2013 VOLKSWAGEN BEETLE CONVERTIBLE Owners Manual

Vehicle key set

Remote control vehicle keys

Fig. 18 Remote control vehicle key with panic button.
Please first read and note the introductory information and heed the WARNINGS
Remote control vehicle key
The remote control vehicle key can unlock and lock the vehicle from a distance .
The remote transmitter and battery are inside the remote control vehicle key. The receiver is inside the
passenger compartment. The operating range of the remote control vehicle key for a fresh battery is
several yards (meters) around the vehicle.
If the remote control vehicle key will not lock or unlock your vehicle, you probably need to replace the
battery in the remote control vehicle key, Replacing the remote control vehicle key battery. If this is not
the problem, the key should be resynchronized by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop. See also , Synchronizing the remote
control vehicle key.
Folding the key bit in or out
Pressing button ⇒ fig. 18 (1) releases the key bit and folds it out.
To fold the key bit in press button (1) while pressing the key bit back until it clicks.
Panic button
Press the panic button (2) only in emergencies! After pushing the panic button, the horn will sound and
the turn signals will flash. Press the panic button again to switch off the panic feature.
Replacement vehicle keys
The vehicle identification number is required to get a replacement key or an additional remote control
vehicle key.
Up to 8 vehicle keys, each of which must be properly cut, coded, programmed, and synchronized, can
be used with your vehicle.
Each new vehicle key contains a microchip and must be coded with the data from the vehicle's elec-
tronic immobilizer. A vehicle key will not work if it does not contain a microchip or contains a chip that
is not coded, even if the key bit was cut correctly.
You can obtain additional or duplicate remote control vehicle keys from authorized Volkswagen deal-
ers, authorized Volkswagen Service Facilities, and from certain independent repair facilities and lock-
smiths which are qualified to make remote control vehicle keys.
Each vehicle key must be programmed by an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility in order for it to work with your vehicle.
To find the nearest qualified independent repair facility, locksmith, or Volkswagen dealer which can cut
and code replacement vehicle keys, call the VW Customer Care Hotline at 1-800-822-8987 or visit
http://www.vw.com and search for “replacement keys.”

Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or
call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
NOTICE
The remote control vehicle keys contain electrical components. Protect them from damage,
moisture and rough handling.
Do not press the buttons on the remote control vehicle key unless you actually want to use the
function in question. Since terrain and conditions vary, pressing a button on the remote control vehicle
key when it is not necessary may unlock the vehicle or set off the panic alarm, even if you think you
are out of range.
Remote control vehicle key functions can be temporarily disrupted by interference from transmit-
ters near the vehicle that use the same frequency range (such as radio equipment or cellular phones).
Things between the remote control vehicle key and vehicle, bad weather, as well as a weak
battery can reduce the operating range.
If the remote control vehicle key buttons 50 or the power locking buttons 51 are pushed repeat-
edly in quick succession, the power locking system is switched off for a brief period to help keep it
from being overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the
luggage compartment lid is opened in this span of time, the vehicle is automatically locked afterwards.
Indicator light in the remote control vehicle key

Fig. 19 Indicator light in the remote control vehicle key.
Please first read and note the introductory information and heed the WARNINGS
If a button in the remote control vehicle key is pressed briefly, the indicator light ⇒ fig. 19 (arrow) will
flash once briefly. If you push and hold a button, it flashes repeatedly.
If the indicator light in the remote control vehicle key does not come on when the button is pressed,
the battery inside the key must be replaced 46.
A Declaration of Compliance with United States FCC and Industry Canada regulations is found in the
Consumer information section of this Manual 253.

Replacing the remote control vehicle key battery

Fig. 20 Remote control vehicle key: Open battery compartment cover.

Fig. 21 Remote control vehicle key: Remove old battery.
Please first read and note the introductory information and heed the WARNINGS
Volkswagen recommends having the battery in the remote control vehicle key changed by an author-
ized Volkswagen dealer or authorized Volkswagen Service Facility.
The battery is on the back of the remote control vehicle key under a cover ⇒ fig. 20.
When changing the battery, pay attention to the correct polarity and use the same type of battery
⇒ .
Replacing the battery
x Unfold the key bit on the remote control vehicle key
x Remove the cover on the back of the remote control vehicle key in the direction of the arrow ⇒ .
x Use a thin object to pry the battery out of the battery compartment ⇒ fig. 21.
x Position the new battery in as shown and press it into the battery compartment (opposite to direc-
tion of the arrow) ⇒ .
x Position the cover as shown and press it down (opposite to direction of the arrow) until you hear it
click into place.
NOTICE
x Changing the battery improperly can damage the remote control vehicle key.
x Using the wrong battery can damage the remote control vehicle key. Replace a dead battery
with a new one that has the same voltage, size, and specifications.

x Make sure the plus and minus poles of the battery are correctly positioned.
Dispose of old batteries in an environmentally responsible manner and keep them out of the
reach of children.
Batteries of the type used in your remote control vehicle key may contain Perchlorate Material.
Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal
requirements regarding handling and disposal of these batteries. Authorized Volkswagen dealers and
authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that
you have them perform this service for you.
Synchronizing the remote control vehicle key

Power locking and closing system

Description of the power locking system
Please first read and note the introductory information and heed the WARNINGS
The power locking system lets you unlock and lock all doors, the luggage compartment lid, and the
fuel filler flap:
x From the outside with the vehicle key
x From the outside with Keyless Access
x From the inside with the power locking button
Special functions of the power locking system can be activated or deactivated by an authorized
Volkswagen dealer or authorized Volkswagen Service Facility.
The doors and the luggage compartment lid can be locked manually if the remote control vehicle key
or the power locking system is not working
Automatic locking (Auto Close)
The vehicle locks automatically when it reaches a speed of about 10 mph (15 km/h). When the vehicle
is locked, the indicator light W comes on in the power locking button ⇒ fig. 23.
Automatic unlocking (Auto Open)
The vehicle unlocks automatically when the vehicle key is taken out of the ignition. On vehicles with
Keyless Access, Auto Open is triggered by opening the driver door. Auto Open works only if the vehi-
cle has been automatically locked with the Auto Close feature. The indicator light W goes out in the
power locking button when the doors unlock ⇒ fig. 23.
Locking the vehicle after airbag inflation
If the airbags are activated during a collision, the entire vehicle is unlocked. Depending on the severity
of the damage, the vehicle can be locked after a collision when the airbags have deployed as follows:

Function Action
Locking the vehicle with the
power locking button:
– Switch the ignition off.
– Open and close a door once.
– Press the power locking button 1
Locking the vehicle with the
remote control vehicle key:
– Switch the ignition off.
OR: Remove the vehicle key from the ignition.
– Open a door once.
– Lock the vehicle with the remote control vehicle key.

Indicator light in the driver door

After the vehicle is locked: Meaning
The red LED light flashes for about 2 seconds in short
intervals, then slower.
The vehicle is locked.
Red LED light lights up continuously for about
30 seconds.
Locking system malfunction. See an
authorized Volkswagen dealer or an
authorized Volkswagen Service Facility.

If the vehicle key buttons 42 or the power locking buttons 51 are pushed repeatedly in quick
succession, the power locking system is switched off for a brief period to help keep it from being

overloaded. The vehicle is then unlocked for about 30 seconds. Unless a door or the luggage com-
partment lid is opened during this time, the vehicle is automatically locked afterwards.
Unlocking or locking the vehicle from the outside

Fig. 22 Remote control vehicle key with panic button.
