2013 TOYOTA xD Accessories, Audio & Navigation (in English)

65
65
WMA additional
information
• This unit plays back WMA files encoded by
Windows Media Player.
• You can only playbac
k WMA files in the
frequencies 32 kHz, 44.1 kHz and 48 kHz.
• The sound quality of

WMA files generally
becomes better with an increased bit rate.
This unit can play recordings with bit rates
from 48 kbps to 320 kbps (CBR) or from
48 kbps to 384 kbps (VBR), but in order to
be able to enjoy sound of a certain quality,
we recommend using discs recorded with
a higher bit rate.
• This unit doesn't support the follo

wing for-
mats.
- Wind

ows Media Audio 9 Professional
(5.1ch)
- Windows Media

Audio 9 Lossless
- Windows Media Audio 9 Voice
About folders and
MP3/WMA files
• An outline of a CD-ROM and USB portable
audio player/USB memory with MP3/WMA
files on it is shown below. Subfolders are
shown as folders in the folder currently
selected.
001.mp3
(001.wma)
010.mp3
(010.wma)
021.mp3
(021.wma)
030.mp3
(030.wma)
011.mp3
(011.wma)
020.mp3
(020.wma)
First
levelSecond levelThirdlevel
001
(ROOT)
002
004
005
003
NOTES
This unit assigns folder
number. The user can not
assign folder numbers.
MP3/ WMA files in the USB
portable audio player/USB
memory are played in the
same order as they were
copied to the USB portable
audio player/USB memory.
To specify the order in
which files in the USB
portable audio player/USB
memory are played, we
recommend the following
method.
1 Using a personal computer,
add a number indicating
the playback order in
front of the file name, e.g.
[001xxx.mp3] or [099yyy.wma].
 Put the files into a folder.
3 Copy the folder to the USB
portable audio player/USB
memory.
Depending on the
computer environment,
it may not be possible to
specif y the order by this
method.
•
•
•

66
66
USB portable audio
player/ USB memory
compatibility
• USB version: 2.0, 1.1 and 1.0
• USB data transfer rate: High speed
•
USB Class: MSC (Mass Storage Class) device• Protocol: Bulk
• Minimum amount of memory: 256 MB
• Maximum amount of memory: 250 GB
• File system: FAT32 and FAT16
• Supply current: 1 A
NOTES
Partitioned USB memory
is not compatible with this
unit.
Depending on the kind of
USB portable audio player/
USB memory you use, this
unit may not recognize
the USB audio player/USB
memory or audio files
may not be played back
properly.
•
•
This unit can playback
files in the USB portable
audio player/USB memory
that is USB Mass Storage
Class. However, copyright
protected files that are
stored in above-mentioned
USB devices cannot be
played back. (If the iPod is
connected to this unit, file
playback condition depends
on the iPod specifications.)
You cannot connect a USB
portable audio player/USB
memory to this unit via a
USB hub.
Not all multimedia portable
devices are compatible.
We cannot guarantee
compatibility with all USB
mass storage devices and
assumes no responsibility
for any loss of data on media
players, smart phones, or
other devices while using this
product.
•
•
•
•
It is not possible to check
folders that do not include
MP3/ WMA files. (These
folders will be skipped
without displaying the
folder number.)
MP3/ WMA files in up to
eight tiers of folders can
be played back. However,
there is a delay in the
start of playback on discs
and USB portable audio
player/USB memory with
numerous tiers. For this
reason we recommend
creating discs with no more
than two tiers.
It is possible to playback up
to 19
 f

olders on one disc.
It is possible to playback up
to  55 f

olders on one USB
portable audio player/USB
memory.
•
•
•
•

67
67
Terms
Packet writeThis is a general term for a method
of writing on CD -R, etc. at the time
required for a file, just as is done
with files on floppy or hard discs.
Bit rateThis expresses data volume per
second, or bps (bits per second)
units. The higher the rate, the more
information is available to reproduce
the sound. Using the same encoding
method (such as MP3), the higher
the rate, the better the sound.
Multi-sessionMulti-session is a recording method
that allows additional data to be
recorded later. When recording
data on a CD -ROM, CD -R or CD -
RW, etc., all data from beginning
to end is treated as a single unit or
session. Multi-session is a method
of recording more than 2 sessions in
one disc.
CD-DACD - DA is an abbreviation of
Compact Disc Digital Audio. It refers
to the uncompressed format of
regular CDs.
ID3 TagThis is a method of embedding track-
related information in a MP3 file. This
embedded information can include
the track title, the artist's name, the
album title, the music genre, the
year of production, comments and
other data. The contents can be
freely edited using software with ID3
Tag editing functions. Although the
tags are restricted to the number of
characters, the information can be
viewed when the track is played back.
ISO9660 formatThis is the international standard
for the format logic of CD -ROM
folders and files. For the ISO9660
format, there are regulations for the
following two levels.
Level 1:
The file name is in 8.3 format (the
name consists of up to 8 characters,
half-byte English capital letters
and half-byte numerals and the "_"
sign, with a file- extension of three
characters).
Level 2:
The file name can have up to 31
characters (including the separation
mark "." and a file extension).
Each folder contains less than 8
hierarchies.
Extended formats
Joliet:
File names can have up to 64
characters.Romeo:
File names can have up to 128
charac
ters.
m3uPlaylists created using the
" WINAMP " software have a playlist
file extension (.m3u).
MP3MP3 is short for MPEG1 & 2 Audio
Layer3. It is an audio compression
standard set by a working group
(MPEG) of the ISO (International
Standards Organization). MP3 is able
to compress audio data to about 1/10
the level of a conventional disc.
WMAWMA is short for Windows MediaTM
Audio and refers to an audio
compression technology that is
developed by Microsoft Corporation.
WMA data can be encoded by using
Windows Media Player version 7 or
later.

68
68
• If the heater is used in cold weather,
moisture may form on components
inside the CD player. Condensation
may cause the CD player to malfunc-
tion. If you think that condensation is
a problem, turn off the CD player for
an hour or so to allow it to dry out and
wipe any damp discs with a soft cloth
to remove the moisture.
• Roa

d shocks may interrupt CD play-
back.
• Nev

er put a label, tape or scratches on
a disc. These will prevent the disc from
being played.
• When using discs that can be printed
on label surfaces, check the instruc -
tions and the warnings of the discs.
Depe

nding on the discs, inserting and
ejecting may not be possible. Using
such discs may result in damage to
this equipment.
Do not a

ttach commercially available
labels or other materials to the discs.
- The d

iscs may warp making the disc
unplayable.
- The l

abels may come off during
playback and prevent ejection of the
discs, which may result in damage to
the equipment.
CD-R and CD-RW
discs
• When CD - R/CD - RW discs are used,
playback is possible only for discs
which have been finalized.
• It ma

y not be possible to playback
CD - R/CD - RW discs recorded on a
music CD recorder or a personal com-
puter because of disc characteristics,
scratches or dirt on the disc, or dirt,
condensation, etc., on the lens of this
unit.
• Pla

yback of discs recorded on a per-
sonal computer may not be possible,
depending on the application settings
and the environment. Please record
with the correct format. (For details,
contact the manufacturer of the appli-
cation.)
CD player and care
• Use only CDs that have either of the
two Compact Disc Digital Audio marks
as shown below.
• Use o

nly normal, round CDs. If you
insert irregular, non-round, shaped
CDs they may jam in the CD player or
not play properly.
• Check all CDs for cracks, scratches
or warping before playing. CDs that
have cracks, scratches or are warped
may not play properly. Do not use such
discs.
• Avoi

d touching the recorded (non-print-
ed) surface when handling the disc.
• Sto

re discs in their cases when not in
use.
• Keep d

iscs out of direct sunlight and
do not expose the discs to high tem-
peratures.
• Do no

t attach labels, write on or apply
chemicals to the surface of the discs.
• To cl

ean a CD, wipe the disc with a
soft cloth outward from the center.

69
69
• Playback of CD - R/CD - RW discs may
become impossible in case of direct
exposure to sunlight, high tempera-
tures, or the storage conditions in the
car.
• Tit

les and other text information
recorded on a CD - R/CD - RW disc may
not be displayed by this unit (in the
case of audio data (CD - DA)).
• Thi

s unit conforms to the track skip
function of the CD - R/CD - RW disc. The
tracks containing the track skip infor-
mation are skipped automatically (in
case of audio data (CD - DA)).
• If yo

u insert a CD - RW disc into this
unit, time to playback will be longer
than when you insert a conventional
CD or CD - R disc.
• Rea

d the precautions accompanying
the CD - R/CD - RW discs before use.
• Rec

ordings on CD - R/CD - RW can
not be played back using the DDCD
(Double Density CD) system.
• Thi

s unit will not playback SACD
(Super Audio CD).
DualDiscs
• DualDiscs are two -sided discs that
have a recordable CD for audio on one
side and a recordable DVD for video on
the other.
• Sin

ce the CD side of DualDiscs is not
physically compatible with the general
CD standard, it may not be possible to
play the CD side with this unit.
• Fre

quent loading and ejecting of a
DualDisc may result in scratches on
the disc. Serious scratches can lead
to playback problems on this unit. In
some cases, a DualDisc may become
stuck in the disc loading slot and will
not eject. To prevent this, we recom-
mend you refrain from using DualDisc
with this unit.
• Ple

ase refer to the information from
the disc manufacturer for more
detailed information about DualDiscs.

70
70
BeSpoke Troubleshooting
SymptomAction
BeSpoke does not work.
Is the application installed in the iPhone?
Are you logged in?
Please check the iPhone.
Forgotten the password for
BeSpoke.Reset Password from the iPhone.
You can change the password from the link that will be sent to your registered mail
address.
The map does not display.
Are you in the coverage area?
Is the cable connected correctly?
The map does not scroll.Flick operation is not supported.
Scroll the map by dragging it with your finger.
There is no sound from the
internet radio.Are you in the coverage area?
Switch the source to iPod or Pandora, and then to BeSpoke.
The Voice Recognition does not
work.
Start talking after the beep stops.
Start talking within 3 seconds after the beep stops.
Is the Bluetooth connected?
Are you in the coverage area?
* Touch [] on your iPhone and then use [Help] to check the operating procedures for each icon.
* For more details, please visit our website at w w w.Scion.com/BeSpoke.

71
71
Error indications
If the CD player does not work, the CD stops suddenly during playback, or a similar problem occurs, an error
indication will appear on the display. The cause of the trouble will be indicated by an error number, and you
should check the corresponding item shown in the table below.
Check DISCWhen the disc is dirty or has been inserted upside-down.
Check the disc.
DISC ErrorThere is probably an electrical or mechanical fault in the CD player.
Contact your Scion dealer and ask for repair.
No music files found.
This appears when an MP3/WMA file format is unusual and not supported by this unit
like WAV format recordings.
Please check the MP3/WMA file format.

7
7
When problems occur while the iPod is connected to this unit, a message will appear on the display. Refer to the
table below to identif y the problem, then take the suggested corrective action.
Please check the iPod firmware
version.This appears when an iPod software version is unusual and not supported by this unit.
Please check the iPod software version.
Connection error.
Please consult your Owner’s
Manual for
instructions on how to connect
the iPod.Communication failure. Or, the overcurrent was detected.
Disconnect the cable from the iPod. Once the iPod main menu appears in the iPod
display, connect the cable again.
There are no songs available for
playback.
Please load compatible media
to your iPod.No songs.
Transfer the songs to the iPod.
No items available.There are no songs in the selected list.
Select a list that contains songs.
iPod full. Tags cannot be stored.Because the capacity of iPod was full, tag was not able to be transferred from this
machine.
Transferring data from the iPod.
Please wait …Because this unit is acquiring data from iPod, it is not possible to operate it.
Wait until the data acquisition finished.
iPod authorization failed.This appears when the iPod is unusual and not compatible with this unit.
Please check the iPod compatibility.
