer.
o

n acceleration after the vehicle has
been running for a prolonged period
at
  very   low   speed   or   at   idle,   you   may,
in

  exceptional   circumstances,   notice
the

  emission   of   water   vapour   at   the
exhaust.


This
  water   vapour   does   not
have any adverse ef

fect on vehicle
handling
  or   the   environment.
Battery
At the start of summer or winter, have your  battery   checked   by   a   CITROËN
dealer

  or   a   qualified   workshop.
Brake pads
Brake pad wear depends on the style of driving, in particular for vehicles
which are used in town, over short
distances.
  It   may   be   necessary   to
check

  the   thickness   of   the   pads,   even
between

  services.
Unless
  there   is   a   leak   on   the   circuit,   a
drop

  in   the   brake   fluid   level   indicates
that

  the   brake   pads   are   worn.
Brake disc / drum wear
For information on checking the brake disc  /   drum   wear,   contact   a   CITROËN
dealer

.
Parking brake
Where the parking brake travel is too great or there is a reduction in the
performance
  of   the   system,   the   parking
 brake

  should   be   adjusted,   even   between
 services.
Have

  the   system   checked   by   a   CITROËN
 dealer

  or   a   qualified   workshop.
Oil filter
Change the filter regularly in accordance  with   the   manufacturer's
servicing

  schedule.
An

access

flap

allows

replacement

of

the


filters.
The

carbon

filter

permits

continuous

and


effective

filtering

of

dust.
If

the

passenger

compartment

filter

becomes


blocked,

this

may

reduce

the

performance


of

the

air

conditioning
 system

and

generate

unpleasant
 odours.
W
e

recommend

the

use

of

a

combined

passenger


compartment

filter.

By

means


of

its

second

special

active

filter

,

it

contributes

to

the

purification

of the air breathed by the occupants
and the cleanness of the passenger
compartment


(reduction

of

allergic

symptoms,


unpleasant

odours

and

greasy


deposits).
Refer to theservicing and warranty
booklet

for

the

replacement

interval

for

these


components. Depending
  on   the   environment   (dusty
atmosphere...)

  and   the   use   of   the
vehicle

  (urban   driving...),   change   them
twice

  as   often   if   necessary.
Checks
CHECkS
7

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
160
1. Parking the vehicle
- The  occupants   must   get   out   of   the  vehicle
  and   wait   in   a   safe   location.
-

If
  possible,   park   the   vehicle   on
level, stable and non-slippery
ground.
-


Apply
  the   parking   brake,   switch
of

f   the   ignition   and   engage   first   or
reverse

  gear. -
 Place   a   chock   under   the   wheel  diagonally opposite the one to be
changed.
cHAnGInG A WHEEL
2. t
ools
The tools are stowed in a storage area
closed  by   a   flap   under   a   front   seat.
-

If
  necessary,   move   the   seat   forward
to

  access   the   storage   compartment
from

  the   rear.
-

Remove
  the   flap   then   take   out   the
jack

  and   the   tool   carrier.
-

Remove
  the   tools   needed   from   the
carrier

.
1.

Jack.
2.


Wheelbrace.
3.


Chock.
4.


Spanner for the Modutop roof bars
and

  rear   lamps.
5.

Allow
  wheel   trim   removal   tool.
6.

T
owing   eye.
If

the

vehicle

is

fitted

with

a

towbar,

it


is

sometimes

necessary

to

raise

the


vehicle

slightly

to

make

it

easier

to


remove

the

spare

wheel

from

its

carrier

.
On

certain

types

of

ground

and/
or if considerable loads are being
transported, call a CITR
o
Ë
n
dealer or
a

qualified

workshop.
The

jack

and

tools

are

specific

to

your

vehicle.


Do

not

use

them

for

other

purposes.
Changing a wheel

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
166
rEMOVABLE SnOW
S cr EE n
According to country, the removable snow screen is installed on the lower
part
  of   the   front   bumper   to   prevent   the
accumulation

  of   snow   at   the   radiator
cooling

  fan.
Fittingr emoval
- offer up the snow screen facing its
centring pin A   on   the   front   bumper.
-

Put it in place by pressing at each
clip

B   located   in   the   four   corners.
Do

not

forget

to

remove

the

snow screen when the exterior
temperature


is

higher

than

10°C

(no


risk

of

snowfall)

and

when


towing. -
Pass a screwdriver into the hole
located
  near   each   of   the   clips.
-

Use the screwdriver as a lever to
unclip the four clips

B   in   turn.
Snow screen

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
170
4. Foglamps type
c , H1 - 55W
-

Remove
  the   three   clips   and   the
screw securing the wheelarch liner

,
located
  below   the   bumper.
-

Move
  the   wheelarch   liner   upwards.
-

Remove
  the   foglamp   by   removing
the screw

, which can be accessed
via the hole provided for this
purpose
  in   the   bumper,   using   a
T

orx
© 30 screwdriver.
-
 Unclip   the   foglamp   by   squeezing
the


clip   to   release   it.
-

Remove the foglamp from the outside.- Turn the yellow cover a 1/4 turn to open.- Separate the clips which secure
the base of bulb on each side to
release   the   bulb.
-

Remove
  the   bulb   by   pulling,
keeping

  it   straight.
-

Insert the new bulb, reposition the
clips around the base of the bulb
and carry out the operations in
reverse

  order   to   put   the   lamp   unit
and

  the   bumper   back   in   position.
SIdE rEPEAtE r
type A,   WY5W   -   5W   (amber)
-
Push the repeater towards the rear
and disengage it by pullin

g the
front.
-

Contact a CITR
o Ë n dealer to
obtain a new repeater which is a
sealed
  component.
-

T
o   refit,   engage   the   repeater
towards the rear and bring it
towards

  the   front.
cOurtESY LAMPS
type A, 12V5W - 5W
-
Unclip the lens by sliding a
screwdriver in the slots on each
side

  of   the   courtesy   lamp.
-

Pull
  the   bulb   out   and   change   it.
-

Clip the lens in its housing and
ensure

  that   it   is   secured   correctly.
Front /
r ear
Changing a bulb

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
171
rEAr LAMPS
This procedure requires the use of the spanner supplied with the tools for
changing  a   wheel.
When
  refitting,   take   care   to
reposition the tabs and the supply
wire correctly to avoid trapping


the
  wire.
a

fter changing the rear direction
indicator
  bulb,   the   reinitialisation   time
is
  above   2   minutes.
-
Move aside the 4 tabs then extract
the
  bulb   holder.
-

Remove
  the   faulty   bulb   by
pressing it lightly while turning it
anticlockwise.
-


Change
  the   bulb.
When
  removing   the   lamp   unit:
-

with
  tailgate,   pull   the   lamp   unit
towards the centre of the vehicle,
-


with
  hinged   doors,   pull   the   lamp
unit

  towards   you.
For

more

information

concerning

the
 bulbs,

refer

to

the

"Types

of

bulb".
1.

Brake lamps / sidelamps


type B

,

P21/5W

-

21/5W
2.
d
irection indicators
type B

,

PY21W

-

21W

(amber)
3.
r
eversing lamps
type B

, P21W - 21W
4.

Foglamps


type B

, P21W - 21W
High pressure jet washing When using this type of washing
on stubborn dirt, do not persist on
the

headlamps,

the

other

lamps

and


their

edges

to

avoid

damaging

their


coating

and

seals. Chapter
  9,   "Changing   a   wheel"
section.
-


Identify the faulty bulb, then open
the

  rear   doors   to   180°.
Chapter
  3,   "Access"   section.
-

Remove
  the   two   fixing   bolts   using
the

  spanner   provided.
-

Pull
  the   lamp   unit   from   the   outside.
-

Holding
  the   lamp,   disconnect   the
electrical

  connector.
Changing a bulb
QUICk HELP
8

Berlingo_2_VP_en_Chap08_aide-rapide_ed02-2014
178
Without lifting (4 wheels on the
road)
You should always use a towing bar.
BEInG tOWEd
Ths procedure involves the use of the
towing eye supplied with the tools for
changing
  a   wheel.
From the front
- Unclip the cover by pressing the
bottom  part.
-

Fully
  screw   in   the   removable   towing
eye.
From the rear
- Unclip the cover using a coin or the
flat  part   of   the   towing   eye.
-

Fully
  screw   in   the   removable   towing
eye. When towing with the engine
switched

  off,   there   is   no   braking   or
steering

  assistance.
Lifting (only 2 wheels on the
road)
It is preferable to raise the vehicle
using
  professional   lifting   equipment.
Vehicles fitted with a manual
gearbox (d iesel version)
In the case of vehicles fitted with a  manual   gearbox,   the   gear   lever
must

  be   in   neutral,   failure   to   observe
this

  special   condition   may   result   in
damage

  to   transmission   and   braking
components

  and   the   absence   of
braking

  assistance   when   the   engine   is
started

  again.
Chapter

9,

"Changing

a

wheel"

section.
Having your vehicle towed

184
Berlingo_2_VP_en_Chap09_Caract-technique_ed02-2014
EnGInE cHArActErIStIcS
The engine characteristics (capacity,
maximum  power,   maximum   power
speed, fuel, C

o
2 emissions...) for your vehicle are given in the registration
document.
These characteristics correspond
to the values type-approved on a
test

bed,

under

conditions   defined
in European legislation (

d irective
1999/99/EC).
For

more

information,   refer   to   the
manufacturer's


website   or   sales
brochure


for

the
  model.   Contact
a


CITROËN

dealer   or   a   qualified
workshop.
WEIGHtS And tOWE d LOA d S
The weights and towable loads for your
vehicle can be found on the vehicle's
registration
  certificate.
These
  values,   expressed   in   kg,   are
laos

  present   on   the   manufacturer's
plate

  or   label.
The
  kerb   weight   is   equal   to   the   weight
without

  load   +   driver   (75   kg)   +   fuel   tank
filled

  to   90%.
The GTW and towed load values
indicated
  are   valid   up   to   a   maximum
altitude

  of   1000   metres.
The
  value   of
the

  towed   load   mentioned   must   be
reduced by 10 % for each additional
1000

  metres.
With
  load   transfer,   the   braked   trailer
weight can be increased, on condition
that

  the   equivalent   of   this   load   is
removed

  from   the   vehicle   so   that   the
GTW

  is   not   exceeded. High
  ambient   temperatures
may

  result   in   a   reduction   in   the
performance

  of   the   vehicle   in
order

  to   protect   the   engine.   When   the
ambient

  temperature   is   higher   than
37
  °C,   limit   the   towed   weight.
Towing with a lightly loaded
vehicle can adversely affect road
holding.
Towing
  a   trailer   increases   braking
distances.
When

  towing,   the   maximum   permitted
speed

  is   reduced   (comply   with   the
legislation

  in   force   in   the   country).
The
  recommended   nose   weight   is  the downward force on the towball
(removable
  with   or   without   tools).
GVW: gross vehicle weight, the
maximum
  authorised   weight.
G
t W:   gross   train   weight,   the   maximum
weight

  for   vehicle   plus   trailer.
Refer
  to   chapter   9,   "Identification
markings"

  section.
In
  each   country,   it   is   imperative   that
the towed loads authorised by local
legislation

  are   complied   with.
T
o   find
out your vehicle's towing capacities
and its gross train weight, consult a
CITROËN

  dealer.
Weights
