2013 VOLKSWAGEN GOLF GTI Vehicle tool kit

x Take the wire clip out of the vehicle tool kit
x Insert the wire clip through the opening of the cover cap ⇒ fig. 181 and pull off in the direction of
the arrow.
The caps are designed to protect the wheel bolts and should be installed again after the wheel
change.
The anti-theft wheel bolt has a separate cap. This only fits the anti-theft wheel bolt, but not the
standard wheel bolts.

Changing a wheel
Introduction
In this section you’ll find information about:
Preparations for changing a wheel
Wheel bolts
Lifting the vehicle with the vehicle jack
Changing a wheel
After changing a wheel
Change a wheel by yourself only if the vehicle is parked in a safe location, you are familiar with safety
procedures and the technical steps, and you have proper tools available. Otherwise, get expert
assistance.
The vehicle jack can only be safely used to change the wheel on a vehicle that has only one flat or
damaged tire. If the vehicle does not have the support it needs from 3 fully inflated tires, the vehicle
can fall off the jack. If more than 1 tire on the vehicle is flat or damaged, do not lift the vehicle with the
vehicle jack. Instead, get expert assistance.
More information:
x Exterior views
x Vehicle key set
x Tires and wheels
x In an emergency
x Vehicle tool kit
x Wheel covers

Color Current strength in amps
Green 30
Orange 40

Opening the fuse box in the instrument panel
x Insert a flat object, such as a screwdriver from the vehicle tool kit, into the opening ⇒ fig. 187
(magnified view) and carefully lift off the cover.
x On the inside of the cover there are plastic tweezers (1) for removing and inserting fuses.
x To install, guide the cover from the bottom into the instrument panel and push until you can hear it
latch into place.
Opening the fuse box in the engine compartment
x Open the engine hood

Changing light bulbs
Introduction
In this section you’ll find information about:
Indicator light
Information on light bulb replacement
Changing headlight bulbs
Changing light bulbs in the front bumper
Changing taillight bulbs in the rear hatch
Changing taillight bulbs in the vehicle body
Changing license plate light bulbs
Changing a light bulb requires a certain amount of skill. If you are uncertain about how to proceed,
Volkswagen recommends having the light bulb changed by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility. Special training and knowledge are generally required when
other vehicle parts must be disassembled to replace a bulb, or when HID – High Intensity Discharge
(Xenon) headlights must be replaced.
You should always keep a box in the vehicle with all the replacement bulbs required for traffic safety.
Replacement bulbs are available from your authorized Volkswagen dealer or authorized Volkswagen
Service Facility. The laws of some countries explicitly require you to have replacement bulbs in the
vehicle.
Driving with outside lights that do not work may be against the law.
Additional light bulb specifications
Some factory-installed light bulbs in the headlights or the rear lights may have different specifications
than conventional light bulbs. Specifications are on the glass bulb or on the metal base.
More information:
x Exterior views
x Lights and Vision
x Preparations for working in the engine compartment
x Vehicle tool kit
x Fuses
WARNING
Crashes and other accidents can happen when you cannot see the road ahead and when you
cannot be seen by other motorists.
