EBU21865General maintenance and lubrication chart TIP●For ATVs not equipped with an odometer or an hour meter, follow the month maintenance intervals.●For ATVs equipped with an odometer or an hour meter, follow the km (mi) or hours maintenance inter-
vals. However, keep in mind that if the ATV isn’t used for a long period of time, the month maintenance
intervals should be followed.●Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools,
data and technical skills.NO.ITEM CHECK OR MAINTENANCE
JOB INITIAL
EVERY
Whichev- er comes first month136612
km
(mi) 320
(200) 1300
(800) 2500
(1600) 2500
(1600) 5000
(3200)
hours 20 80 160 160 320
1 Air filter element Clean and replace if necessary. Every 20–40 hours (more often in wet or
dusty areas)
2 *Front brake Check operation and correct if necessary.
Check fluid level and ATV for fluid leakage, and
correct if necessary. √√√√√
Replace brake pads. Whenever worn to the limit
3 *Rear brake Check operation and correct if necessary.
Check brake lever and pedal free play, and adjust
if necessary. √√√√√
Check brake friction plate wear and replace if nec- essary. √ √√√
U1CT62E0.book Page 5 Friday, May 11, 2012 9:03 AM

8-6
8
4*Brake hoses Check for cracks or other damage, and replace if
necessary. √√√√
Replace. Every 4 years
5 *Wheels Check runout and for damage, and replace if nec-
essary. √ √√√
6 *Tires Check tread depth and for damage, and replace if
necessary.
Check air pressure and balance, and correct if necessary. √ √√√
7 *Wheel hub bearings Check for looseness or damage, and replace if
necessary. √ √√√
8 *V- b e l t Check for wear, cracks or other damage, and re-
place if necessary. √ √√√
9 *Drive shaft univer-
sal joint Lubricate with lithium-soap-based grease.
√√√
10 *Chassis fasteners Make sure that all nuts, bolts, and screws are
properly tightened. √√√√√
11 *Shock absorber as-
semblies Check operation and correct if necessary.
Check for oil leakage and replace if necessary.
√√√
12 *Stabilizer bushes Check for cracks or other damage, and replace if
necessary. √√√
NO. ITEM
CHECK OR MAINTENANCE
JOB INITIAL EVERY
Whichev- er comes first month136612
km
(mi) 320
(200) 1300
(800) 2500
(1600) 2500
(1600) 5000
(3200)
hours 20 80 160 160 320U1CT62E0.book Page 6 Friday, May 11, 2012 9:03 AM

8-7
8
13*Rear knuckle pivots Lubricate with lithium-soap-based grease. √√√
14 *Steering shaft Lubricate with lithium-soap-based grease. √√√
15 *Steering system Check operation and repair or replace if damaged.
Check toe-in and adjust if necessary. √√√√√
16 *Engine mount Check for cracks or other damage, and replace if
necessary. √√√
17 *Axle boots Check for cracks or other damage, and replace if
necessary. √√√√√
18 Engine oil Change.
Check ATV for oil leakage, and correct if neces-
sary. √ √√√
19 Engine oil filter car-
tridge Replace.
√√√
20 *Engine oil strainer Clean. √√√
21 Differential gear oil Change.
Check ATV for oil leakage, and correct if neces-
sary. √√
22 Final gear oil Change.
Check ATV for oil leakage, and correct if neces-
sary. √ √√√
NO. ITEM
CHECK OR MAINTENANCE
JOB INITIAL EVERY
Whichev- er comes first month136612
km
(mi) 320
(200) 1300
(800) 2500
(1600) 2500
(1600) 5000
(3200)
hours 20 80 160 160 320U1CT62E0.book Page 7 Friday, May 11, 2012 9:03 AM

8-8
8
EBU28391TIP●Some maintenance items need more frequent service if you are riding in unusually wet, dusty, sandy or
muddy areas, or at full-throttle.23 Cooling system Check coolant level and ATV for coolant leakage,
and correct if necessary. √√√√√
Replace coolant. Every 2 years
24 *Moving parts and
cables Lubricate.
√√√√
25 *Drive select lever
safety system cable Check operation and adjust or replace if neces-
sary. √√√
26 *Throttle lever Check operation.
Check throttle lever free play, and adjust if neces-
sary.
Lubricate cable and lever housing. √√√√√
27 *Front and rear brake
switches Check operation and correct if necessary.
√√√√√
28 *Lights and switches Check operation and correct if necessary.
Adjust headlight beams. √√√√√
NO. ITEM
CHECK OR MAINTENANCE
JOB INITIAL EVERY
Whichev- er comes first month136612
km
(mi) 320
(200) 1300
(800) 2500
(1600) 2500
(1600) 5000
(3200)
hours 20 80 160 160 320U1CT62E0.book Page 8 Friday, May 11, 2012 9:03 AM

8-9
8
●Hydraulic brake service
Regularly check and, if necessary, correct the brake fluid level.
Every two years replace the internal components of the brake master cylinder and calipers, and changethe brake fluid.
Replace the brake hoses every four years and if cracked or damaged.
U1CT62E0.book Page 9 Friday, May 11, 2012 9:03 AM

8-10
8
EBU23090Removing and installing panels The panels shown need to be removed to perform
some of the maintenance jobs described in this
chapter. Refer to this section each time a panel
needs to be removed and installed.
EBU30261Panels A and C
To remove a panel1. Remove the seat. (See page 4-18.)
2. Pull outward on the areas shown, and thenpull upward as shown.
1. Panel A
1. Panel B
2. Panel C
3. Panel D
4. Panel E
U1CT62E0.book Page 10 Friday, May 11, 2012 9:03 AM

8-11
8
To install a panel
1. Place the panel in its original position. 2. Install the seat.
U1CT62E0.book Page 11 Friday, May 11, 2012 9:03 AM

8-12
8Panel B
To remove the panel
1. Remove the carrier top bolts.
2. Remove the carrier bolts under the fenders,
and then take the carrier off. 3. Remove the quick fastener screws, and then
pull the panel upward to remove it.1. Carrier bolt (top)
1
1
1
1. Carrier bolt (under the fenders)
