Removing the front head restraints
x Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the
way up ⇒  in Adjusting the front and rear head restraints. Recline the backrest with the head
restraint so that there is enough overhead clearance to remove it.
x Slide a flat object, such as a plastic credit card, underneath the right side of the cap on the right-
hand seat guide rod ⇒ fig. 41 (1) to unlock the head restraint.
x Push the flat object (plastic card) in against the guide rod to depress a release button located
under the cap (not visible).
x Use one hand to hold the release button in with the flat object. With your other hand, lift the same
guide rod slightly to expose a notch in the rod at the bottom (can be seen and felt with fingers). The
right-hand guide rod is now released.
x To release the left-hand guide rod, press button (2) in (towards guide rod) and hold.
x Pull the head restraint out completely while holding button (2).
Installing the front head restraints
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Move the seat backrest into an upright position.
x Adjust the head restraint according to the occupant's size .
Removing the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward
x Pull the head restraint all the way up ⇒ .
x If necessary, press the flat blade of the screwdriver from the vehicle tool kit into the slit of the trim
cap ⇒ fig. 42 (1) in the direction of the arrow and hold it in this position.
x At the same time press button (2) while a second person pulls out the head restraint completely.
x Fold the backrest of the rear seat bench back so that it locks securely.
Reinstalling the rear head restraint
x Unlock the backrest of the rear seat bench and fold it forward
x Position head restraint properly over the head restraint guides of the respective seat backrest and
insert the head restraint into the guides.
x Push the head restraint down while pressing button (2).
x Fold the backrest of the rear seat bench back so that it locks securely.
x Adjust the head restraint according to the occupant's size
WARNING
Driving without head restraints or with improperly adjusted head restraints increases the risk
of serious injuries in a collision.
x Always drive with the head restraints in place and properly adjusted to help minimize the
risk of neck injury in crash.
x Always reinstall head restraints as soon as possible so that vehicle occupants are
properly protected.

Tires and wheels
Introduction
In this section you’ll find information about:
Tire and wheel handling
Wheel rims
New and replacement tires
Tire inflation pressure
Tire inflation pressure in cold tires
Tire inflation pressure in cold tires
Tread depth and tread wear indicators
Tire wear and damage
Spare wheel or compact spare wheel
Tire labeling
Winter tires
Snow chains
Glossary of tire and loading terminology
Tires and vehicle load limits
Determining the correct load limit
Volkswagen recommends that all work on tires and wheels be done by an authorized Volkswagen
dealer or authorized Volkswagen Service Facility. They are familiar with the technical requirements
and recommended procedures, have the necessary special tools and spare parts, and can properly
dispose of old tires.
More information:
x Transporting
x Trailer towing
x Braking, stopping and parking
x Tire Pressure Monitoring System
x Exterior care and cleaning
x Vehicle tool kit
x Consumer information
x Wheel covers
x Changing a wheel

Stowing the replaced wheel
x Hook the floor covering on the upper edge of the luggage compartment.
x Put the wheel you took off the vehicle into the spare wheel well so that the center hole of the rim is
aligned with the threaded pin.
x Turn the handwheel clockwise until the wheel replaced is securely in place.
x If necessary, return the vehicle tool kit to its location in the luggage compartment.
x Unhook the floor covering and fold it back down onto the floor of the luggage compartment.
x Close the rear hatch.
If the spare wheel is different from the road wheels
If the spare is different from the road wheels, a compact spare wheel, for example, or if the road
wheels are winter tires, the spare wheel must be used only in the event of a flat tire, only for a brief
time, and only when driving with extra caution ⇒ .
Replace it with a tire matching the others on your vehicle as soon as possible.
Please heed the following:
x Do not drive faster than 50 mph (80 km/h)!
x Avoid full-throttle acceleration, hard braking and fast cornering!
x Do not use snow chains on the compact spare wheel
x After installing the spare wheel or compact spare wheel, check the tire pressure as soon as
possible
Check the tire inflation pressure of the spare or compact spare whenever you check the tire pressure
of the road wheels, at least once a month. Inflate a spare wheel to the cold tire pressure specified for
the vehicle's road wheels on the tire pressure label; inflate a compact spare wheel to the cold tire
pressure specified for the compact spare on the tire pressure label or on a separate label for the
compact spare, if there is one.

In an emergency
Introduction
In this section you’ll find information about:
Protecting yourself and the vehicle
More information:
x Braking, stopping and parking
x Emergency closing and opening
x Vehicle tool kit
x Changing a wheel
WARNING
A vehicle breakdown in traffic is dangerous and creates a great risk for you, your
passengers, and others.
x Always stop the vehicle as soon as it is safe to do so. Move the vehicle a safe distance off
the road where it is safe to park and, if necessary, lock all doors in an emergency. Turn on
the emergency flashers and set up another warning device about 25 yards (25 meters) behind
the vehicle to warn approaching traffic.
x Never leave children, disabled persons, or anyone who cannot help themselves alone in
the vehicle when locking the doors. This could result in people being trapped in the vehicle in
an emergency. Depending on the time of year, people trapped in the vehicle can be exposed
to very high or very low temperatures.
Protecting yourself and the vehicle

Fig. 167 In the center of the instrument panel: Switch for emergency flashers.

In an emergency
Introduction
In this section you’ll find information about:
Protecting yourself and the vehicle
More information:
x Braking, stopping and parking
x Emergency closing and opening
x Vehicle tool kit
x Changing a wheel
WARNING
A vehicle breakdown in traffic is dangerous and creates a great risk for you, your
passengers, and others.
x Always stop the vehicle as soon as it is safe to do so. Move the vehicle a safe distance off
the road where it is safe to park and, if necessary, lock all doors in an emergency. Turn on
the emergency flashers and set up another warning device about 25 yards (25 meters) behind
the vehicle to warn approaching traffic.
x Never leave children, disabled persons, or anyone who cannot help themselves alone in
the vehicle when locking the doors. This could result in people being trapped in the vehicle in
an emergency. Depending on the time of year, people trapped in the vehicle can be exposed
to very high or very low temperatures.
Protecting yourself and the vehicle

Fig. 167 In the center of the instrument panel: Switch for emergency flashers.

Vehicle tool kit
Introduction
In this section you’ll find information about:
Storage
Contents
When securing the vehicle after a breakdown, always obey all applicable legal requirements.
More information:
x Trailer towing
x Preparations for working in the engine compartment
x In an emergency
x Changing a wheel
WARNING
Loose tools and other items in the vehicle tool kit and a loose spare (or compact spare) wheel
may be thrown through the passenger compartment if you brake suddenly or steer sharply or
are involved in an accident. This can cause severe injuries.
x Always make sure the vehicle tool kit and spare (or compact spare) wheel are securely
stowed in the luggage compartment.
WARNING
Improper or damaged vehicle tools can lead to accidents and injury.
x Never work with tools that are damaged or not right for the job.
Storage

Fig. 176 In the luggage compartment: Floor covering raised and 1 secured.

The vehicle tool kit, spare wheel, or compact spare wheel may be in one of several places under the
floor covering in the luggage compartment.
x If necessary, detach the luggage net
x Lift the floor covering and hang it on the hook beneath the luggage compartment cover ⇒ fig. 176
(1).
Completely retract the jack after use. Otherwise it will not fit in its compartment and cannot be
stowed safely.
Contents

Fig. 177 Contents of the vehicle tool kit.

Wheel covers
Introduction
In this section you’ll find information about:
Hubcaps
Wheel covers
Wheel bolt caps
More information:
x Exterior care and cleaning
x Vehicle tool kit
x Changing a wheel
WARNING
Unsuitable wheel covers and improper installation of wheel covers can cause accidents and
severe injuries.
x Improperly installed wheel covers can come loose while driving and endanger other
motorists and cyclists.
x Do not use damaged wheel covers.
x Always make sure that the flow of air for brake system cooling is not blocked or reduced
before installing wheel covers. This applies to both factory-installed wheel covers and
aftermarket wheel covers. Insufficient air supply may significantly increase stopping
distance.
NOTICE
To help prevent damage to the vehicle, be careful when removing wheel covers and be sure to
install them properly.
