2013 VOLKSWAGEN GOLF Max gb

Maximum power
output (SAE net)
Injection
technology
Engine
ID
code
Maximum torque (SAE net) No. of cylinders
Displacement
170 hp at 5700 rpm
(125 kW at
5700 rpm)
CBTA
CBUA
2.5L
177 lb-ft at 4250 rpm
(240 Nm at 4250 rpm)
5 cylinders
151 CID
(2480 ccm)
256 hp at 6000 rpm
(188 kW at
6000 rpm)
TSI® CRZA
2.0L
243 lb-ft at 2,400 – 5,200 rpm
(330 Nm at 2400 – 5200 rpm)
4 cylinders
121 CID
(1984 ccm)

Diesel engines

Maximum power
output (SAE net)
Injection
technology
Engine
code
Maximum torque No. of cylinders
Displacement
140 hp at 4,000 rpm
(103 kW at 4,000 rpm
with DPF)
TDI® CJAA
2.0L
236 lb-ft at 1750 rpm
(320 Nm at 1750 rpm)
4 cylinders
120 CID
(1968 ccm)

Dimensions

x If the outside temperature or the temperature inside the passenger compartment is 77 °F (25 °C) or
more.

Function Action for seat heating ⇒fig.46
Switch on: Press the Aor ebutton. Seat heating is
switched on to maximum.
Adjust the heating level: Press the A or ebutton repeatedly until the
desired heating level is set.
Switch off: Press the A or ebutton repeatedly until all
indicator lights in the button are off.

Special seat heating features
On the driver and the passenger side, the seat heating will resume at the setting that was set when the
ignition was switched off. However, this feature only works if the key is not taken out of the ignition
switch, or, for vehicles with Keyless Access, the driver door is not opened or the vehicle is not locked.
People suffering from a low level of perceived pain or a lowered awareness of pain as from
medication, paralysis, or chronic illness (e.g. diabetes) should NEVER use the seat heating feature
⇒ !
The use of seat heating by persons with these conditions could result in burns to the back, buttocks,
and legs that may take a long time to heal and may never heal completely. If you have any of these
conditions, you should take regular breaks and get out of the vehicle, particularly on long trips. Consult
your doctor for advice regarding your specific condition.
WARNING
Certain medical conditions, such as paralysis and diabetes, and certain medications can
increase the risk of serious burns when the seat heating feature is switched on.
x Vehicle occupants who have a low level of perceived pain or a lowered awareness of pain
can receive serious burns to the back, buttocks, and legs that take a long time to heal or may
never heal completely.
x Never use the seat heating feature if you or your passengers are at risk of being burned
because of a medical condition. Take regular breaks and get out of the vehicle, particularly
on long trips. Consult your doctor for advice regarding your specific condition.
x Never let exposed skin remain in contact with the seat upholstery when the seat heating is
being used.
WARNING
A wet seat can cause the seat heating to malfunction and increase the risk of serious burns.
x Always make sure the seats are dry before using the seat heating.
x Never sit on the seat with wet clothes.
x Never put damp or wet things including clothes on the seat.
x Never spill liquids on the seats.
NOTICE
x To help prevent damage to electrical and other parts in the seat, do not kneel on the front
seats or apply concentrated pressure to a small area of the seat or backrest.

Synchronous mirror adjustment
x In the Settings - Convenience menu, select Mirror adjust - Both mirrors for
synchronous outside mirror adjustment
x Turn the adjusting knob to the L position.
x Adjust the left outside mirror. The right (passenger) outside mirror will automatically adjust at the
same time.
x If needed, correct the position of the right mirror by turning the adjusting knob to the R position.
Auto-dimming outside mirror on the driver side
Some models are equipped with an auto-dimming outside mirror, which is controlled together with the
auto-dimming inside mirror
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base
when moving the mirrors.
WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and
serious injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision.
But vehicles or other objects seen in a convex mirror will look smaller and farther away than
they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when
changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of
vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by
pressing on the edges of the mirror surface.

x Hitch weight and tongue weight for trailer towing.
Please refer to the Gross Vehicle Weight Rating (GVWR) and the Gross front and rear Axle Weight
Ratings (GAWR) for your vehicle, which are printed on the vehicle's Safety Compliance Certification
Label on the driver door jamb.
WARNING
Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and
serious personal injury.
x Never let the actual weights at the front and rear axles exceed the permissible Gross Axle
Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle
Weight Rating.
x Always remember that the vehicle's handling and braking will be affected by extra load
and the distribution of this load. Adjust your speed accordingly.
NOTICE
x Always distribute the load evenly and as low as possible in the vehicle. The vehicle capacity
weight figures apply when the load is distributed evenly in the vehicle (passengers and
luggage).
x When transporting a heavy load in the luggage compartment, carry the load as close to the
rear axle (as far forward) as possible so that the vehicle's handling and braking are affected as
little as possible.

WARNING
Elastic straps have to be stretched when being attached to the tie-downs in the luggage
compartment. Hooks on these straps can cause serious personal injury if not handled
properly and attached securely.
x Always protect eyes and face from injury from hooks when attaching them to the tie-
downs in the luggage compartment.
x Always hold the hooks on elastic straps firmly when attaching to the vehicle and do not let
them snap back and hit you.
x First attach the hooks on the straps to the tie-downs at the rear seat backrest in the
luggage compartment and then to the tie-downs near the loading edge of the luggage
compartment. This way, if one of the hooks on the elastic straps snaps back, it will move
away from you, decreasing the risk of personal injury.
The maximum load for the tie-downs is about 380 lbs. (172 kg).
For suitable straps and luggage stowage systems, please see an authorized Volkswagen dealer
or authorized Volkswagen Service Facility.
Shopping bag hooks

Fig. 102 In the luggage compartment: Shopping bag hooks.

Maximum power consumption for the trailer
Do not exceed the power ratings listed in the chart below.

Electrical load Maximum power
Brake lights total 108 watts
Turn signals per side 54 watts
Side marker lights total 100 watts
Taillights total 54 watts

WARNING
x An improperly installed or incorrect trailer hitch can cause a trailer to separate from the
tow vehicle and cause serious personal injuries.
x If you don't have to tow a trailer any more, remove the entire trailer hitch. Always seal all
bolt holes to prevent water and deadly exhaust fumes from getting into the vehicle.
NOTICE
x If the trailer lights are not connected properly, the vehicle's electronics may be damaged.
x If the trailer uses too much electricity, the vehicle's electronics may be damaged.
x Never connect the electrical system for the trailer directly to the electrical connections for
the rear lights or to any other unsuitable power sources. Use only a suitable connector to
provide power to the trailer.
If you tow a trailer frequently, Volkswagen recommends having the vehicle serviced between the
regular maintenance and inspection intervals because of the extra load it has to pull.
Hitching up and connecting a trailer

Loading the trailer
The weight distribution in the vehicle and trailer must be balanced. Use the maximum permissible
tongue weight and make sure that the load in the trailer is evenly distributed and that it is not front-
heavy or tail-heavy:
x Distribute the load in the trailer so that heavy objects are directly above the axle or as close as
possible to the axle.
x Secure loads properly on the trailer.
Tire pressure
Always follow the trailer manufacturer's tire pressure recommendations for the trailer tires.
When towing, inflate the towing vehicle's tires to the maximum permissible pressure listed on the tire
pressure label
WARNING
Exceeding the gross weight ratings for axle, tongue, vehicle, trailer or combined weight can
cause accidents and serious personal injury.
x Never exceed the specified values.
x Never let the actual weights at the front and rear axles exceed the Gross Axle Weight
Rating. Never let the combined front and rear weights exceed the Gross Vehicle Weight
Rating.
WARNING
Trailer loads that are not properly secured can shift when the vehicle is moving or braking
and suddenly change the way the vehicle handles, causing accidents and severe injuries.
x Always load the trailer properly.
x Always secure the load properly with suitable, undamaged straps that can be tightened so
that the load cannot shift.
Driving with a trailer

CAUTION
The ball mount sticks out behind the rear bumper and can cause injury to pedestrians and
cyclists.
x To reduce the risk of injury in rear-end collisions, and the risk to pedestrians and cyclists
when the vehicle is parked, always remove the ball carrier when you are not towing a trailer.
NOTICE
x Never use a ball larger than 11/4 inches (32 mm) on your vehicle. The vehicle was not
designed to tow heavier trailers with a receiver larger than the specified ball. The increased
loads can damage the attachment points for the trailer hitch.
x Never use an adapter to increase the size of the trailer hitch receiver from 11/4 inches
(32 mm) to 2 inches (50.8 mm) or more to tow a trailer that is heavier than the maximum
permissible trailer weight that your vehicle can tow.
x You can use an adapter if required for the proper installation of a bicycle rack or other
similar carrier as long as the maximum weight limits are observed. When using bicycle racks
or similar carriers, make sure that the rear lights are not blocked.
x Only use trailer hitches that are approved by the hitch manufacturer for your vehicle and
model.
