2013 TOYOTA LAND CRUISER key

671 6-1. Specifications
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Ignition system
Electrical system
Spark plug
Make DENSO
GapSK20HR11
0.043 in. (1.1 mm)
NOTICE
■Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine.
Battery
Open voltage at
68F (20C):12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11 . 8  12.0 V Discharged
(Voltage is checked 20 minutes after
the key is removed with all lights
turned off.)
Charging rates5 A max.

693 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Customizable features
Vehicle customization settings can be changed at your Toyota dealer.
For vehicles with the navigation system, some settings can be
changed using the touch screen.
Settings that can be changed using the touch screen
Settings that can be changed using the vehicle switches
Settings that can be changed by your Toyota dealer
Definition of symbols: O= Available, — = Not available
ItemFunctionDefault
settingCustomized
setting
Smart key
system
(P. 32)Smart key
systemOn Off O — O
Smart door
unlockingDriver’s door All the doors O O O

694 6-2. Customization
LC200_OM_OM60F57U_(U)
Wireless
remote
control
(P. 44)Wireless remote
controlOn Off — — O
Open door warn-
ing function
(when locking the
vehicle)On Off — — O
Unlocking opera-
tionDriver’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one stepO—O
Smart key
system
(P. 32)
and
wireless
remote
control
(P. 44) Operation signal
(Emergency
flashers)On Off O — O
Time elapsed
before automatic
door lock function
is activated if
door is not
opened after
being unlocked60 secondsOff
O—O 30 seconds
120 seconds
Adjust the vol-
ume of confirma-
tion buzzer
sounds when the
vehicle is locked
or unlocked7Off
O—O
1 to 6
ItemFunctionDefault
settingCustomized
setting

695 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
Door lock
(P. 46)Unlocking using a
mechanical keyDriver’s door
unlocked in
one step, all
doors
unlocked in
two stepsAll doors
unlocked in
one stepO—O
Speed-detecting
automatic door
lock functionOff On O O O
Shifting the shift
lever to position
other than “P”
locks all doorsOn Off O O O
Shifting the shift
lever to “P”
unlocks all doorsOn Off O O O
Opening driver’s
door unlocks all
doorsOff On O O O
Power
windows
(P. 93)Mechanical key
linked operation
(close)Off On — — O
Mechanical key
linked operation
(open)Off On — — O
Wireless remote
control linked
operation (open)Off On — — O
Linked entry
functionOff On — — O
ItemFunctionDefault
settingCustomized
setting

696 6-2. Customization
LC200_OM_OM60F57U_(U)
Moon roof
(P. 97)Mechanical key
linked operation
(open)
*1Off On — — O
Mechanical key
linked operation
(close)
*1Off On — — O
Linked operation
of components
when door key is
usedSlide only Tilt only — — O
Wireless remote
control linked
operation
(open)
*2
Off On — — O
Linked operation
of components
when wireless
remote control
usedSlide only Tilt only — — O
Linked entry
function
*3Off On — — O
ItemFunctionDefault
settingCustomized
setting

697 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
ItemFunctionDefault
settingCustomized
setting
Illumination
(P. 462)Time period
before the interior
lights turn off15 secondsOff
O—O 7.5 seconds
30 seconds
Operation after
the “ENGINE
START STOP”
switch is turned
offOn Off — — O
Operation when
the doors are
unlockedOn Off — — O
Operation when
you approach the
vehicle with the
electronic key on
your person
(When the inte-
rior light switch is
door position)On Off — — O
Sensitivity of the
ambient light sen-
sor used for dim-
ming the meter
lights etc.Standard -2 to 2 — — O
Sensitivity of the
ambient light sen-
sor used for
brightening the
meter lights etc.Standard -2 to 2 — — O

699 6-2. Customization
6
Vehicle specifications
LC200_OM_OM60F57U_(U)
*1: The settings can be changed when the mechanical key linked operation of
the power window is set to ON.
*2: The settings can be changed when the wireless remote control linked oper-
ation of the power window is set to ON.
*3: The settings can be changed when the entry function linked operation of the
power window is set to ON.
■Vehicle customization
●If the smart key system is turned “OFF”, unlock door cannot be selected.
●If the doors are not opened after unlocking and are then automatically re-
locked, a signal will be given if “Operation signal (Emergency flashers)”
or “Operation signal (Buzzer)” are set to ON.
■When setting using the vehicle switches (vehicles with navigation sys-
tem)
When using the vehicle switches to set an item that can also be set using the
touch screen, the item displayed on the touch screen will not change imme-
diately.
If the “ENGINE START STOP” switch is first turned to OFF, the screen dis-
play will change once the “ENGINE START STOP” switch is turned to IGNI-
TION ON mode again.
■When customizing using the touch screen (vehicles with navigation
system)
Stop the vehicle in a safe place, apply the parking brake, and shift the shift
lever to “P”. Also, to prevent battery discharge, leave the engine running
while customizing the features.

709 Alphabetical index
LC200_OM_OM60F57U_(U)
Back door
Back door ............................... 51
Wireless remote control key ... 44
Back-up lights
Replacing light bulbs ............ 581
Wattage ................................ 675
Battery
If the vehicle has discharged
battery ............................... 654
Preparing and checking
before winter ...................... 310
Bluetooth
® audio
(vehicles without
navigation system) ............... 402
Bluetooth
® audio
(vehicles with
navigation system)
*
Bluetooth® phone (vehicles
without navigation
system ................................... 423
Bluetooth
® phone (vehicles
with navigation system)
*
Bottle holder ............................ 472
Brake
Fluid...................................... 536
Parking brake ....................... 177
Brake assist ............................. 282
Break-in tips ............................ 155
Brightness control
Instrument light control ......... 182Care
Exterior ..................................512
Interior ...................................515
Seat belts ..............................516
Card holder ...............................474
Cargo capacity .........................302
Cargo net hooks.......................495
CD player
*/changer*...............365
Center differential
lock/unlock switch.................240
Chains .......................................312
Child-protectors .........................47
Child restraint system
Booster seats, definition ........135
Booster seats, installation .....140
Convertible seats,
definition .............................135
Convertible seats,
installation ...........................140
Front passenger occupant
classification system ...........129
Infant seats, definition ...........135
Infant seats, installation.........140
Installing CRS with
LATCH system....................141
Installing CRS with
seat belts ............................143
Installing CRS with top
tether strap..........................148
BC
*: For vehicles with a navigation system,
refer to the “Navigation System Owner’s Manual”.
