2013 VOLKSWAGEN BEETLE Owners Manual

Fig. 16 Vehicle identification number (VIN).

Maximum power
output (SAE net)
Injection
technology
Engine ID
code
Maximum torque No. of
cylinders
Displacement
170 hp at 5700 rpm
(125 kW at 5700 rpm) SRE
CBTA,
CBUA
2.5L
177 lb-ft at 4250 rpm
(240 Nm at 4250 rpm)
5 cylinder
151 CID
(2480 ccm)
200 hp at 5100 –
6000 rpm
(147 kW at 5100 –
6000 rpm)
TSI®
CCTA,
CBFA
2.0T
207 lb-ft at 1700 – 5000 rpm
(280 Nm at 1700 – 5000
rpm)
4 cylinder
121 CID
(1984 ccm)

Diesel engines

Maximum power
output (SAE net)
Injection
technology
Engine ID
code
Maximum torque No. of
cylinders
Displacement
140 hp at 4000 rpm
(103 kW at 4000 rpm)
TDI® with
DPF
CJAA
2.0L TDI
236 lb-ft at 1750 – 2500 rpm
(320 Nm at 1750 – 2500 rpm)
4 cylinders
120 CID
(1968 ccm)

Dimensions

x Always be careful when you enter a driveway or drive up or down steep ramps or over
curbs or other obstacles. Parts of the vehicle close to the ground may be damaged (such as
bumper covers, spoilers, and parts of the engine, suspension, and exhaust systems).

Vehicle key set

Remote control vehicle keys

Fig. 17 Remote control vehicle key with panic button.

Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or
call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons.or the power locking buttons.are pushed repeatedly in
quick succession, the power locking system is switched off for a brief period to help keep it from being
overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the rear hatch is
opened in this span of time, the vehicle is automatically locked afterwards.
Indicator light in the remote control vehicle key

Fig. 18 Indicator light in the remote control vehicle key.

Replacing the remote control vehicle key battery

Fig. 19 Remote control vehicle key: Open battery compartment cover.

Fig. 20 Remote control vehicle key: Remove old battery.

x Make sure the plus and minus poles of the battery are correctly positioned.
Dispose of old batteries in an environmentally responsible manner and keep them out of the
reach of children.
Batteries of the type used in your remote control vehicle key may contain Perchlorate Material.
Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding handling and disposal of these batteries. Authorized Volkswagen dealers and
authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that
you have them perform this service for you.
Synchronizing the remote control vehicle key
