2013 TOYOTA MATRIX clock

382 4-3. Do-it-yourself maintenance
Unplug the bulb while depress-
ing the lock release.
■Front turn signal/parking and front side marker lights
Turn the bulb base counterclock-
wise.
Remove the light bulb.STEP4
STEP1
STEP2

384 4-3. Do-it-yourself maintenance
Turn the bulb base counterclock-
wise.
Rear turn signal light
Back-up light
Stop/tail and rear side marker
light
Remove the light bulb.
Rear turn signal light
Back-up light
Stop/tail and rear side marker
lightSTEP3
STEP4

385 4-3. Do-it-yourself maintenance
4
Maintenance and care
■License plate lights
Open the back door and remove
the cover.
To protect the cover, place a rag
between the flathead screwdriver
and the cover, as shown in the
illustration.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
■LED high mounted stoplight
The high mounted stoplight consists of a number of LEDs. If any of
the LEDs burn out, take your vehicle to your Toyota dealer to have
the light replaced.
STEP1
STEP2
STEP3

490 Alphabetical index
Child safety
Airbag precautions ..................80
Battery precautions ....... 346, 429
Child restraint system..............90
Child-protectors .......................32
How your child should wear
the seat belt ..........................50
Installing child restraints ..........94
Moon roof precautions ............63
Power window lock switch.......59
Power window precautions .....60
Removed key battery
precautions ......................... 368
Seat belt extender
precautions ...........................52
Seat belt precautions ..............51
Child-protectors .........................32
Cleaning
Exterior .................................. 314
Interior ................................... 317
Seat belts .............................. 318
Clock ......................................... 292
Compass ................................... 309
Condenser ................................ 342
Console box ............................. 284
Cooling system
Engine overheating ............... 430
Cruise control........................... 148
Cup holder ................................ 285
Curtain shield airbags ...............73
Customizable features............. 469Daytime running light
system .................................... 140
Defogger
Rear window ......................... 193
Side mirror ............................ 193
Dimension ................................ 438
Dinghy towing .................. 181, 182
Display
Trip meter.............................. 132
Do-it-yourself maintenance .... 326
Doors
Door lock ........................... 28, 31
Door windows ......................... 59
Side mirrors............................. 57
Driver's seat belt reminder
light ......................................... 400
Driving
Break-in tips .......................... 109
Correct posture ....................... 71
Procedures............................ 106
Winter driving tips ................. 162D
