2013 VOLKSWAGEN TIGUAN check engine

WARNING
Inadequate experience and knowledge of the demands of off-road driving can lead to critical
situations and cause serious personal injury.
x Never take routes or risks that could put you or your passengers in danger. If you cannot
go on, or have doubts about the safety of your route, turn back and take a new route.
x The intelligent technology of the vehicle cannot change the laws of physics. Despite the
ABS, adverse terrain can cause instability through blocked wheels – for example, if you brake
hard when driving on a loose gravel road. Difficult terrain may also prevent the ESC from
doing its job.
x Never operate the vehicle at the limit of its performance ability. Always leave a good safety
margin.
x To reduce the risk of loss of control and serious personal injury, never use the cruise
control when driving off-road.
x Even terrain that looks easy can be difficult and dangerous, putting you and your
passengers in a critical situation. It is often best to check an area out on foot first.
x Drive with special care and think ahead in off-road terrain. If you drive too fast, or fail to
maneuver the vehicle properly, you could cause personal injury and damage the vehicle.
x Never drive faster than is appropriate for the prevailing terrain and the road, traffic, and
weather conditions.
x Never drive too fast across embankments, ramps, or slopes. The vehicle could become
airborne. If that happens, you will not be able to steer and can lose control.
x If your vehicle becomes airborne, always keep the front wheels pointing straight ahead. If
the wheels are not pointing straight ahead when the vehicle lands, it could roll over.
x Never allow people to stand in front of or behind the vehicle if you have put items such as
stones or pieces of wood under the wheels to improve traction on slippery ground. Spinning
wheels can turn these items into dangerous flying objects causing serious personal injury.
x Even areas that look harmless can be dangerous. Potholes, ditches, trenches, drop-offs,
different kinds of obstacles, and soft or swampy ground often cannot be seen and can be
partially or fully covered by water, grass, branches, or other things. Driving over such terrain
can cause accidents and severe injuries. Before crossing an unknown area, carefully explore
the route you plan to take on foot.
WARNING
Never drive off-road if you are low on fuel. Too little fuel in the tank can cause an accident
and serious injuries. You can also run out of fuel in a remote area where getting help is
difficult or impossible.
x When the fuel tank is almost empty, fuel supply to the engine can be interrupted,
especially when driving over bumps, across slopes, and up and down hills. The interruption
in fuel flow could stall the engine during a maneuver in difficult terrain and make you lose
control of the vehicle.
x Steering and braking assistance as well as ESC and related systems will not work if the
engine “sputters” or stalls due to lack of fuel. This can cause loss of vehicle control,
especially in difficult terrain.
x Always refuel when the tank is 1/4 full to reduce the risk of running out of fuel.
NOTICE
If the power sunroof or the windows are open when it rains or snows, the interior of the vehicle
will get wet and the vehicle may be damaged. Always keep the windows and the power sunroof
closed when driving off-road.

¥ Check tires, suspension struts, and axles for damage and remove coarse dirt, stones, and foreign
objects from the tire tread.
¥ Examine the vehicle underbody and remove objects such as twigs, leaves, or bits of wood that
have gotten stuck in the brake system, the wheels, the suspension, the exhaust system, of the
engine ⇒ . If damage or leaks are detected, see an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
¥ Remove coarse dirt from the radiator grille and the vehicle underbody, Exterior care and cleaning.
¥ Check the engine compartment to for dirt that interferes with engine operation

WARNING
Moving parts in the engine compartment can cause serious personal injury on contact.
x Never reach into the area around or touch the radiator fan. Contact with the blades can
cause serious personal injury. Always remember that the radiator fan is temperature-
controlled and can come on suddenly even when the engine has been switched off for a while
and the key has been removed from the ignition.
x If you have to perform a check or repair when the engine is running, there are more risks
from the rotating parts, such as the drive belts, alternator, radiator fan, etc., and from the
high-voltage ignition system. Always use extreme care.
– Always make sure that jewelry, loose clothing and long hair do not get caught in
rotating engine parts. Before starting any work remove your jewelry, take off your necktie,
tie back and cover your hair, and do not wear clothing that can hang down and get caught
in moving engine parts.
– Always use extreme caution if the accelerator pedal has to be depressed to perform a
check. The vehicle will start to move even if the electronic parking brake is on.
x Never leave any objects in the engine compartment, for example cleaning rags and tools.
Objects left behind can cause malfunctions, engine damage, and even fires.
WARNING
Operating fluids and some materials in the engine compartment can catch fire easily, causing
burns and other serious personal injuries!
x Do not smoke.
x Never work next to open flames or sparks.
x Never pour or spill operating fluids or other flammable liquids on the engine. These fluids
can ignite on hot engine parts and cause injuries.
x If work on the fuel system or the electrical system is necessary:
– Always disconnect the 12 Volt vehicle battery. Make sure the vehicle is unlocked when
you disconnect the battery, or the alarm will go off. Never touch the electrical wiring of the
ignition system.
– Never work near heaters, water heaters, or other open flames.
x Always have a functional, approved fire extinguisher nearby.
NOTICE
When changing or topping off fluids, make sure that you pour the fluids into the correct
reservoirs. Adding the wrong type of operating fluids will cause serious malfunctions and
engine damage.
Fluid leaks are harmful to the environment. Regularly check the ground underneath your vehicle
for this reason. If you find spots of oil or other fluids, have your vehicle checked by your authorized
Volkswagen dealer or authorized Volkswagen Service Facility. Dispose of leaked operating fluids
properly.
Warning light

When the hood is properly closed, you can see that it fits flush with the other body parts. The indicator
light in the instrument cluster will go out
WARNING
If the hood is not closed properly, it could fly up and block your view while you are driving.
This can lead to a crash and serious personal injuries.
x After closing the engine hood, check that the hood release lever is properly latched into
the hood latch. The engine hood must be flush with the surrounding auto body parts.
x If you ever notice that the hood latch is not properly secured when the vehicle is moving,
stop at once and close it.
x Never let anyone get in the way of the hood when closing it.
NOTICE
x Make sure the windshield wiper arms are resting on the windshield before you open the
hood. Otherwise, the windshield wipers and the hood may be damaged.
x Always put the windshield wiper arms down against the windshield before driving the
vehicle.
NOTICE
Before opening or closing the engine hood, make sure there is enough room to do so, for
example when the vehicle is in a garage.

Flashes
Temperature
gauge needle
⇒ fig.
Possible cause Proper response
(B)
Normal range
Engine coolant level too
low.
Check the engine coolant level after the
engine has cooled down and add engine
coolant if low
If the engine coolant level is correct or the
problem continues after adding coolant, do
not drive any farther. Contact an
authorized Volkswagen dealer or
authorized Volkswagen Service Facility.
These instructions apply only when the
coolant temperature stays in the normal
range. Stop immediately if the needle goes
into the red warning zone (C).
– Engine coolant system
malfunction.

Lights
up Possible cause Proper response
B
Engine control/monitoring system
malfunction (engine Malfunction Indicator
Light - MIL).
Ease off the accelerator. Carefully drive to the
nearest authorized Volkswagen dealer or
authorized Volkswagen Service Facility. Have
engine checked.


Flashes Possible cause Proper response
B Misfire, which can damage the catalytic
converter.
Ease off the accelerator. Carefully drive to the
nearest authorized Volkswagen dealer or
authorized Volkswagen Service Facility. Have
engine checked.

When the ignition is switched on, several warning and indicator lights come on briefly for a function
check. They go out after a few seconds.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
As long as the indicator lights x or EPC are on, expect engine malfunctions, increased fuel
consumption and loss of engine efficiency.
Catalytic Converter

Frequently asked questions
If you suspect a malfunction or vehicle damage, read and follow the following advice before contacting
an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. You may also find
helpful information under “Characteristics” and “Checklist” in the index.

Description Possible causes among
others Possible remedy
Engine does not start.
Vehicle battery dead. – Perform jump start
– Charge vehicle battery
The wrong remote control
vehicle key is used.
Use a valid remote control vehicle key

Fuel level too low. Refuel
Vehicle cannot be locked
or unlocked using remote
control vehicle key.
– Battery in remote control
vehicle key dead.
– Too far away from vehicle.
– Buttons pressed outside
operating range.
– Replace battery in the remote control
key
– Move closer to vehicle.
– Synchronize remote control vehicle
key
– Lock or unlock vehicle manually
Unusual noises.
Cold engine, braking support
systems, electronic parking
brake.
Check the “Noises” entry in the
keyword index.
Driver seat and outside
mirrors when vehicle is
unlocked.
Convenience settings are
stored. Correct convenience settings
Memory-seat settings are
stored.
– Reassign seat setting
– Clear memory-seat memory
Front seats cannot be
adjusted with power
controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if necessary
Features do not work as
described in this manual.
Settings were adjusted in the
Volkswagen Information
System.
Check and reset to factory settings if
necessary
Headlights do not light up
the road as they should.
– Headlights incorrectly
adjusted.
– Light bulbs burned out.
– Low beams not switched on.
Have the headlight range adjusted by
an authorized Volkswagen dealer or an
authorized Volkswagen Service
Facility. Adjust headlight range .
– Change light bulbs
– Switch on low beams
Electrical consumers do
not work.
Vehicle battery charge too low. Charge vehicle battery
Remaining fuel level too low. Refuel .
Fuse blown. Check fuse and replace if necessary

Fuel consumption higher
than indicated.
– Short hauls.
– “Jumpy gas pedal”.
– Avoid short distance driving.
– Drive defensively.
– Accelerate smoothly.
Electrical loads switched on. Switch off unnecessary loads.
Engine control malfunctioning. Have the malfunction corrected

Description Possible causes among
others Possible remedy
Tire pressure too low. Adjust tire pressure
Driving in the mountains. No direct corrective action possible.
Towing a trailer or driving with
a roof rack.
– Check use.
– Remove if not in use.
Driving with heavy payload. No direct corrective action possible.
Driving at high engine speed. Select a higher gear.
