2013 TOYOTA AVALON HYBRID Owners Manual

2975-4. Using the storage features
5
Interior features
AVALON_HV_U (OM41451U)
NOTICE
■To prevent damage to the hooks
Do not apply too much load to the hooks.

298
AVALON_HV_U (OM41451U)
5-5. Other interior features
To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.
Open the cover to use.
The light turns on when the cover
is opened.
Sun visors and vanity mirrors
Sun visors
1
2
3
Vanity mirrors
NOTICE
■ To prevent 12-volt battery discharge
Do not leave the vanity lights on for extended periods while the hybrid sys-
tem is off.

2995-5. Other interior features
5
Interior features
AVALON_HV_U (OM41451U)
Ty p e AAdjusts the hours
Pressing and holding the button
adjusts the hours forward
quickly 1 hour at a time.
Adjusts the minutes
Pressing and holding the button
adjusts the minutes forward
quickly by 1 minute at a time. If
the button is pressed and held
for 5 seconds or more, the min-
utes move forward by 5 minutes
at a time.
Ty p e B
Adjusts the hours
Pressing and holding the button
adjusts the hours forward
quickly 1 hour at a time.
Adjusts the minutes
Pressing and holding the button
adjusts the minutes forward
quickly by 1 minute at a time. If
the button is pressed and held
for 5 seconds or more, the min-
utes move forward by 5 minutes
at a time.
Clock
The clock can be adjusted by pressing the buttons.
1
2
1
2

3005-5. Other interior features
AVALON_HV_U (OM41451U)
■The clock is displayed when
The power switch is in ACCESSORY or ON mode.
■ When disconnecting and reconnect ing 12-volt battery terminals
Type A
The time display will automatically be set to 12:00 AM.
Type B
The time display will automatically be set to 12:00.
■ Time display (Type B)
After pressing “H” or “M” to show the setting screen, press “H” and “M” at the
same time to change between the analog and digital displays.

3015-5. Other interior features
5
Interior features
AVALON_HV_U (OM41451U)
■The outside temperature is displayed when
The power switch is in ON mode.
■ Display
In the following situations, the correct outside temperature may not be dis-
played, or the display may take longer than normal to change.
●When the vehicle is stopped, or moving at low speeds (less than 9 mph [15
km/h]).
● When the outside temperature has changed suddenly (at the entrance/exit
of a garage, tunnel, etc.)
■ When “--- F” is displayed
The system may be malfunctioning. Take your vehicle to your Toyota dealer.
Outside temperature display
The temperature display shows temperatures within the
range of -40 F (-40 C) to 122 F (50 C).
Ty p e AType B
9ò

3025-5. Other interior features
AVALON_HV_U (OM41451U)■
Console box
Power outlets
The power outlets can be used for 12 V accessories that run on
less than 10 A.

3035-5. Other interior features
5
Interior features
AVALON_HV_U (OM41451U)■
Instrument panel
■
The power outlets can be used when
The power switch is in ACCESSORY or ON mode.
Ty p e AType B
NOTICE
■To avoid damaging the power outlets
Close the power outlet lids when the power outlets are not in use.
Foreign objects or liquids that enter the power outlets may cause a short cir-
cuit.
■ To prevent blown fuse
Do not use an accessory that uses more than 12 V 10 A.
■ To prevent 12-volt battery discharge
Do not use the power outlets longer than necessary when the hybrid system
is off.

3045-5. Other interior features
AVALON_HV_U (OM41451U)■
Front seats
Vehicles with ventilator
Press the knob to release it,
and turn the knob to the
desired temperature setting.
OFF
Press the knob to lock it when
not in use.
Ventilation
Heat
Vehicles without ventilator
Press the knob to release it, and
turn the knob to the desired tem-
perature setting.
The further you turn the knob
clockwise, the warmer the seat
temperature becomes. Turn the
knob counterclockwise all the way
to turn the system off.
Press the knob again to lock it
when not in use.
Seat heaters/seat ventilators
: If equipped
The seat heaters warm the seats and the seat ventilators main-
tain good airflow by blowing air through the seats.
Seat heaters/ventilators
CTY57AX039
1
2
3
4
