Vehicle battery

WARNING
Working on the batteries or the electrical system in your vehicle can cause serious acid
burns, fires, explosions, or electrical shocks. Always read and heed the following WARNINGS
and safety precautions before working on the batteries or the electrical system.
x Before working on the electrical system, always switch off the ignition and all electrical
consumers and disconnect the negative (-) cable from the standard 12 Volt battery.
x When you change a light bulb, always switch off the light first.
x Always keep children away from battery acid and vehicle batteries in general.
x Always wear eye protection. Never let battery acid or lead particles come into contact with
your eyes, skin, or clothing.
x Sulfuric battery acid is very corrosive. It can burn unprotected skin and cause blindness.
Always wear protective gloves and eye protection. To reduce your risk of injury, never tilt the
batteries, as this could spill acid through the vents and burn you.
x If you get battery acid in your eyes or on your skin, immediately rinse with cold water for
several minutes and then get immediate medical attention. If you swallow any battery acid,
get medical attention immediately.
x When disconnecting the batteries from the vehicle electrical system, always disconnect
the negative cable (-) first and then the positive cable (+).
x Always switch off all electrical consumers before reconnecting 12 Volt batteries.
Reconnect the plus cable (+) first and then the negative cable (-). Never reverse the polarity of
the connections. This could cause a fire.
x A highly explosive mixture of gases is given off when the battery is being charged.
x Do not smoke and avoid fires, sparks, and open flames when working. Never create
sparks or electrostatic charges when handling cables and electrical equipment. Never short
circuit the battery terminals. High-energy sparks can cause serious personal injury.
x Never use or attempt to charge a damaged or frozen battery, or a battery that was frozen
but has thawed. Charging a frozen or thawed battery could cause explosions and chemical
burns! Replace damaged or frozen vehicle batteries immediately. A dead battery can freeze at
temperatures around +32 °F (0 °C).
x If the battery has a vent line or tube, make sure that it is properly connected to the battery.
WARNING
California Proposition 65 Warning
x Battery posts, terminals, and related accessories contain lead and lead components,
chemicals known to the State of California to cause cancer and reproductive harm. Wash
your hands after handling.
NOTICE
x Do not expose the vehicle battery to direct sunlight for an extended period of time as
ultraviolet rays may damage the battery housing.
x If the vehicle is left standing in the cold for a long time, protect the vehicle battery from
freezing. A battery will be permanently damaged by freezing.
Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle
battery has been replaced may change or delete system settings (including time, date, personal
convenience settings, and programming). Check the settings and correct as necessary once the
vehicle battery has built up a sufficient charge.

Passenger car tire
A tire intended for use on passenger cars, multipurpose passenger vehicles, and trucks, that have a
gross vehicle weight rating (GVWR) of 10,000 pounds or less.
Ply
A layer of rubber-coated parallel cords.
Ply separation
A parting of rubber compound between adjacent plies.
Pneumatic tire
A mechanical device made of rubber, chemicals, fabric, and steel or other materials, that, when
mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the
load.
Production options weight
The combined weight of installed regular production options weighing over 5 lbs (2.3 kg) more then the
standard items they replace, and not previously considered as curb weight or accessory weight. These
include, for example, heavy-duty brakes, ride levelers, heavy-duty battery, and special trim.
Radial ply tires
A pneumatic tire in which the ply cords that extend to the beads are laid at substantially 90 degrees to
the centerline of the tread.
Recommended inflation pressure
The tire pressure recommended by the vehicle manufacturer for a tire of a specified size that has not
been driven for more than a couple of miles (kilometers) at low speeds in the 3 hour period before the
tire pressure is measured or adjusted.
Reinforced tire
A tire designed to operate at higher loads and at higher inflation pressures than the corresponding
standard tire.
Rim
The outer edge of a wheel upon which the tire beads are seated.
Rim diameter
The nominal diameter of the wheel's tire bead seating surface. If you change your wheel size, to
wheels of a different diameter, you will have to purchase new tires to match the new wheels.
Rim size
Designation means rim diameter and width.
Rim type designation
The industry or manufacturer's designation for a rim by style or code.
Rim width
The nominal distance between wheel rim flanges.
Section width
The linear distance between the exteriors of the sidewalls of an inflated tire, excluding elevations due
to labeling decoration, or protective bands.
Sidewall
The portion of a tire between the bead and the tread.

Frequently asked questions
If you suspect a malfunction or vehicle damage, read and follow the following advice before contacting
an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. You may also find
helpful information under “Special considerations” or “Checklist” in the index.

Description Possible causes, among
others Possible remedy
Engine does not start.
Vehicle battery dead. – Perform jump-start
– Charge vehicle battery
The wrong vehicle key is used. Use a valid vehicle key
Fuel level too low. Refuel
Vehicle cannot be locked
or unlocked using vehicle
key.
– Battery in the remote control
vehicle key is dead.
– Too far away from the
vehicle (out of range).
– Buttons have been pressed
too many times.
– Replace the battery in the remote
control vehicle key
– Move closer to vehicle.
– Synchronize vehicle key
– Lock or unlock vehicle manually
Unusual noises.
Cold engine, braking assist
systems, electronic steering
column lock.
Check the “Noises” entry in the index.
Odd driving behavior.
Assistance systems activated. Check the “Assistance systems” entry
in the index.
DSG® Direct Shift Gearbox too
hot.
Stop vehicle as soon as you can safely
do so.
Outside mirrors move
when the vehicle is
unlocked.
Convenience settings are
stored. Correct convenience settings
Front seats cannot be
adjusted with power
controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if necessary
CSC roof will not move. CSC roof malfunction.
Check whether any technical
requirement for opening and closing
the CSC roof is not met . If necessary
contact an authorized Volkswagen
dealer or an authorized Volkswagen
Service Facility.
Features do not work as
described in this manual.
Settings were adjusted in the
Volkswagen Information
System.
Check and reset to factory settings if
necessary
Headlights do not light up
the road as they should.
– Headlights incorrectly
adjusted.
– Light bulbs burned out.
– Low beams not switched on.
– Have the headlight range adjusted by
an authorized Volkswagen dealer or an
authorized Volkswagen Service
Facility.
– Change light bulbs
– Switch on low beams .
Electrical consumers do
not work.
Vehicle battery charge too low. Charge vehicle battery .
Remaining fuel level too low. Refuel

Frequently asked questions
If you suspect a malfunction or vehicle damage, read and follow the following advice before contacting
an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. You may also find
helpful information under “Special considerations” or “Checklist” in the index.

Description Possible causes, among
others Possible remedy
Engine does not start.
Vehicle battery dead. – Perform jump-start
– Charge vehicle battery
The wrong vehicle key is used. Use a valid vehicle key
Fuel level too low. Refuel
Vehicle cannot be locked
or unlocked using vehicle
key.
– Battery in the remote control
vehicle key is dead.
– Too far away from the
vehicle (out of range).
– Buttons have been pressed
too many times.
– Replace the battery in the remote
control vehicle key
– Move closer to vehicle.
– Synchronize vehicle key
– Lock or unlock vehicle manually
Unusual noises.
Cold engine, braking assist
systems, electronic steering
column lock.
Check the “Noises” entry in the index.
Odd driving behavior.
Assistance systems activated. Check the “Assistance systems” entry
in the index.
DSG® Direct Shift Gearbox too
hot.
Stop vehicle as soon as you can safely
do so.
Outside mirrors move
when the vehicle is
unlocked.
Convenience settings are
stored. Correct convenience settings
Front seats cannot be
adjusted with power
controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if necessary
CSC roof will not move. CSC roof malfunction.
Check whether any technical
requirement for opening and closing
the CSC roof is not met . If necessary
contact an authorized Volkswagen
dealer or an authorized Volkswagen
Service Facility.
Features do not work as
described in this manual.
Settings were adjusted in the
Volkswagen Information
System.
Check and reset to factory settings if
necessary
Headlights do not light up
the road as they should.
– Headlights incorrectly
adjusted.
– Light bulbs burned out.
– Low beams not switched on.
– Have the headlight range adjusted by
an authorized Volkswagen dealer or an
authorized Volkswagen Service
Facility.
– Change light bulbs
– Switch on low beams .
Electrical consumers do
not work.
Vehicle battery charge too low. Charge vehicle battery .
Remaining fuel level too low. Refuel

Checklist
For your own safety and that of your passengers, carry out the following steps in the order listed ⇒ :
1. Park the vehicle at a safe distance from traffic and on a suitable surface ⇒ .
2. Switch on emergency flashers by pressing the  switch ⇒ fig. 165.
3. Apply the parking brake to help prevent the vehicle from moving
4. Shift the transmission into Park (P) (automatic) or Neutral (manual only)
5. Stop the engine and remove the key from the ignition switch
6. Have all passengers exit and go to a safe location away from moving traffic, such as behind a
guard rail.
7. Take all vehicle keys with you when leaving your vehicle.
8. Set up a warning triangle or other warning device in order to alert other motorists and cyclists.
9. Let the engine cool down and get expert assistance if necessary.
If the emergency flashers are on, use the turn signal lever to indicate a direction or lane change, for
example when the vehicle is being towed. This temporarily interrupts the emergency flashers.
Switch on the emergency flashers when:
x Traffic suddenly slows down or stops in front of you to warn those approaching from behind.
x In any emergency situation.
x If the vehicle breaks down.
x When being towed.
Always obey traffic laws that govern the use of emergency flashers where you are driving.
If the emergency flashers are not working, a different method – as permitted by law – must be used to
alert other motorists and cyclists to the breakdown.
WARNING
Disregarding the safety-related checklist may lead to accidents and serious personal injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common
sense.
WARNING
The vehicle exhaust system and the catalytic converter get very hot. They can cause fires and
serious personal injury.
x Never park where parts of the hot exhaust system or catalytic converter could ignite
flammable materials, such as dry grass, brush, leaves, spilled fuel, etc.
The vehicle battery will be drained if the emergency flashers are on for a long time – even if the
ignition is switched off.

WARNING
Before using the emergency procedure to close the CSC roof, park the vehicle as far away
from moving traffic as possible. If necessary, switch on the emergency flashers and set up a
warning triangle. Obey all applicable legal requirements.
NOTICE
If the vehicle's battery fails or the power windows won't work, the door windows are not
lowered when the door is opened or closed. Always close and open the door carefully to help
prevent damage to the window, the paint, or the rubber seal.
NOTICE
x Before using the emergency procedure to close the CSC roof and while doing it, check the
area behind the vehicle for possible obstacles and make sure there is enough room to avoid
damage. Rear lid assist does not work before and during the emergency closing procedure.
x Never close the CSC roof if the car is on a workshop hoist, parked with one side on a curb,
or raised on a car jack or jackstands.
NOTICE
To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency
locking or unlocking.
Manually unlocking and locking the driver door

Fig. 166 Door handle on driver door: Concealed lock cylinder.

Possible situations for emergency closing
Provided the preliminary requirements have been met, the CSC roof can be closed using the
emergency procedure if you have one or more of the following problems:
x The windows in the doors will not go down.
x The soft-close feature of the luggage compartment lid is not working.
x Sensors that determine the position of the CSC roof when it is opening and closing are not
working.
Emergency CSC roof closing
x Check whether there is enough room behind the vehicle for the luggage compartment lid to swing
out backwards.
x Open the driver and passenger door and leave the doors open.
x Press your thumb on the top part of the Volkswagen emblem on the luggage compartment lid, and
flip lower part of the emblem outward. This unlocks the rear lid. But do not lift the luggage
compartment lid.
x Switch the ignition off and back on again.
x Start the engine.
x Pull and hold the center console lever ⇒ fig. 174 for at least 30 seconds.
x Release the lever.
x Pull and hold the lever again and immediately pull back and hold the driver door switch ⇒ fig. 175
(1) until the CSC roof has completely closed and locked.
It takes a few seconds for the closing process to start after you pull both controls. A tone sounds and
the indicator light X in the instrument cluster display lights up during the emergency closing process.
There may also be a message in the instrument cluster display.
The closing process is immediately interrupted if you let go of the lever or the switch or if one of the
cancel conditions changes ( 324, Cancel conditions for emergency closing). The process can be
restarted by again pulling the center console lever and the switch in the driver door.
x After emergency roof closing is complete, continue to hold the lever and switch to close all
windows.
x OR: After emergency closing, pull switch (1).
x OR: Insert the key in the lock of the driver's door, turn in the closing direction, and hold until all
windows are closed.
x Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility.
Cancel conditions for emergency closing
Emergency closing the CSC roof is canceled if any of the following situations occurs:
x The lever in the center console or the switch in the driver door is released.
x The ignition is switched off.
x Any door is shut.
x The vehicle battery voltage is less than 9 Volts.
x The luggage compartment lid is closed before the roof frames are locked into the mountings on the
windshield.
x The vehicle moves at a speed greater than about 0.6 mph (1 km/h).
x The outside temperature is below +5° F (- 15° C).
Emergency closing using the lever-switch combination is possible only if the CSC control unit has
detected a malfunction that is caused by one of the listed feasible problems 324, Possible situations
for emergency closing.
