2013 VOLKSWAGEN TIGUAN maximum

Maximum power
output (SAE net)
Injection
technology
Engine
ID code
Maximum torque (SAE net) No. of cylinders
Displacement
kW at 0 – 0 rpm 2.0T Nm at 0 – 0 rpm .1 CID
( 4 ccm)

Dimensions

Function Action for seat heating ⇒fig.52
Switch on: Press the Aor ebutton. Seat heating is switched on
to maximum.
Adjusting heating
level:
Press the button Aor erepeatedly until the desired
heating level is set.
Switch off: Press the button Aor erepeatedly until all indicator
lights in the button are off.

Special seat heating features
The seat heating on the passenger side is switched off every time the ignition is switched off.
Seat heating must be switched on again each time the ignition is switched on.
On the driver side the seat heating will resume at the setting that was set when the ignition was
switched off. However, this feature only works if the key does not get pulled out of the ignition switch,
or, for vehicles with Keyless Access, the doors are not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from medica-
tion, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature ⇒ .
The use of seat heating by persons with these conditions could result in burns to the back, buttocks,
and legs that may take a long time to heal and may never heal completely. If you have any of these
conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult
your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications, can
increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain
can receive serious burns to the back, buttocks, and legs that take a long time to heal or may
never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned
because of a medical condition. Take regular breaks and get out of the vehicle, particularly
on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is
being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front
seats or apply concentrated pressure to a small area of the seat or backrest.

WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and
serious injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision.
But vehicles or other objects seen in a convex mirror will look smaller and farther away than
they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when
changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of
vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
x Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
x Never fold power mirrors in manually because doing so could damage the electrical drive.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by
pressing on the edges of the mirror surface.

x Hitch weight and tongue weight for trailer operation.
Please refer to the Gross Vehicle Weight Rating (GVWR) and the Gross front and rear Axle Weight
Ratings (GAWR) for your vehicle, which are printed on the vehicle's Safety Compliance Certification
Label on the driver door jamb.
WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and
serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle
Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle
Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load
and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity
weight figures apply when the load is distributed evenly in the vehicle (passengers and
luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the
rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as
little as possible.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment Hooks on elastic straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from the hooks when attaching them to the
vehicle and do not let them snap back and hit you.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let
them snap back and hit you.
x First attach hooks to the tie-downs at the rear seat backrest in the luggage compartment
and then to the tie-downs near the loading edge of the luggage compartment. This way, if one
of the hooks on the elastic straps snaps back, it will move away from you, decreasing the risk
of personal injury.
The maximum load for the tie-downs is about lbs. ( kg).
For suitable ratchet straps and luggage stowage systems, please see an authorized Volkswagen
dealer or authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. In the luggage compartment: Shopping bag hooks.

NOTICE
The maximum load for the shopping bag hook is 6.6 lbs. (3 kg).
Applicable only in the United States
Luggage net

Fig. In the luggage compartment: Luggage net hooked in place.

Electrical load Maximum power
Turn signals per side 54 watts
Side marker lights total4 watts
Taillights lights total 54 watts

WARNING
x An improperly installed or incorrect trailer hitch can cause a trailer to separate from the
tow vehicle and cause serious personal injuries.
x If you don't have to tow a trailer any more, remove the entire trailer hitch. Always seal all
bolt holes to prevent water and deadly exhaust fumes from getting into the vehicle.
NOTICE
x If the trailer lights are not connected properly, the vehicle's electronics may be damaged.
x If the trailer uses too much electricity, the vehicle's electronics may be damaged.
x Never connect the electrical system for the trailer directly to the electrical connections for
the rear lights or to any other unsuitable power sources. Use only a suitable connector to
provide power to the trailer.
If you tow a trailer frequently, Volkswagen recommends having the vehicle serviced between the
regular maintenance and inspection intervals because of the extra load it has to pull.
In some countries an additional fire extinguisher must be carried if the total weight of the trailer
exceeds 5, lbs. (2, kg).
Hitching up and connecting a trailer

Loading the trailer
The weight distribution in the vehicle and trailer must be balanced. Use the maximum permissible
tongue weight and make sure that the load in the trailer is evenly distributed and that it is not front-
heavy or tail-heavy:
x Distribute the load in the trailer so that heavy objects are directly above the axle or as close as
possible to the axle.
x Secure loads properly on the trailer.
Tire pressure
Always follow the trailer manufacturer's tire pressure recommendations for the trailer tires.
When towing, inflate the towing vehicle's tires to the maximum permissible pressure listed on the tire
pressure label
WARNING
Exceeding the gross weight ratings for axle, tongue, vehicle, trailer or combined weight can
cause accidents and serious personal injury.
x Never exceed the specified values.
x Never let the actual weights at the front and rear axles exceed the Gross Axle Weight
Rating. Never let the combined front and rear weights exceed the Gross Vehicle Weight
Rating.
WARNING
Trailer loads that are not properly secured can shift when the vehicle is moving or braking
and suddenly change the way the vehicle handles, causing accidents and severe injuries.
x Always load the trailer properly.
x Always secure the load properly with suitable, undamaged straps that can be tightened so
that the load cannot shift.
Driving with a trailer
