2013 VOLKSWAGEN GOLF GTI Owners Manual

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions,
and serious personal injury.
x Never switch off the fan for a long time, because no fresh air will enter the passenger
compartment.
Applicable only in Canada
Controls

Fig. 143 In the center console: Manual AC controls.

Fig. 144 In the center console: Climatronic controls.

Buttons,
knobs More information: Manual AC ⇒ fig. 143, and Climatronic ⇒ fig. 144.

Buttons,
knobs More information: Manual AC ⇒ fig. 143, and Climatronic ⇒ fig. 144.
/&& Climatronic: Press /&& button or set the fan manually to 0. If the system is switched
off, an indicator light in the /&& button lights up.

WARNING
Stale air causes driver fatigue and reduces alertness, which can cause accidents, collisions,
and serious personal injury.
x Never switch off the fan for a long time, because no fresh air will enter the passenger
compartment.
Air conditioner operation

Air conditioner does not work
The air conditioner may not switch on for one of the following reasons:
x The engine is not running.
x The fan is switched off.
x The air conditioner fuse has blown.
x The outside air temperature is colder than about +38 °F (+3 °C).
x The air conditioner compressor has been temporarily switched off due to excessive engine coolant
temperature.
x There is another malfunction in the vehicle. Have the air conditioner checked by an authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
Special considerations
When it is very hot and humid outside, water condensation can drip from the air conditioner
evaporator and form a puddle under the vehicle. This is normal and does not indicate a leak.
The climate control system adjusts the passenger compartment temperature as fast as possible
considering the outside temperature.
Due to residual moisture in the air conditioner, the windshield may fog up after the engine is
started. Switch on the windshield defroster to help evaporate the condensation as quickly as possible.
The air coming out of the vents flows through the passenger compartment and through the vents
under the rear window. Do not cover these slots with clothing or other things.
Air vents

Fig. 145 In the instrument panel: Air vents.

NOTICE
Do not place food, medications, or other heat-sensitive things in front of the air vents. Food,
medications, and other things that are sensitive to heat or cold can be damaged or made
unusable by the air flow from the vents.
The air coming out of the vents flows through the passenger compartment and through vents
below the rear window. Do not cover these slots with clothing or other things.
Applicable only in the United States
Air recirculation

Applicable only in Canada
Air recirculation

Temporarily deactivating the automatic air recirculation

Refueling
Introduction
In this section you’ll find information about:
Indicator lights and fuel gauge
Refueling
Fuel capacities
Refueling checklist
The fuel filler flap is located on the rear right side of the vehicle.
More information:
x Exterior views
x Fuel
x Preparations for working in the engine compartment
WARNING
Improper refueling or handling of fuel is dangerous and can cause fire, explosion, and severe
burns.
x Always make sure that the fuel filler cap is screwed on all the way. This helps keep fuel
from spilling out or evaporating.
x Fuel is highly flammable and explosive; it can cause severe burns and other severe
injuries.
x Failure to shut the engine off while refueling and/or to insert the pump nozzle all the way
into the fuel filler neck can cause fuel to overflow and to spray out. Fuel spray and
overflowing fuel are dangerous because they can cause fire and serious personal injury.
x During refueling, the engine and the ignition must be switched off for safety reasons.
x Never use a cellular telephone, CB radio, or other radio equipment while refueling. The
electromagnetic radiation can cause sparks that can ignite fuel vapors and cause a fire.
x Never get back into your vehicle while refueling. If in exceptional circumstances you must
get back in your vehicle while refueling, make certain that you close the door and touch metal
to discharge static electricity before touching the filler nozzle again. This helps avoid the
build-up of static electricity, which can cause sparks that can ignite fuel vapors released
during refueling.
x Never smoke or have an open flame (or sparks, cigarettes, or other smoldering objects)
anywhere in or near your vehicle when refueling or filling a portable fuel container.
x Follow all safety instructions and procedures that apply at the service station where you
refuel.
x Never spill fuel in the vehicle or the luggage compartment.
