2013 VOLKSWAGEN JETTA SPORTWAGEN Owners Manual

Turn signal lever and high beam switch

Fig. 84 Turn signal lever and high beam switch.

WARNING
Improper use of high beams can distract and blind others, causing accidents and serious
injuries.
The turn signal light works only when the ignition is switched on. The emergency flasher works
even when the ignition is switched off .
The indicator light flashes twice as fast if a turn signal bulb is burned out.
High beams can only be switched on when the low beams are on.
Switching lights on and off

Fig. 85 Headlight switch next to the steering wheel.

Fig. 86 Headlight switch next to the steering wheel (with fog lights).

Adjust the light switch to the desired position ⇒ fig. 85 or ⇒ fig. 86:
Symbol When the ignition is switched off When the ignition is switched on
 Low beams switched off. The DRL may
stay on. The length of time they stay on
depends on the vehicle battery charge.
Low beams switched on.
Fog lights switched off. The DRL may
stay on for some time. Headlights and fog lights switched on.

Fog lights
The indicator light in the headlight switch or the instrument cluster shows that the fog lights are
switched on.
x To switch on the fog lights : first turn the light switch to position , then pull the light switch out
to the first detent.
x To switch off the fog lights, push the switch back in from the first detent. To then turn off the
headlights, turn the switch to position O.
Acoustic warning when lights are not switched off
In the following situation, a warning chime will sound if you take the key out of the ignition and open
the driver door. This is to remind you that lights are still on.
x Light switch in position .
WARNING
Daytime running lights are not bright enough to let you see ahead or be seen by others when
it is dark.
x Always switch on the low-beam headlights at dusk or when it is dark and whenever the
weather is bad or visibility is poor.
x Never use the daytime running lights to see where you are going. They are not bright
enough and will not let you see far enough ahead for safety, especially at dusk or when it is
dark. Always switch on the low-beam headlights at dusk or when it is dark.
x The taillights do not come on with the daytime running lights. Unless the taillights are on,
a vehicle cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in the United States
Lights and vision features

The daytime running lights are switched on whenever the ignition is switched on and the light switch is
in position O. The indicator light  or $2, may come on in the instrument cluster to indicate that the
feature is active
Daytime running lights (DRL) parking feature
Some models are equipped with a daytime running lights (DRL) parking feature that switches the
daytime running lights off when the vehicle is parked and the ignition is switched on.

Function Action
Switching the DRL off: – Switch the ignition on.
– Turn the light switch to the O position.
– Set the parking brake.
Switching the DRL back on: – Release the parking brake.

Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static
cornering lights. On some models the static cornering lights may be integrated in the headlights. At
speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on automatically
when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog
light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. The static cornering lights do not
come on when the headlight switch is in the O position or when the fog lights themselves have been
switched on .
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Applicable only in Canada
Lights and vision features

When the daytime running lights are switched on, only these separate lamps come on ⇒ .
The daytime running lights are switched on whenever the ignition is switched on and the light switch is
in position O. The indicator light  or $2, may come on in the instrument cluster to indicate that the
feature is active
Static cornering lights
Your vehicle may have fog lights under the front bumper, which on some models are also static
cornering lights. On some models the static cornering lights may be integrated in the headlights. At
speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on automatically
when you turn a corner. If you turn to the right, the right fog light comes on; turn left and the left fog
light comes on. The light dims and goes out when the steering wheel is straightened out again.
When you move the selector lever to Reverse (R), the static cornering lights on both sides of the
vehicle may come on so that you can see the area around the vehicle better when backing up.
The static cornering lights work only when the headlights are on. The static cornering lights do not
come on when the headlight switch is in the O position or when the fog lights themselves have been
switched on .
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
x Never use daytime running lights (DRL) to see where you are going. DRL are not bright
enough to light up the roadway and be seen by other motorists. You will not be able to see far
enough ahead for safety, especially at dusk or when it is dark. Always switch on the low-
beam headlights at dusk or when it is dark.
x The taillights do not come on when the daytime running lights are switched on. A vehicle
without taillights on cannot be seen by others in bad weather, at dusk, or when it is dark.
In cool or humid weather, the insides of the headlights, the rear lights, and turn signals can
temporarily fog up. This is normal and does not affect the service life of the vehicle's lighting system.
Instrument panel lighting

Fig. 87 To the left of the steering wheel: Thumbwheel to adjust instrument panel lighting 1.

Instrument panel lighting
When the lights are on, the brightness of the instrument panel lighting is adjusted by turning the
thumbwheel ⇒ fig. 87 (1).
Instrument cluster brightness
When the lights are on, the brightness of the instrument cluster lighting is adjusted by turning the
thumbwheel (1).
In some vehicles with daytime running lights (DRL), the instrument cluster lighting switches on
automatically when it is dark outside or when driving through tunnels, for example. You will need to
switch the headlights on manually when this happens, so that the vehicle's taillights will turn on , .
WARNING
Headlights that are aimed too high because of the way the vehicle is loaded can blind and
distract other drivers. This can lead to a crash and serious personal injuries.
x Always make sure the headlights are adjusted to loading conditions so that they do not
blind others.
Interior and reading lights

Sun protection

Windshield made of heat-insulating glass

Fig. 89 Heat-reflective windshield with communications window (blue shaded area).
