5
When trouble arises
623 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle.Indicates that all main-
tenance according to
the driven distance on
the maintenance
schedule
* should be
performed soon.If necessary, perform
maintenance.
Comes on approxi-
mately 4500 miles
(7200 km) after the
maintenance data has
been reset.
Indicates that all main-
tenance is required to
correspond to the
driven distance on the
maintenance sched-
ule
*.Perform the necessary
maintenance.
Please reset the main-
tenance data after
the maintenance is per-
formed (P. 519) Comes on approxi-
mately 5000 miles
(8000 km) after the
maintenance data has
been reset. (The indi-
cator will not work
properly unless the
maintenance data has
been reset.)
Warning messageDetailsCorrection procedure
660 5-2. Steps to take in an emergency
LC200_OM_OM60F57U_(U)
CAUTION
■To prevent an accident or injury when inspecting under the hood of
your vehicle
●If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injury such as burns.
●Keep hands and clothing (especially a tie, a scarf or a muffler) away from
the fan and belts. Failure to do so may cause the hands or clothing to be
caught, resulting in serious injury.
●Do not loosen the radiator cap and the coolant reservoir cap while the
engine and radiator are hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
NOTICE
■When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.
■To prevent damage to the cooling system
Observe the following precautions:
●Avoid contaminating the coolant with foreign matter (such as sand or dust
etc.).
●Do not use commercially available coolant additives.
684 6-1. Specifications
LC200_OM_OM60F57U_(U)■Treadwear
The treadwear grade is a comparative rating based on the wear
rate of the tire when tested under controlled conditions on a
specified government test course.
For example, a tire graded 150 would wear one and a half (1 - 1/2)
times as well on the government course as a tire graded 100.
The relative performance of tires depends upon the actual conditions
of their use, however, and may depart significantly from the norm due
to variations in driving habits, service practices and differences in
road characteristics and climate.
■Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B and C,
and they represent the tire’s ability to stop on wet pavement as
measured under controlled conditions on specified government
test surfaces of asphalt and concrete.
A tire marked C may have poor traction performance.
Warning: The traction grade assigned to this tire is based on braking
(straight ahead) traction tests and does not include cornering (turn-
ing) traction.
■Temperature A, B, C
The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of heat and its
ability to dissipate heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the material of the tire to
degenerate and reduce tire life, and excessive temperature can lead
to sudden tire failure.
The grade C corresponds to a level of performance which all passen-
ger car tires must meet under the Federal Motor Vehicle Safety Stan-
dard No. 109.
Grades B and A represent higher levels of performance on the labo-
ratory test wheel than the minimum required by law.
718
LC200_OM_OM60F57U_(U)
What to do if...
What to do if...
A tire puncturesP. 633If you have a flat tire
The engine does not start
P. 105Engine immobilizer system
P. 647If the engine will not start
P. 654If the battery is discharged
The shift lever cannot be
moved outP. 649If the shift lever cannot be shifted
from “P”
The engine coolant temperature
gauge enters the red zone
Steam can be seen coming
from under the hood
P. 658If your vehicle overheats
The key is lostP. 650If you lose your keys
The battery runs outP. 654If the battery is discharged
The doors cannot be lockedP. 4 6Side doors
P. 5 1Back door
The horn begins to soundP. 107Alarm
The vehicle is stuck in mud
or sandP. 661If the vehicle becomes stuck
The warning light or indi-
cator light comes onP. 606If the warning light turns on
