2013 VOLKSWAGEN TIGUAN bulb

Lights
up Possible cause Proper response

One or more driving lights not working or
cornering light malfunction.
Replace burned out bulb or
if all light bulbs are OK, visit an authorized
Volkswagen dealer or authorized
Volkswagen Service facility.
Cornering light system malfunction. See an authorized Volkswagen dealer or
authorized Volkswagen Service Facility Adaptive Front Lighting System
malfunction.
; License plate light not working.
Replace the light bulb that isn't working
Error! Bookmark not defined.. If all light
bulbs are OK, see an authorized
Volkswagen dealer or an authorized
Volkswagen Service facility.



Left or right turn signal.
Check the turn signals on the vehicle and
the trailer. The indicator light blinks twice as fast if a
turn signal is not working on the vehicle or
the trailer.
 Daytime running lights (DRL) on. .
$2,
 High beams switched on or headlight
flashers in use.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to
break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
x Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, stop
the engine, turn on the emergency flashers, and use other warning devices to warn
approaching traffic.
x Never park the vehicle in areas where the hot catalytic converter and exhaust system can
come into contact with dry grass, brush, spilled fuel, oil, or other material that can catch fire.
x A broken down vehicle presents a high accident risk for itself and others. Switch on
emergency flashers and set up a warning triangle to warn oncoming traffic.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
High Intensity Discharge (HID) headlights provide bright, uniform lighting to help you see and be
seen. The light comes from an electric arc between two electrodes in the gas-filled bulb. Over time, the
electrodes can wear down and the gap between them will get wider. The HID lamp’s control unit then

increases the voltage to keep the arc’s brightness constant. However, the commonly called “Xenon”
bulbs will also ultimately burn out. Before they burn out, HID lamps can flicker. A message will then
appear in the MFI. This is your reminder to see an authorized Volkswagen dealer or an authorized
Volkswagen Service facility to check the headlights.
Turn signal lever and high beam switch

Fig. 82 Turn signal lever and high beam switch.

The turn signal light works only when the ignition is switched on. The emergency flasher works
even when the ignition is switched off
The indicator light flashes twice as fast if a turn signal bulb is burned out.
High beams can only be switched on when low beams are on.
Switching lights on and off

Fig. 83 Headlight switch next to the steering wheel: A: Vehicles with front fog lights. B: Vehicles without front
fog lights.

Information regarding changing light bulbs
WARNING
Disregarding the safety-related checklist may lead to accidents and injuries.
x Please note and follow the points listed in the checklist.

WARNING
The engine compartment of any motor vehicle is a potentially dangerous area and can cause
serious personal injury.
x Always use extreme caution when doing any work in the engine compartment. Always
follow commonly accepted safety practices and use common sense. Never risk personal
injury.
x Never perform any work in the engine compartment unless you know exactly how to carry
out the job and have the correct technical information and the correct tools.
x If you are uncertain about what to do, have the work performed by an authorized
Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified
workshop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID - High Intensity Discharge (Xenon)
lights and H7/H15 bulbs replaced by a qualified technician. Serious personal injury may result
from improperly performed work.
x Never open or close the engine hood if steam or coolant is escaping. Hot steam or coolant
can cause serious burns. Always wait until you no longer see or hear steam or coolant
escaping from the engine.
x Always let the engine cool down completely before carefully opening the hood.
x Hot parts of the engine and the exhaust system will burn skin on contact.
x When the engine has cooled down and you are ready to open the hood:
– Firmly apply the parking brake and shift the transmission into Park (P) (automatic) or
Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the remote control vehicle key is out
of range of the vehicle and that the vehicle cannot be started by depressing the starter
button.
– Always keep children and others away from the engine compartment and never leave
them unsupervised.
x The engine coolant system is under pressure when the engine is hot. Never unscrew the
coolant expansion tank cap when the engine is hot. Hot coolant can spray out and cause
severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclockwise direction while applying
light downward pressure on the top of the cap.
– Always protect your face, hands, and arms from hot escaping coolant or steam by
covering the cap with a large, thick rag.
x Never spill fluids on the engine or exhaust system when refilling. Spilling fluids onto hot
parts of the engine or exhaust system can cause a fire.
WARNING
High voltage systems in the engine compartment can cause electrical shocks or even
electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially careful when using jumper cables.
The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the engine is running or
being started:
– Never touch ignition cables. Never touch other components of the high voltage
electronic ignition system.
– Never touch the wiring of the HID - High Intensity Discharge (Xenon) headlights.

WARNING
Working on the batteries or the electrical system in your vehicle can cause serious acid
burns, fires, explosions, or electrical shocks. Always read and heed the following WARNINGS
and safety precautions before working on the batteries or the electrical system.
x Before working on the electrical system, always switch off the ignition and all electrical
consumers and disconnect the negative (–) cable from the standard 12 Volt battery.
x When you change a light bulb, always switch off the light first.
x Always keep children away from battery acid and vehicle batteries in general.
x Always wear eye protection. Never let battery acid or lead particles come into contact with
your eyes, skin, or clothing.
x Sulfuric battery acid is very corrosive. It can burn unprotected skin and cause blindness.
Always wear protective gloves and eye protection. To reduce your risk of injury, never tilt the
batteries, as this could spill acid through the vents and burn you.
x If you get battery acid in your eyes or on your skin, immediately rinse with cold water for
several minutes and then get immediate medical attention. If you swallow any battery acid,
get medical attention immediately.
x When disconnecting the batteries from the vehicle electrical system, always disconnect
the negative cable (–) first and then the positive cable (+).
x Always switch off all electrical consumers before reconnecting 12 Volt batteries.
Reconnect the plus cable (+) first and then the negative cable (–). Never reverse the polarity
of the connections. This could cause a fire.
x A highly explosive mixture of gases is given off when the battery is being charged.
x Do not smoke and avoid fires, sparks, and open flames when working. Never create
sparks or electrostatic charges when handling cables and electrical equipment. Never short
circuit the battery terminals. High-energy sparks can cause serious personal injury.
x Never use or attempt to charge a damaged or frozen battery, or a battery that was frozen
but has thawed. Charging a frozen or thawed battery could cause explosions and chemical
burns! Replace damaged or frozen vehicle batteries immediately. A dead battery can freeze at
temperatures around +32 °F (0 °C).
x If the battery has a vent line or tube, make sure that it is properly connected to the battery.
x Always make sure that the vent line is securely attached to a vehicle battery that is located
in the luggage compartment.
WARNING
California Proposition 65 Warning
x Battery posts, terminals, and related accessories contain lead and lead components,
chemicals known to the State of California to cause cancer and reproductive harm. Wash
your hands after handling.
NOTICE
x Do not expose the vehicle battery to direct sunlight for an extended period of time as
ultraviolet rays may damage the battery housing.
x If the vehicle is left standing in the cold for a long time, protect the vehicle battery from
freezing. A battery will be permanently damaged by freezing.
Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle
battery has been replaced may change or delete system settings (including time, date, personal

Frequently asked questions
If you suspect a malfunction or vehicle damage, read and follow the following advice before contacting
an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. You may also find
helpful information under “Characteristics” and “Checklist” in the index.

Description Possible causes among
others Possible remedy
Engine does not start.
Vehicle battery dead. – Perform jump start
– Charge vehicle battery
The wrong remote control
vehicle key is used.
Use a valid remote control vehicle key

Fuel level too low. Refuel
Vehicle cannot be locked
or unlocked using remote
control vehicle key.
– Battery in remote control
vehicle key dead.
– Too far away from vehicle.
– Buttons pressed outside
operating range.
– Replace battery in the remote control
key
– Move closer to vehicle.
– Synchronize remote control vehicle
key
– Lock or unlock vehicle manually
Unusual noises.
Cold engine, braking support
systems, electronic parking
brake.
Check the “Noises” entry in the
keyword index.
Driver seat and outside
mirrors when vehicle is
unlocked.
Convenience settings are
stored. Correct convenience settings
Memory-seat settings are
stored.
– Reassign seat setting
– Clear memory-seat memory
Front seats cannot be
adjusted with power
controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if necessary
Features do not work as
described in this manual.
Settings were adjusted in the
Volkswagen Information
System.
Check and reset to factory settings if
necessary
Headlights do not light up
the road as they should.
– Headlights incorrectly
adjusted.
– Light bulbs burned out.
– Low beams not switched on.
Have the headlight range adjusted by
an authorized Volkswagen dealer or an
authorized Volkswagen Service
Facility. Adjust headlight range .
– Change light bulbs
– Switch on low beams
Electrical consumers do
not work.
Vehicle battery charge too low. Charge vehicle battery
Remaining fuel level too low. Refuel .
Fuse blown. Check fuse and replace if necessary

Fuel consumption higher
than indicated.
– Short hauls.
– “Jumpy gas pedal”.
– Avoid short distance driving.
– Drive defensively.
– Accelerate smoothly.
Electrical loads switched on. Switch off unnecessary loads.
Engine control malfunctioning. Have the malfunction corrected

Changing light bulbs
