Page 4 of 321
Passenger compartment
Driver door overview
Fig. 4 Overview of controls in the driver door.
Key to fig. 4:
(1) Door handle
(2) Power locking button for locking and unlocking the vehicle 1 – 0
(3) Indicator for power locking system
(4) Switch for adjusting the outside mirror
– Adjusting outside mirrors , – / – 2
– Outside mirror heating ?
(5) Buttons for operating the power windows
– Power windows
– Safety switch for rear power windows _
(6) Lever for releasing the engine hood
(7) Bottle holder
(8) Storage compartment
(9) Reflector
Page 12 of 321
Instrument explanations ⇒ fig. 11:
(1) Button for setting the instrument cluster clock1.
– With the ignition on, push the
Page 13 of 321
Instrument explanations ⇒ fig. 12:
(1) Button for setting the instrument cluster clock2.
– With the ignition on, push the
Page 25 of 321
Convenience
menu Function
Driver
Manual unlocking: The driver window opens when the key is
held in the unlocking position.
Manual locking: All windows close when the key is held in the
locking position.
Keyless Access: All windows close when the locking sensor
on the door handle is pressed and held .
Back The display switches back to the Convenience menu.
Mirror adjust
IndividuallyBoth outside mirrors are adjusted separately.
Both mirrorsThe front passenger outside mirror is adjusted at the same
time as the driver outside mirror.
Back The display switches back to the Convenience menu.
Factory
setting Resets the features in the Convenience submenu back to the factory settings.
Back The display returns to the Settings menu.
Lights & Vision submenu
Page 34 of 321
Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or
call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from
transmitters near the vehicle that use the same frequency range (such as radio equipment or cellular
phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons 46 or the power locking buttons 47 are pushed
repeatedly in quick succession, the power locking system is switched off for a brief period to help keep
it from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear
hatch is opened in this span of time, the vehicle is automatically locked afterwards.
Mechanical key
Fig. 20 Mechanical key.
Page 37 of 321
Power locking and closing system
Page 38 of 321
Description of the power locking system
Page 39 of 321
overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear hatch is
opened during this time, the vehicle is automatically locked afterwards.
Unlocking or locking the vehicle from the outside
Fig. 24 Remote control vehicle key with panic button.
