2013 VOLKSWAGEN TIGUAN ESP

WARNING
Never try to drive crosswise on a slope, especially one that is too steep for your vehicle. The
vehicle could slide sideways and tumble down the slope. To reduce the risk of accidents and
serious injuries:
x Never underestimate the difficulties and dangers of driving crosswise on a slope. Never
take routes or risks that could put you or your passengers in danger. If you cannot go on or
have doubts about the safety of your route, turn back and take a different route.
x When driving crosswise on a hill, the vehicle can lose its hold, slide sideways, tip or turn
over and roll down the hill.
x Make certain that the wheels on the downhill side of the vehicle do not run over holes or
depressions. Make certain that the wheels on the high side of the vehicle do not run over
rocks, tree stumps, or protruding objects.
x Before driving crosswise on a hill, check whether it is possible to steer into the fall line
along the selected route. If this is not possible, select a different route. If the vehicle
threatens to tip, immediately steer downhill into the fall line and gently accelerate ⇒ fig. .
x If the vehicle is stopped a hillside and is laterally tilted, avoid sudden and uncontrolled
movement in the vehicle The vehicle can lose its hold, slide sideways, tip, or turn over and
roll down the hill.
x If the vehicle is stopped at while pointed crosswise on a steep slope, make certain that no
one exits the vehicle through a door on the downhill side. This can shift the vehicle center of
gravity to the downhill side. The can tilt or roll over and roll down the hill. To help minimize
this risk, always exit the vehicle through the doors that are facing uphill ⇒ fig. .
x When getting out, make certain that doors opened on the uphill side are not closed
carelessly and do not swing shut due to their own weight and injure anybody.
Avoiding deep ruts and depressions

WARNING
The engine compartment of any motor vehicle is a potentially dangerous area and can cause
serious personal injury.
x Always use extreme caution when doing any work in the engine compartment. Always
follow commonly accepted safety practices and use common sense. Never risk personal
injury.
x Never perform any work in the engine compartment unless you know exactly how to carry
out the job and have the correct technical information and the correct tools.
x If you are uncertain about what to do, have the work performed by an authorized
Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified
workshop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID - High Intensity Discharge (Xenon)
lights and H7/H15 bulbs replaced by a qualified technician. Serious personal injury may result
from improperly performed work.
x Never open or close the engine hood if steam or coolant is escaping. Hot steam or coolant
can cause serious burns. Always wait until you no longer see or hear steam or coolant
escaping from the engine.
x Always let the engine cool down completely before carefully opening the hood.
x Hot parts of the engine and the exhaust system will burn skin on contact.
x When the engine has cooled down and you are ready to open the hood:
– Firmly apply the parking brake and shift the transmission into Park (P) (automatic) or
Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the remote control vehicle key is out
of range of the vehicle and that the vehicle cannot be started by depressing the starter
button.
– Always keep children and others away from the engine compartment and never leave
them unsupervised.
x The engine coolant system is under pressure when the engine is hot. Never unscrew the
coolant expansion tank cap when the engine is hot. Hot coolant can spray out and cause
severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclockwise direction while applying
light downward pressure on the top of the cap.
– Always protect your face, hands, and arms from hot escaping coolant or steam by
covering the cap with a large, thick rag.
x Never spill fluids on the engine or exhaust system when refilling. Spilling fluids onto hot
parts of the engine or exhaust system can cause a fire.
WARNING
High voltage systems in the engine compartment can cause electrical shocks or even
electrocution, severe burns, other serious injuries, and even death!
x Never short-circuit the electrical system. Be especially careful when using jumper cables.
The vehicle's battery could explode!
x To reduce the risk of electrical shock and personal injury while the engine is running or
being started:
– Never touch ignition cables. Never touch other components of the high voltage
electronic ignition system.
– Never touch the wiring of the HID - High Intensity Discharge (Xenon) headlights.

Lights up Possible cause Proper response

Flashes
Temperature
gauge needle
⇒ fig.
Possible cause Proper response
(B)
Normal range
Engine coolant level too
low.
Check the engine coolant level after the
engine has cooled down and add engine
coolant if low
If the engine coolant level is correct or the
problem continues after adding coolant, do
not drive any farther. Contact an
authorized Volkswagen dealer or
authorized Volkswagen Service Facility.
These instructions apply only when the
coolant temperature stays in the normal
range. Stop immediately if the needle goes
into the red warning zone (C).
– Engine coolant system
malfunction.

WARNING
New tires or tires that are old, worn or damaged cannot provide maximum control and
braking performance.
x Improper care and handling of tires and wheels can reduce driving safety and cause
accidents and severe injuries.
x Install only radial tires of the same make, the same dimensions (tread circumference), and
similar tread profile on all 4 wheels.
x New tires tend to be slippery and must be broken in. Always drive with special care for the
first miles ( km) to help reduce the risk of losing control, a collision, and serious personal
injuries.
x Check tire inflation pressure regularly when the tires are cold and always maintain the
prescribed tire pressure. Low tire pressure can cause tires to get too hot, resulting in tread
separation, sudden loss of pressure, and blowouts. Tires with excessively low pressure flex
(bend) more, which can cause the tire to overheat and fail suddenly without warning.
x Check tires regularly for wear and damage.
x Never drive with worn or damaged tires (for example, tires with punctures, cuts, cracks,
blisters, or bumps). Driving with worn or damaged tires can lead to loss of vehicle control,
sudden tire failure including blowouts and sudden deflation, crashes, and serious personal
injuries.
x Have worn or damaged tires replaced immediately.
x Never exceed the maximum speed rating or the maximum load rating of the tires on your
vehicle.
x The effectiveness of the driver assistance systems and the braking support systems
depends on the tire traction.
x If you notice unusual vibration or if the vehicle pulls to one side when driving, always stop
as soon as it is safe to do so and check the wheels and tires for damage.
x To reduce the risk of losing control, crashes, and serious personal injuries, never loosen
the bolts on wheels with bolted rim rings.
x Never mount used tires on your vehicle if you are not sure of their past use. Old, used
tires and wheels may have damage that cannot be seen that can lead to sudden tire failure
and loss of vehicle control.
x Tires age even if they are not being used and can fail suddenly, especially at high speeds,
causing loss of vehicle control, accidents, and severe personal injuries. Tires that are more
than 6 years old can be used only in an emergency and even then only with special care and
at low speed.
For technical reasons it is usually not possible to use wheel rims from other vehicles. Even wheel
rims from the same model may not fit properly. Check with an authorized Volkswagen dealer or
authorized Volkswagen Service Facility if necessary.

Rotating tires
To help ensure even wear on all tires, regular tire rotation according to the diagram ⇒ fig. is
recommended. In this way all tires can have about the same service life.
Volkswagen recommends that you have your tires rotated by an authorized Volkswagen dealer or
authorized Volkswagen Service Facility.
Tires more than 6 years old
Tires age even if they are not being used. Physical and chemical processes reduce tire strength and
performance and cause them to harden and become brittle. Old tires can fail suddenly and without
warning.
Volkswagen recommends replacing tires that are 6 years and older. This also applies to tires that look
new (including the tire on the compact spare wheel) or that seem to still be usable with tread depth
that has not yet reached the legal minimum depth ⇒ .
The age of each tire can be determined with the manufacturing date that is part of the U.S. DOT tire
identification number (TIN)
Tire storage
Mark tires before removing them to help make sure that the previous location (left, right, front, rear)
and rolling direction can be maintained when remounting them. Store tires in a cool, dry and preferably
dark place. Do not store tires mounted on wheels standing up.
Tires not mounted on wheels should be covered to help protect them from dirt and stored vertically
(sitting on the tread).
WARNING
Aggressive fluids and materials can cause visible and invisible tire damage that can cause
tire blowouts.
x Always keep chemicals, oils, grease, fuels, braking fluids and other aggressive
substances away from tires.
WARNING
Tires age even if they are not being used and can fail suddenly, especially at high speeds,
causing loss of vehicle control, accidents, and severe personal injuries.
x Tires that are more than 6 years old can be used only in an emergency and even then only
with special care and at low speed.
Always dispose of old tires in accordance with legal requirements.
Wheel rims

Wear indicators show when the tires are worn down. The tires must be replaced no later than when
the tread pattern is worn down to the wear indicators.
WARNING
Worn tires are dangerous and can cause loss of vehicle control including serious personal
injuries.
x Never drive a vehicle when the tread on any tire is worn down to the wear indicators,
replace them sooner.
x Worn tires do not grip the road properly, especially on wet roads, increasing your risk of
“hydroplaning” and loss of control.
x Worn tires reduce the ability of your vehicle to handle well in normal and difficult driving
situations and increase braking distances and the risk of skidding.
Tire wear and damage

WARNING
Improper use of a compact spare tire can cause loss of vehicle control, a crash or other
accident, and serious personal injury.
x Never use a compact spare tire if it is damaged or worn down to the wear indicators.
x In some vehicles, the compact spare tire is smaller than the original tire. A smaller
compact spare tire is identified with a sticker and the words “50 mph” or “80 km/h”. This is
the maximum permissible speed when driving with this tire.
x Never drive faster than 50 mph (80 km/h) with a compact spare tire. Avoid full-throttle
acceleration, heavy braking, and fast cornering!
x Never drive more than miles ( km) if a compact spare wheel is installed on the front axle
(drive axle).
x Replace the compact spare with a normal wheel and tire as soon as possible. Compact
spare tires are designed for brief use only.
x Regularly check the U.S. DOT Tire Identification Number (TIN) to determine the age of the
compact spare tire
x Tires age even if they are not being used and can fail suddenly, especially at higher
speeds.
x Tires that are more than 6 years old can only be used in an emergency and then with
special care and at low speeds.
x The compact spare tire must always be secured with the wheel bolts provided by the
factory.
x Never drive using more than one compact spare wheel.
x After installing the compact spare tire, the tire pressure must be checked as soon as
possible
x Snow chains cannot be used on the compact wheel tire. If you must use snow chains and
have a compact spare wheel mounted, move the compact spare tire to the rear axle if a front
tire has to be replaced. The tire taken off the rear axle can then be used to replace the flat
front tire. Be sure you do not change the tire's direction of rotation. Install the snow chains
on the full-sized road tire.
NOTICE
When the spare wheel or compact spare is being used, the TPMS indicator light can start
flashing after about 10 minutes.
If possible, attach the compact spare tire or the tire you took off the vehicle securely in the
luggage compartment.
