2013 VOLKSWAGEN EOS Top function

Emergency shift program
If all selector lever position indicators in the instrument cluster display are highlighted against a bright
background, there is a system malfunction. The automatic transmission and the DSG automatic
transmission will then operate in the emergency shift program. The emergency shift program lets you
drive the vehicle, but at a reduced speed and without being able to use all of the forward gears.
In some cases, vehicles with a DSG® Direct Shift Gearbox automatic transmission may not be able to
shift into reverse. It is then impossible to drive the vehicle backwards.
In any event, have the automatic transmission checked by an authorized Volkswagen dealer or
authorized Volkswagen Service Facility.
Overheating of Direct Shift Gearbox (DSG®) automatic transmission
The DSG® automatic transmission may overheat, for example, due to frequent starts, extended
“creeping,” or stop-and-go traffic. Overheating is indicated by the warning light Á and, if applicable, by
a text message in the instrument cluster. An additional warning chime may sound. Stop and let the
transmission cool down ⇒ .
The vehicle does not move forward or in reverse even though a drive position is selected
with the selector lever
If the vehicle does not move in the desired direction, the system may not have engaged the drive
position correctly. Press the brake pedal and select the drive position again.
If the vehicle still does not move in the desired direction, there is a system malfunction. See your
authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance to have the
system checked.
NOTICE
x As soon as you get any of these warnings about transmission overheating, you must either
park the vehicle in a safe place or drive faster than 12 mph (20 km/h).
x If the text message and acoustic warning repeat themselves every 10 seconds or so, you
must park the vehicle in a safe place as soon as you can safely do so and stop the engine. Let
the transmission cool down.
x To help prevent damage to the transmission, do not drive the vehicle again until the
acoustic warning has stopped. As long as the engine is overheated, avoid stop and start
driving and avoid low speeds (“walking pace”).

braking a couple of times while driving at relatively high speed to help clean the brake discs and pads.
Make sure nobody is behind you and that you do not endanger yourself or others ⇒ .
Brake system malfunction
If you brake and find that the vehicle doesn't brake nearly as well as it used to (sudden increase in
stopping distance), a brake circuit may have failed. The brake warning light h or BRAKE will come on
and a message may appear in the instrument cluster display. If you believe the vehicle is safe to drive,
immediately take it to the nearest authorized Volkswagen dealer or authorized Volkswagen Service
Facility for repair. Drive slowly and very carefully, allow for the longer stopping distance, and be ready
to push longer and harder on the brake pedal to slow the vehicle down.
Brake booster
The brake booster works only when the engine is running. It increases the force on the brakes above
and beyond the pressure put on the brake pedal by the driver.
If the brake booster is not working, or if the vehicle has to be towed, you will have to push the brake
pedal harder to make up for the lack of booster assistance and the resulting longer stopping distance
⇒ .
WARNING
New brake pads do not provide maximum braking performance.
x New brake pads do not have the best stopping power for the first 200 miles (320 km) and
must be “broken in.” You can compensate for the slightly reduced braking force by putting
more pressure on the brake pedal.
x Drive with extra care while the new brake pads are being broken in. This reduces the risk
of collisions and serious personal injuries due to a loss of control over the vehicle.
x Never follow other vehicles too closely or put yourself into other situations that might
require sudden, hard braking, especially when the brake pads have not been broken in.
WARNING
Overheated brakes will reduce the vehicle's stopping power and increase stopping distances
considerably.
x When driving downhill, the brakes have to work especially hard and heat up quickly.
x Before driving downhill, especially on hills that are long or steep, always reduce speed
and shift into lower gear (manual or automatic transmission). This will let the vehicle use
engine braking and reduce the load on the brakes. Otherwise, the brake system could
overheat and possibly fail. Only use the brakes when you need them to slow the vehicle down
more or to stop.
x A damaged front spoiler or a non-standard spoiler can reduce airflow to the brakes and
make them overheat.
WARNING
Wet brakes or brakes coated with ice or road salt react slower and need longer stopping
distances.
x Carefully apply the brakes to test them.
x Always dry brakes and clean off ice and salt coatings with a few cautious brake
applications when visibility, weather, road and traffic conditions permit.

Brake fluid specifications
Volkswagen has developed a special brake fluid that is optimized for the brake system in your
Volkswagen. Volkswagen recommends that you use brake fluid that expressly conforms to quality
standard VW Standard 501 14 for optimum performance of the brake system. Check the information
on the container for the brake fluid you want to use to make sure it meets the requirements for your
vehicle.
Brake fluid that complies with VW Standard 501 14 can be purchased from your authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
If this special brake fluid is not available you may – under these circumstances – use another high-
quality brake fluid that complies with U.S. Federal Motor Vehicle Safety Standard (FMVSS) 116 DOT 4
⇒ .
Please note, however, that not all brake fluids that comply with U.S. Federal Motor Vehicle Safety
Standard FMVSS 116 DOT 4 have the same chemical composition. Some of these brake fluids can
contain chemicals that could, over time, degrade or damage internal parts of the vehicle’s brake
system.
Volkswagen therefore recommends that you use brake fluid that expressly complies with VW
Standard 501 14 for optimum brake system performance over the long term.
Brake fluid level
The fluid level in the transparent brake fluid reservoir must always be between the MIN and MAX
marking ⇒ .
On some vehicles, engine components block the view of the brake fluid reservoir and make it
impossible to see the brake fluid level. If you cannot clearly see the brake fluid level in the brake fluid
reservoir, please see an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
The brake fluid level drops slightly when the vehicle is being used as the brake pads wear and the
brakes are automatically adjusted.
Changing brake fluid
Brake fluid must be changed according to the service schedule in your ⇒ Booklet Warranty and
Maintenance. Have the brake fluid checked by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility. Refill only with new brake fluid that meets the standards listed above.
WARNING
Brake failure and reduced brake performance can be caused by not having enough brake
fluid in the reservoir or by old or incorrect brake fluid.
x Check the brake system and brake fluid level regularly.
x Always change the brake fluid according to the service schedule in your
⇒ Booklet Warranty and Maintenance.
x Hard braking with old brake fluid may cause vapor lock. Vapor lock reduces braking
performance, increases stopping distances and can even cause total brake failure.
x Always make sure that only the correct brake fluid is used. Only use brake fluid that
expressly conforms to VW Standard 501 14 or, if it is not available, only use a high-quality
brake fluid that conforms to U.S. Standard FMVSS 116 DOT 4 requirements.
x Using another brake fluid, or one that is not of high quality, can impair the function of the
brake system and reduce its effectiveness. If the container does not say that the brake fluid
complies with VW Standard 501 14, or U.S. Standard FMVSS 116 DOT 4, do not use it.
x The brake fluid must be new.

Lights
up Possible cause Proper response
D
Power steering assist is reduced.
Stop, restart the engine, and drive a short
distance. If the yellow warning light does not
come on again, you do not need to have the
steering system checked.
Otherwise, have the steering checked
immediately by an authorized Volkswagen
dealer or an authorized Volkswagen Service
Facility.
Vehicle battery was disconnected and
has been reconnected.
Drive a short distance at about 10–12 mph
(15–20 km/h).


Flashes Possible cause Proper response
D Electronic steering column lock
malfunction.

Sport Drive (S), or Reverse (R) and you must use the foot brake to hold the vehicle before starting to
move.
Hill Hold keeps the brake applied for not quite 2 seconds with the same force you used to prevent the
vehicle from moving. This gives you time to take your foot off the brake and gently depress the
accelerator to get the vehicle moving again. If you do not depress the accelerator pedal and get the
vehicle moving again within this time, the brakes will release and the vehicle will roll downhill.
Furthermore, if any requirement for engaging Hill Hold is no longer met while the vehicle is stopped,
Hill Hold disengages and the brakes are automatically released and will no longer hold the vehicle.
Hill Hold is activated automatically when the following conditions are all met at the same
time.

Points 1 to 3 must all be met at the same time:
Step Automatic transmission
1. Hold the stopped vehicle on an incline with the foot or parking brake.
2. The engine must be running “smoothly.”
3. An automatic transmission vehicle must be in Reverse (R), Drive (D), or Sport Drive (S)
and the foot brake must be depressed to keep the vehicle from moving.
4. To drive off, take your foot off the brake pedal and gently depress the accelerator within
2 seconds.

Hill Hold is immediately deactivated:
x If any requirement listed in the table above is no longer met (see 213, Hill Hold is activated
automatically when the following conditions are all met at the same time.).
x If the engine is not running smoothly or the engine malfunctions.
x If the engine stalls or is switched off.
x If the transmission is in Neutral (N).
x If a tire does not have enough road contact (such as when the vehicle is tipped or at an angle).
WARNING
The intelligent technology of Hill Hold cannot overcome the laws of physics. Never let the
increased convenience provided by Hill Hold tempt you into taking risks.
x The Hill Hold feature cannot hold the vehicle in all hill start situations (for example, if the
surface is icy or slippery).
x Hill Hold can only help keep the vehicle from moving for less than 2 seconds. After that,
the brakes will be released and the vehicle can roll down the hill.

x If the distance remains the same, the warning tone volume decreases after a few seconds. If a
continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep
turns on again automatically if the vehicle approaches the obstacle again.
x For vehicles with automatic transmissions, there is no beeping when the transmission is in Park
(P).
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.
x Rear lid assist only works when the vehicle is not moving.
Rear lid assist during opening and closing the CSC roof
Before the CSC roof opens or closes, the rear lid assist system uses the PDC sensors to check that
there is enough room behind the vehicle for the rear lid to swing out past the rear bumper.
x If an obstacle is detected, roof operation stops. Unlike the Park Distance Control system, rear lid
assist has no acoustical alert signal. Remove any obstacles behind the vehicle or move the vehicle
forward so that there is enough room for the luggage compartment lid to swing out.
x If you operate the CSC roof lever again after roof has automatically stopped (because rear lid
assist has detected an obstacle), roof operation will start again after a few seconds. The CSC roof will
not stop again automatically if an obstacle is detected a second time. Instead, a warning will appear in
the instrument cluster display.
x Because the rear lid assist system uses the PDC sensors, its operation depends on whether or not
the PDC system is working properly. PDC is working properly if the warning chime sounds when you
shift into Reverse.
WARNING
Never rely completely on the PDC for information about people and objects that might be in
the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may
not always be able to detect them.
If there is a malfunction in the Park Distance Control, a brief continuous warning tone will sound
and the indicator light in the button will blink when you first switch the system on. Switch off the Park
Distance Control system with the button and have it immediately checked by an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
Rear lid assist can be deactivated by an authorized Volkswagen dealership or authorized
Volkswagen Service Facility. If this is done, Park Distance Control still works and will give an acoustic
warning if the CSC roof is opened or closed while the vehicle is in Reverse. The signal sounds as
soon as the luggage compartment lid swings into the area scanned by the PDC sensors.

Your vehicle's Tire Pressure Monitoring System (TPMS) uses the Anti-lock Brake System (ABS)
sensors to indirectly check the tire pressure of all 4 tires while you are driving. The sensors monitor the
tread circumference (rolling circumference) and vibration characteristics of the individual tires. TPMS
warns if there is a significant loss of pressure in one or more tires while the vehicle is moving.
Pressure loss is signaled by the indicator light Ç (described below) as well as by acoustic warnings and
text warnings in the instrument cluster display if your vehicle has this display (Multi-Function Indicator -
MFI).
The original benchmark pressure is the recommended maximum load cold tire inflation pressure for
the tires that come with your vehicle. This pressure is listed on the tire pressure label on the driver
door jamb Error! Bookmark not defined.. After adjusting the tire pressures in all 4 tires, you must
confirm and store the new cold inflation pressures by pressing the SET button, which changes the
benchmark pressure to match the current pressure of the tires on your vehicle
Recalibrating the TPMS to reset the benchmark cold tire inflation pressure with proper use of the SET
button is explained below
More information:
x Transporting
x Braking, stopping and parking
x Exterior care and cleaning
x Tires and wheels
x Parts, accessories, repairs and modifications

underinflated. Accordingly, when the low tire pressure telltale illuminates, you should stop and check
your tires as soon as possible, and inflate them to the proper pressure. Driving on a significantly
underinflated tire causes the tire to overheat and can lead to tire failure. Underinflation also reduces
fuel efficiency and tire tread life, and may affect the vehicle's handling and stopping ability.
Please note that the TPMS is not a substitute for proper tire maintenance, and it is the driver's
responsibility to maintain correct tire pressure, even if underinflation has not reached the level to
trigger illumination of the TPMS low tire pressure telltale.
Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system
is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure
telltale. When the system detects a malfunction, the telltale will flash for approximately 1 minute and
then remain continuously illuminated. This sequence will continue upon subsequent vehicle start-ups
as long as the malfunction exists.
When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire
pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation
of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning
properly. Always check the TPMS malfunction telltale after replacing one or more tires or wheels on
your vehicle to ensure that the replacement or alternate tires and wheels allow the TPMS to continue
to function properly.
Spare wheel or compact spare wheel
The spare wheel or compact spare wheel has no tire pressure sensor. When the spare or compact
spare wheel is mounted on the vehicle, the Tire Pressure Monitoring System (TPMS) indicator light will
flash in the instrument cluster display. The TPMS continues to monitor the other 3 wheels.
Tire storage
If the tires do not move for an extended period of time, the sensors will not transmit tire pressures to
the system. This saves sensor battery life. The sensors are reactivated by driving the vehicle again.
WARNING
Incorrect tire pressure can cause sudden tire failure, loss of vehicle control and serious
personal injury.
x Always check and correct air pressure in all 4 tires, particularly after changing,
exchanging, or repairing tires.
x After that, always make sure that all 4 tires are inflated to the correct tire pressure for the
tires installed on the vehicle.
x See the tire pressure label ⇒ fig. 159 and the Owner's Literature for recommended cold
tire inflation pressure and other important information.
x When replacing tires or wheel rims on vehicles equipped with TPMS, always read and
heed all of the information and WARNINGS
NOTICE
x The wheel electronics are attached to special aluminum valves on the wheels. These valves
are screwed on rigidly. Never bend the valves “into position” when checking and adjusting tire
pressure.
x Missing tire air valve caps could result in damage to the valves, as well as to the sensors on
the Tire Pressure Monitoring System. Therefore, make sure your valve caps conform to the
specifications of those originally installed on the vehicle and that they are always tightly and
properly screwed on to the valves. Do not use metallic valve caps
x Do not use “comfort valve caps.” They do not seal properly and can damage the sensors.
x When changing or rotating the tires, be careful not to damage the valves or sensors.
