2013 TOYOTA PRIUS PLUG-IN audio

25
3. Basic operation
PRIUS PHV_QG_OM47788U_(U)
■Changing “POWER” switch modes
Modes can be changed by pressing the “POWER” switch with the
brake pedal released. (The mode changes each time the switch is
pressed.)
Off
The emergency flashers can be
used.
ACCESSORY mode
Some electrical components such
as the audio system can be used.
The “POWER” switch indicator
turns amber.
ON mode
All electrical components can be
used.
The “POWER” switch indicator
turns amber.

9
PRIUS PHV_OM_OM47787U_(U)
Tires
●Rotation
●Replacement
●Inflation pressure
●Information
P. 476
P. 448
P. 619
P. 625
Rear side marker lights P. 292
Side doors P. 134
Tail lights P. 292
∗:If equipped
*:Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
Rear turn signal lights P. 254
License plate lights P. 292
Camera*
Back door P. 140
Rear window wiper∗ P. 304
Rear window defoggers P. 375
Charging port P. 73

11
PRIUS PHV_OM_OM47787U_(U)
A
Anti-glare inside rear view mirror
Garage door opener switches∗
P. 166
P. 407
Sun visors P. 392
SRS curtain shield airbags P. 184
Rear interior light P. 384
Vanity mirrors P. 393
Front interior/personal lights P. 383
∗:If equipped
*:Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
Microphone* P. 415
“SOS” button∗
Auxiliary box
P. 415
P. 391
Assist grips P. 400

13
PRIUS PHV_OM_OM47787U_(U)
C
Console box P. 387
*:Refer to “Display Audio System Owner’s Manual” or “Navigation System Owner’s Manual”.
Cup holders P. 388
AUX port/USB port* P. 381
Power outlet P. 395

15
PRIUS PHV_OM_OM47787U_(U)
Pictorial indexInstrument panel
Headlight switch
Turn signal lever
Fog light switch∗
P. 292
P. 254
P. 298
Pre-collision braking off switch∗ P. 336
Parking brake pedal P. 255
Tire pressure warning reset switch P. 478
Windshield wipers and
washer switch
Rear window wiper and
washer switch∗
P. 300
P. 304
Gauges and meters
Multi-information display
P. 257
P. 266
Audio system*2 P. 376
Navigation system*1
SRS driver airbag
Horn
P. 184
P. 256
SRS knee airbag P. 184
Tilt and telescopic steering control lever P. 165
∗:If equipped
*1:Refer to “Navigation System Owner’s Manual”.
*2:Refer to “Display Audio System Owner’s Manual”.

17
PRIUS PHV_OM_OM47787U_(U)
B
Telephone switches*1, 2
“DISP” button P. 267Audio remote
control switches*1, 2
Cruise control switch∗
Dynamic radar cruise control
switch∗
P. 308
P. 312
Vehicle-to-vehicle distance button∗ P. 312
Talk switch*1, 2
“TRIP” button P. 267, 273
Climate remote control switches P. 369
∗:If equipped
*1:Refer to “Navigation System Owner’s Manual”.
*2:Refer to “Display Audio System Owner’s Manual”.

52
1-1. Plug-in hybrid system
PRIUS PHV_OM_OM47787U_(U)
Energy monitor/consumption screen
Energy monitor
Displays the flow of energy as it changes in accordance with driving
conditions.
Display Audio system
Press “CAR”.
If the “Consumption” screen is
displayed, touch “Energy”.
Yo u c a n v i e w t h e s ta t u s o f y o u r h ybrid system on the Display Audio
system screen, the navigation system screen or the multi-informa-
tion display.
Display Audio system
screen or navigation system
screen
Multi-information display

61
1-1. Plug-in hybrid system
1
Before driving
PRIUS PHV_OM_OM47787U_(U)
Consumption screen
Display Audio system
Press “CAR”.
If the “Energy Monitor” screen is displayed, touch “Consumption”.
Fuel consumption in the past
30 minutes
Cruising range (→P. 6 6 )
Regenerated energy in the
past 30 minutes
One symbol indicates 30 Wh. Up
to 4 symbols are shown.
The image is an example only, and may vary slightly from actual conditions.
Navigation system
Press “INFO APPS” or “INFO”.
To u c h “ F u e l C o n s u m p t i o n ” o n the “Information” screen.
If the “Energy Monitor” screen is displayed, touch “Fuel Consump-
tion”.
Fuel consumption in the past
30 minutes
Regenerated energy in the
past 30 minutes
One symbol indicates 30 Wh. Up
to 4 symbols are shown.
Cruising range (→P. 6 6 )
The image is an example only, and may vary slightly from actual conditions.
STEP 1
STEP 2
