2013 PORSCHE 911 CARRERA Tequipment Manual

Exterior · 17
16 · Exterior
Wheel/tyre set9 11 C a r r e r a
9 11 C a r r e r a S
9 11 C a r r e r a 4
9 11 C a r r e r a 4 S
9 11 T u r b o
9 11 T u r b o S
9 11 G T 3
Wheel dimensions
(offset (ET) in mm) Tyre specifications
20-inch Carrera S wheels
with summer tyres
1, 6• –––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 70 Front:
245/35 ZR 20 (91Y)
Rear: 295/30 ZR 20 (101Y) XL
–• ––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 52 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
20-inch Carrera S wheels
in satin platinum
with summer tyres
1, 6
• –––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 70 Front:
245/35 ZR 20 (91Y)
Rear: 295/30 ZR 20 (101Y) XL
–• ––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 52 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
Wheel/tyre set9 11 C a r r e r a
9 11 C a r r e r a S
9 11 C a r r e r a 4
9 11 C a r r e r a 4 S
9 11 T u r b o
9 11 T u r b o S
9 11 G T 3
Wheel dimensions
(offset (ET) in mm) Tyre specifications
20-inch SportDesign wheels
with summer tyres
• –––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 70 Front:
245/35 ZR 20 (91Y)
Rear: 295/30 ZR 20 (101Y) XL
–• ––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 52 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
20-inch SportTechno wheels
with summer tyres 3, 6• –––Front: 9 J x 20 ET 51
Rear: 11.5 J x 20 ET 68 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
–• ––Front: 9 J x 20 ET 51
Rear: 11.5 J x 20 ET 48 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
For footnotes, please refer to page 21.

18 · Exterior Exterior · 19
Note on the use of winter tyres
Summer t yres provide optimum
performance at ambient temperatures
above +7 °C. Below this point, the t yre
compound begins to harden and braking
distances are increased. We therefore
recommend that you fit winter t yres
during the colder months of the year so
that you can drive your 911 safe in the
knowledge that it will continue to meet our high standards for driving safet y

even at low temperatures. All winter t yres
approved by Porsche are identifiable
by the ‘N’ designation on the sidewall. The
crucial advantage of winter t yres is that they reduce braking distances at low

temperatures (below +3
°C).
Wheel/tyre set9 11 C a r r e r a
9 11 C a r r e r a S
9 11 C a r r e r a 4
9 11 C a r r e r a 4 S
9 11 T u r b o
9 11 T u r b o S
9 11 G T 3
Wheel dimensions
(offset (ET) in mm) Tyre specifications
20-inch Carrera S wheels
with winter tyres
5• –––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 70 Front:
245/35 R 20 91V M+S
Rear: 295/30 R 20 97V M+S
–• ––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 52 Front:
245/35 R 20 91V M+S
Rear: 295/30 R 20 97V M+S
19-inch Carrera wheels
with winter tyres• –––Front: 8.5 J x 19 ET 54
Rear: 11 J x 19 ET 69 Front:
235/40 R 19 92V M+S
Rear: 285/35 R 19 99V M+S
–• ––Front: 8.5 J x 19 ET 54
Rear: 11 J x 19 ET 48 Front:
235/40 R 19 92V M+S
Rear: 295/35 R 19 100V M+S
Wheel/tyre set9 11 C a r r e r a
9 11 C a r r e r a S
9 11 C a r r e r a 4
9 11 C a r r e r a 4 S
9 11 T u r b o
9 11 T u r b o S
9 11 G T 3
Wheel dimensions
(offset (ET) in mm) Tyre specifications
20-inch Carrera S wheels
painted in black (high-gloss)
with summer tyres
1, 6
• –––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 70 Front:
245/35 ZR 20 (91Y)
Rear: 295/30 ZR 20 (101Y) XL
–• ––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 52 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
20-inch Carrera Classic wheels
with summer tyres 1, 6• –––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 70 Front:
245/35 ZR 20 (91Y)
Rear: 295/30 ZR 20 (101Y) XL
–• ––Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 52 Front:
245/35 ZR 20 (91Y)
Rear: 305/30 ZR 20 (103Y) XL
For footnotes, please refer to page 21.

Exterior · 21
20 · Exterior
Braking with ABS on wet road surface
(49-0 mph) at +3 °C
Braking with ABS on snow
(24-0 mph)
With winter tyres
With winter tyres With summer t yres
With summer t yres
How tyres influence braking performance:
Tyre type SizeFuel efficiency
class/rolling
resistance Wet grip class
External
rolling noise*
class
External
rolling noise
(dB)
Summer t yres 235/40 ZR 19
285/35 R 19
295/35 ZR 19
245/35 ZR 20
295/30 ZR 20
305/30 ZR 20 E
E
E
F
E
EB
C
B
A
A
A68
70
71
71
74
74
Winter t yres 235/40 R 19
285/35 R 19
245/35 R 20
295/30 R 20 E
C
E
CC
C
C
C
72
73
72–70
74 –7 3
Fuel efficiency class, wet grip class, rolling noise:
For logistical and technical reasons relating to the production process, we are unable to accept orders
for a par ticular make of t yre.
*
Quiet rolling noise,Moderate rolling noise,Loud rolling noise.
Wheel/tyre set9 11 C a r r e r a
9 11 C a r r e r a S
9 11 C a r r e r a 4
9 11 C a r r e r a 4 S
9 11 T u r b o
9 11 T u r b o S
9 11 G T 3
Wheel dimensions
(offset (ET) in mm) Tyre specifications
20-inch Turbo wheels with
winter tyres
– –•–Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 56 Front: 245/35 R 20 91V M+S
Rear: 295/30 R 20 97V M+S
20-inch Turbo S wheels
with winter tyres–
–•–Front: 8.5 J x 20 ET 51
Rear: 11 J x 20 ET 59 Front: 245/35 R 20 91V M+S
Rear: 295/30 R 20 97V M+S
–
––•Front: 9 J x 20 ET 51
Rear: 11 J x 20 ET 59 Front: 245/35 R 20 91V M+S
Rear: 295/30 R 20 97V M+S
For footnotes, please refer to page 21. • Compatible
– Not compatible
1 Optional: use of 5 mm spacers on front and
rear axles to widen track.
2 Winter t yres up to max. 149 mph.3 Not compatible with 5 mm wheel spacers (XRP).4 Compatible with snow chains if no spacers fit ted.5 Not compatible with snow chains – for winter t yres only.
6 The wheel centres shown are not included, except in the case of the 20 - inch Carrera S wheels in satin
platinum or black (high -gloss). If your vehicle docu -
ments do not contain details of the correct wheel and
tyre combination, please request a technical approval
cer tificate from your Porsche Centre. All t yres are
designed exclusively for Porsche as indicated by the
special Porsche designation (N0, N1, etc.) on the
sidewall. Tyres that do not carr y this designation are
not recommended for use on your Porsche.
100 105 11 0 115
Approx. 19 % shor ter braking distanceApprox. 12 % shor ter braking distance
Example:
Braking distance in % (measured with the use of tyres conforming to the\
Porsche specification).
Braking distances optimised by the use of Porsche winter tyres. Absolute values may vary.

[3] Anti-theft wheel protection
Set of four wheel bolts with highly secure
Thatcham-approved locking system.
[4] Wheel bolts in black including
anti-theft protection (not shown)
Set of 20 wheel bolts in black, four of
which are anti-theft wheel bolts. Two
versions available: for vehicles with and
vehicles without 5 mm spacers.
[1] Snow chains
Specially designed for Porsche models
and featuring ultra-fine links for minimal
adhesion of ice and snow. Set of t wo
for rear axle.
Not compatible with wheel spacers.
[2] Wheel centres
Set of wheel centre caps with full- colour
Porsche Crest. The perfect finishing touch
for the wheels of your 911.
Exterior · 23
22 · Exterior
[5] Wheel spacers
Wheel spacers create a wider track for
enhanced stability and presence on
the road. When fit ted, your 911 will look
even sportier, as the wheels run virtually
flush with the body of the car. Package
comprises a set of four spacers (5 mm)
including a set of 20 wheel bolts in black,
four of which are anti-theft wheel bolts.
[6] Crested valve caps
Silver- coloured valve caps with embossed
Porsche Crest.
For vehicles with TPM
1 or without TPM1
(not shown).
1 Tyre pressure monitoring.
1 2 3
6
5

24 · Performance
The power concept.
Purposefully redefined.
The 911 and motorsport make an insepa -
rable team. The knowledge we gain on
racetracks all over the world is constantly
being put to use to the benefit of our
production cars. The result is tangible in
the form of continuously improved perfor -
mance, down to the last detail. And the
best thing about it? You have the abilit y
to improve it further still thanks to the
Porsche Tequipment range of accessories.
Whether it ’s a sports exhaust system or a
Powerkit engine upgrade, all our products
focus on one goal: to enhance the perfor -
mance of your Porsche, and to give you
even more driving pleasure.
Performance

Performance · 27
26 · Performance
The only alternative to power?
Even more power. In plain figures, we have managed to
increase power output from 294 kW

(400 hp) to 316 kW (430 hp) and improve
acceleration from 0 to 62 mph by
0.1 seconds. The 911 Carrera S models
with PDK1 and SPORT PLUS but ton complete
the sprint in an impressive 4.0 seconds.
The fastest variant in the range reaches a
top speed of 191 mph. To develop the Powerkit, a number of
sophisticated measures were needed.

The cylinder head intake ports have been
reworked and given a polished finish.
The stroke of the intake camshaft has
been increased and the electronic engine
management adapted accordingly. The highlight of the Carrera S Powerkit is
the newly developed variable resonance
intake manifold with six plus one switchable
valves. This innovation enables the system
to switch bet ween power- and torque-
optimised geometries and deliver a boost
in power output, particularly in the upper
speed range. The extra heat generated by this power increase is dissipated by an
additional centre radiator.
Other components include the sports
exhaust system with t wo specially designed
twin tailpipes and the titanium-coloured
engine cover featuring inlays in carbon. Some models may require additional

components. (Please see fit ting and
conversion instructions.)1 7-speed Porsche Doppelkupplung (PDK).
The 911 was born out of passion for the
sports car. The source of this passion
can be traced back to the Porsche Devel-
opment Centre in Weissach. Here, our
designers and engineers give their all to produce breakthrough after breakthrough.
The most recent accomplishment is the
new Carrera S Powerkit – available for

the 911 Carrera S models (t ype 991).
911 Carrera S/911 Carrera 4S models with Powerkit
911 Carrera S/911 Carrera 4S models series
For fuel consumption and C02 emissions, please refer to page 63.
300
380 400 420 440
460
280 290 300 310 320 330
1000
7000
1500 20002500 3000350040004500 5000550060006500 320
340
3608000
7500 480 500
230 240
250 260 270
Engine speed (rpm)
T orque (Nm)
Power output (kW)
911 Carrera S Coupé/911 Carrera 4S Coupé models with manual transm\
ission/PDK
Performance
911 Carrera S911 Carrera 4S
Top speed 191 m p h / 19 0 m p h188 mph/187 mph
0 – 62 mph 4.4 secs/4.2 secs4.4 secs/4.2 secs
0 – 62 mph with
SPORT PLUS button –/4.0 secs
–/4.0 secs
Flexibility/
overtaking acceleration
(49 –74 m p h ) 5.9 secs/2.4 secs
5t h ge a r/–
6.0 secs/2.5 secs
5t h ge a r/–
911 Carrera S Cabriolet/911 Carrera 4S Cabriolet models with manual transmission/PDK
Performance
911 Carrera S Cabriolet
911 Carrera 4S Cabriolet
Top speed 189 mph/188 mph18 6 m p h / 185 m p h
0 – 62 mph 4.6 secs/4.4 secs4.6 secs/4.4 secs
0 – 62 mph with
SPORT PLUS button –/4.2 secs
–/4.2 secs
Flexibility/
overtaking acceleration
(49 –74 m p h ) 6.2 secs/2.5 secs
5t h ge a r/–
6.3 secs/2.7 secs
5t h ge a r/–

1
28 29
3
2
1
1
28 · Performance Performance · 29
[1] Sports exhaust system
The t ypical Porsche sound – powerful,
robust and sport y. Bet ter still, it can
be further enhanced thanks to the sports
exhaust system, featuring a modified
silencer and specially designed t win dual-
tube tailpipes. By simply pressing the but ton integrated in the right half of the
control panel, the sound will vary with
driving behaviour, ranging from a robust
output during normal road driving to a

distinctively more aggressive tone during
performance use. The specially designed
tailpipes are included as standard. Some models may require additional

components. (Please see fit ting and
conversion instructions.)
[2] Sports tailpipes
Specially designed twin tailpipes in
chrome-plated stainless steel. Give a
sport y look to the rear of your 911.
[3] Fuel filler cap
with Aluminium Look finish
This elegant accessory is a st ylish addition
inspired by our racing heritage. Modelled
on filler caps from historic race vehicles,
it has an engraved ‘PORSCHE’ logo and
securing tether.

Interior
30 · Interior
Why should we be the only devoted
911 exterior and interior stylists?
The 911 is unmistakable on the outside
thanks to its unique silhouet te. Your
911 is unmistakable on both the outside
and the inside because the interior leaves
scope for further personalisation. After all,
this sports car was designed to reflect
your particular lifestyle and symbolise
freedom. Creative freedom included.
