2013 TOYOTA LAND CRUISER clock

585 4-3. Do-it-yourself maintenance
4
Maintenance and care
LC200_OM_OM60F57U_(U)■Fog light
Remove the fender liner bolts,
loose the fender liner nut and
pull down the fender liner.
Fender liner bolts
Fender liner nut
Unplug the connector while
depressing the lock release.
Turn the light bulb counterclock-
wise.
STEP1
STEP2
STEP3

587 4-3. Do-it-yourself maintenance
4
Maintenance and care
LC200_OM_OM60F57U_(U)■Front turn signal light
For the left side only: Remove
the securing bolt and move the
washer fluid filler opening.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
When installing, reverse the steps listed.
ITY43C012
STEP1
STEP2
STEP3
STEP4

588 4-3. Do-it-yourself maintenance
LC200_OM_OM60F57U_(U)■Front side marker light
For the left side only: Remove
the securing bolt and move the
washer fluid filler opening.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
When installing, reverse the steps listed.
ITY43C012
STEP1
ITY43C050
STEP2
ITY43C051
STEP3
STEP4

589 4-3. Do-it-yourself maintenance
4
Maintenance and care
LC200_OM_OM60F57U_(U)■Back-up light
Open the back door and remove
the nuts and lamp assembly.
Remove the cover.
Unclip the connector wire and
turn the bulb bases counter-
clockwise.
STEP1
STEP2
STEP3

591 4-3. Do-it-yourself maintenance
4
Maintenance and care
LC200_OM_OM60F57U_(U)■Rear turn signal light
Open the back door and remove
the bolts and lamp assembly.
Use a cloth to prevent scratches.
Unclip the connector wire.
Turn the bulb bases counter-
clockwise.
STEP1
STEP2
STEP3

593 4-3. Do-it-yourself maintenance
4
Maintenance and care
LC200_OM_OM60F57U_(U)■License plate light
Open the back door and remove
the license plate light unit.
Turn the bulb base counterclock-
wise.
Remove the light bulb.
When installing, reverse the steps listed.
STEP1
ITY43C067
STEP2
ITY43C068
STEP3
STEP4

710 Alphabetical index
LC200_OM_OM60F57U_(U)
Child safety
Airbag precautions ................122
Battery precautions ....... 541, 565
Child-protectors ....................... 47
Child restraint system............135
How your child should wear
the seat belt ..........................81
Installing child restraints ........ 140
Moon roof precautions .......... 100
Power window lock switch....... 93
Power window precautions .....96
Removed key battery
precautions .........................563
Seat belt extender
precautions ...........................84
Seat belt precautions ..............82
Seat heater precautions ........ 490
Cigarette lighter ....................... 484
Cleaning
Exterior .................................. 512
Interior ...................................515
Seat belts ..............................516
Clock (vehicles without
navigation system). ............... 479
Clock (vehicles with
navigation system)
*
Condenser ................................535
Console box ............................. 468
Cool box.................................... 475
Cooling system
Engine overheating ............... 658
Crawl Control ...........................245
Cruise control...........................210
Cup holder ................................470
Curtain shield airbags ............. 113
Customizable features............. 692Daytime running light
system .................................... 199
Defogger
Rear window ......................... 351
Side mirror ............................ 351
Dimension ................................ 666
Dinghy towing .......................... 333
Display
Crawl Control display ............ 245
Dynamic radar cruise
control ................................. 214
Intuitive parking assist
display ................................ 229
Multi-information display ....... 189
Shift position and shift
range .................................. 173
Trip information ..................... 190
Warning messages ............... 617
Do-it-yourself maintenance .... 524
Door courtesy lights
Door courtesy lights .............. 462
Wattage................................. 675
Door lock
Back door ................................ 51
Side door................................. 46
Wireless remote control key.... 44
Doors
Back door ................................ 51
Side door................................. 46
Side mirrors............................. 90
Driver’s seat belt reminder
light ......................................... 609
Driving
Break-in tips .......................... 155
Correct posture ..................... 111
Off-road precautions ............. 297
Procedures............................ 154
Winter driving tips ................. 310
Driving position memory .......... 68
Dynamic radar cruise
control .................................... 214
D
