3-1
3
EBU17680
DESCRIPTION
EBU17690Left view
EBU17700Right view
1. Front shock absorber assembly spring preload adjusting
ring
2. Fuel cock
3. Throttle stop screw
4. Air filter case
5. Battery
6. Owner’s tool kit
7. Oil filter element
8. Shift pedal
1. Spark arrester
2. Fuse
3. Rear shock absorber asse mbly spring preload adjusting
nut
4. Drive select lever
5. Fuel tank cap
6. Spark plug
7. Engine oil filler cap
8. Brake pedal
9. Rear brake light switch
10.Rear brake fluid reservoir
12345 6
78910
U1BS63E0.book Page 1 Tuesday, March 13, 2012 11:43 AM
8-40
8
2. Connect the positive battery lead first, then
connect the negative battery lead by installing
their bolt. NOTICE: When installing the bat-
tery, the main switch must be off, and the
positive lead must be connected before
the negative lead.
[ECB01110]
3. Install the battery holding plate by installing the bolts, and then hook the band to secure
the owner’s tool kit.
4. Install the seat. (See page 4-12.)
EBU25243Replacing the fuse The fuse holder is located under the seat. (See
page 4-12.)
If the fuse is blown, replace it as follows. 1. Turn the key to “OFF” and turn off all electrical circuits.NOTICEECB00640To prevent accidental short-circuiting, turn off
the main switch when checking or replacing a
fuse.
1. Positive battery lead (red)
2. Negative battery lead (black)
2
1. Fuse
2. Spare fuse
U1BS63E0.book Page 40 Tuesday, March 13, 2012 11:43 AM
8-41
82. Remove the blown fuse, and then install a
new fuse of the specified amperage.
WARNING! Always use a fuse of the spec-
ified rating, and never use a substitute ob-
ject in place of the proper fuse. An
improper fuse or a substitute object can
cause damage to the electrical system,
which could lead to a fire.
[EWB02172]
3. Turn the key to “ON” and turn on the electricalcircuits to check if the devices operate.
4. If the fuse immediately blows again, have a Yamaha dealer check the electrical system.EBU25542Replacing a headlight bulb If a headlight bulb burns out, replace it as follows.1. Remove the headlight bulb holder cover at the rear of the headlight by pulling it off. 2. Remove the headlight bulb holder by pushing
it inward and turning it counterclockwise.
Specified fuse:
15.0 A
1. Headlight bulb holder cover
1. Headlight bulb holder
U1BS63E0.book Page 41 Tuesday, March 13, 2012 11:43 AM
10-4
10
Rim size:9 x 8.0ATFront brake:Type:
Disc brake
Operation: Right hand operation
Specified brake fluid: DOT 4Rear brake:Type:Disc brake
Operation: Right foot operation
Specified brake fluid:
DOT 4Front suspension:Type:Double wishbone
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel: 200 mm (7.9 in)Rear suspension:Type:
Swingarm (link suspension)
Spring/shock absorber type: Coil spring/gas-oil damper
Wheel travel: 210 mm (8.3 in)
Electrical system:Ignition system:DC CDI
Charging system:
AC magnetoBattery:Model:YTZ10S
Voltage, capacity:
12 V, 8.6 AhHeadlight:Bulb type:Krypton bulbBulb voltage, wattage × quantity:Headlight:
12 V, 30.0/30.0 W × 2
Tail/brake light: 12 V, 5.0/21.0 W × 1
Neutral indicator light:
12 V, 1.7 W × 1
Reverse indicator light: 12 V, 1.7 W × 1Fuse:Fuse:
15.0 A
