⇒ fig. 40 Function Action
(1) Move the front seat backward or
forward.
Pull the lever up and move the front seat. The front
seat must lock in place after the lever is released!
(2) Lumbar support control. Push the lever forward or pull it backward.
(3) Adjust backrest angle. Push back the lever and adjust the seat backrest.
The seat backrest must lock in place after you
release the lever!
(4) Adjust seat height. Move the lever several times up or down.
(5) Adjust backrest angle.
Push back the lever and adjust the seat backrest.
The seat backrest must lock in place after you
release the lever.
Electrical controls on the driver and front passenger seat
Fig. 41 Driver seat controls to adjust the seat backward and forward, change seat cushion height and angle,
and adjust backrest angle.
Fig. 42 Lumbar support control.
fig. 41 Press the switch in the direction of the arrow:
(2) and (3) Raise or lower the seat cushion.
(2) or (3) Adjust seat cushion angle.
(B) Forward or
backward. Adjust backrest angle.
Press fig. 42 switch for each area:
(1) or (2) Adjust lumbar support.
(3) or (4) Adjust lumbar support height.
WARNING
Improper use of electrical seat controls can cause serious personal injuries.
x The front seats in your vehicle can be electrically adjusted even when the vehicle key has
been removed from the ignition or, on a vehicle with Keyless Access, even if there is no key
in the vehicle.
x Never leave children and persons who need help in the vehicle alone because the unsu-
pervised use of the electric seat adjustments can result in serious personal injury.
x Always make sure that no one is in the way while the front seats are being adjusted, or
while calling up the stored memory settings for the front seats. In an emergency, stop auto-
matic seat adjustment by pressing a seat adjustment switch.
NOTICE
To help prevent damage to electrical parts in the seat, do not kneel on the front seats or apply
concentrated pressure to a small area of the seat or backrest.
If the vehicle battery is too weak, the electrical seat adjustment controls may not work.
Starting the engine stops seat adjustment.
When entering and exiting the vehicle, be careful not to come into contact with any switches that
could change the seat adjustment.
