Strength

| The 911 Carrera
Meetings, conferences, business lunches.
How about some leisure in between?

The 911 Carrera.
In the 21st century, we find ourselves
caught bet ween all kinds of opposites on
a daily basis: bet ween the demands of
our work life and our private life, between
the real world and virtual realit y. How can
they all be reconciled? With a strong iden ­
tit y and a sports car that has incorporated
many contradictory notions since 1963.
Sportiness and everyday practicality
are a prime example. The 911 Carrera is
equipped as standard with direct fuel
injection (DFI) and VarioCam Plus for high
power, high torque, efficient combustion
and, as a result, comparatively low fuel
consumption. Tradition and innovation blend seamlessly
together in the rear
­mounted 3.4 ­litre
flat ­six engine thanks to its downsized
capacity. Despite the reduced displace ­
ment, the engine is capable of delivering
even more power to the road than its
3.6 ­litre predecessor.
The figures speak for themselves. The
maximum power of 257 kW (350 hp) is
available at 7,400 rpm and the maxi ­
mum torque of 390 Nm is generated at
5,600 rpm. Yet, in conjunction with
Porsche Doppelkupplung (PDK), fuel con ­
sumption and CO
2 emissions have been
reduced by 16 % compared with the pre ­
vious model. Even more impressively, the
car accelerates from 0 to 62 mph in
4.8 seconds and reaches a top speed
of 179 mph.
The 911 Carrera generates powerful
forces, which are transmit ted precisely
and directly to the wheels by the 7 ­speed
manual gearbox. As with the optional PDK,
gears 1 to 6 have a sports ratio, while
7th gear has a long ratio for reduced fuel
consumption. The SPORT but ton, which
is fit ted as standard, makes it possible to
select an even more responsive engine
and transmission setup.
In terms of form and function, the single
tailpipes are especially imposing and emit a sound which is t ypically Porsche. The
19
­inch Carrera wheels are fit ted as
standard and improve driving stability
and performance.
Sports car technology as standard, in
the form of black four ­piston monobloc
aluminium fixed calipers, Porsche Stability
Management (PSM) and Bi ­Xenon head ­
lights, shows that sportiness and safety
are not mutually exclusive.
Sport, moderation, everyday practicality
and st yle. Four key themes, one unifying
concept: the 911 Carrera.
For fuel consumption and CO
2 emissions, please refer to pages 143/145.

5455
Temperament

| Chassis and body
“That can’t be done.”
If ever a sentence gave motivation to sports car designers, this is it.

Chassis and body.
A solid identit y tends to be described
with words like stability, directness or
substance. This might sound a lit tle
serious but, when it comes to the chassis
and body, we think that this is entirely
the right approach.
The best example is the engineered
design. Indeed, dynamic per formance
and ride comfort fundamentally depend
on factors such as vehicle weight, body
rigidity, wheelbase, axle construction
and steering. With the 911, we challenged
our engineers to push the boundaries
of what is possible. Chassis control systems make a key

contribution to the 911 driving experience
and thus to the 9 11 i d e n t i t y. T h e s e
include Porsche Stability Management
(PSM), Porsche Active Suspension

Management (PASM), which comes as
standard in the 911 Carrera S models,
Porsche Torque Vectoring Plus (PTV Plus).
Porsche Dynamic Chassis Control (PDCC)
is additionally available as an option for
the
9 11 Carrera S models.
Yet, there is still scope for improvement
as far as sport y performance is

concerned. The optional Sport Chrono Package triggers an adrenaline rush

at the push of a but ton. Dynamic engine
mounts, until now exclusively reserved

for 911 GT and Turbo models, may not be
capable of breaking the laws of physics
but they do succeed in exploiting them

to their own advantage – and yours.

5657
Temperament

| Chassis and body
Engineered design.
The innovative bodyshell of the 911 fulfils
t wo structural design requirements: first,
excellent driving dynamics due to the
body’s extremely high rigidit y; second,
a vehicle weight saving of up to 65 kg
primarily as a result of the intelligent
lightweight construction. To meet the second requirement, we
employed state
­of­ the ­art techniques for
combining various materials in order
to utilise specific material properties
exactly where they are needed.
For the bodyshell, therefore, we used
very thin, but nevertheless extremely
rigid, sheets of steel. Aluminium and magnesium were used extensively in
areas such as the roof, underbody, front
end, doors, rear wings and engine com
­
partment and luggage compartment lids.
Magnesium, which is a particularly light ­
weight material, was also selected for
the cockpit and centre console support
beam and, in the Cabriolet models, the
hood shell elements. Such material effi ­ciency is key to reducing the overall
weight and, as a result, fuel consumption
of the vehicle.
For the driver, this intelligent blend

of materials reduces the weight of the
vehicle and offers a high level of comfort
thanks to excellent vibration ­damping
characteristics and particularly high com ­
posite rigidit y, an increase in dynamic
torsional stiffness of up to 25 % compared
with that of the previous model, and
even
sportier handling despite a further
improvement in the weight to power ratio.
The longer wheelbase improves comfort
as well as straight ­line accuracy and
driving stabilit y at high speeds and in
fast corners.

Front and rear axles.
The independent suspension at the front
features a light weight spring ­strut axle
with longitudinal and transverse links and
cross members that have been refined
for stiffness. Each front wheel is precisely
located, ensuring excellent directional stability, superior handling and reduced
pitching under braking, and the wide
track optimises turn
­in.
The rear axle is equipped with a
motorsport ­derived multi ­link suspension
and chassis subframe. Refined axle
kinematics for improved longitudinal
damping reduce acceleration squat and increase comfort. Light weight spring
struts further enhance agilit y.
The high proportion of aluminium used in
the construction of the axles reduces the
weight of the vehicle and of the unsprung masses, helping to improve fuel economy,
comfort and agility.
Rear axle of the 911 Carrera S
Front axle of the 911 Carrera S
Aluminium
Deep
­drawn steels
Multiphase steels
Super ­high ­strength micro ­alloyed steels
Boron ­alloyed steels

5859
T
emperament
| Chassis and body
Hood.
Our engineers have completely redeveloped
the hood for the 911 Carrera Cabriolet
models. The result is a flexible roof
comprising a glass rear screen and three
individual and integral hood elements,
which are manufactured from magnesium
and covered in fabric. This makes the
hood highly robust and, yet, particularly
lightweight.
Another benefit is that the hood is
smooth and firm. The fabric remains taut
keeping the familiar 911 lines elegant. A trivialit y? Only if you choose to ignore
the impressively low drag coefficient

of just 0.30 for the 911 Carrera Cabriolet
models. A further feat of Porsche
engineering.
The rear screen is made from glass and
is electrically heated and scratch ­
resistant to provide excellent rearward
visibilit y. A rain channel on the hood
carries away water to avoid dripping
when the doors are opened.
Electrically powered, the hood is operat ­
ed using a but ton on the centre console
or via the key remote. It opens or closes in just 13 seconds and remains operable
up to a speed of 31 mph. The concertina
action ensures optimum protection for
the interior lining.
The interior hood lining is made from

a heat ­insulating and sound ­absorbing
material. Consistent interior temperatures
and an effective suppression of wind
noise are the perceptible results. Thank ­
fully, however, even the hood’s sound ­
proofing properties are no match for
the resonant Porsche sound.
Open, flexible, independent.
The optimum prerequisites for a long-term relationship.

Cabriolet technology.

6869
Temperament

| Chassis and body
On activation of SPORT PLUS mode,
Porsche Active Suspension Management
(PASM) and, in the 911 Carrera S models,
optional Porsche Dynamic Chassis Control
(PDCC) switch to a harder damping set
­
ting and offer more direct steering and,
therefore, better road holding.
In SPORT PLUS mode, the trigger thresh­
old for PSM is raised. Agilit y is perceptibly
enhanced when braking for corners with
PSM, allowing sportier braking and exit
acceleration. For maximum dexterit y, PSM
can be set to standby while the car is
still in SPORT PLUS mode. For safet y, it
is set to intervene automatically only
when ABS assistance is required on both
the front wheels.
In combination with PDK, the Sport
Chrono Package has t wo additional

functions for a sport y drive that borders
on a motorsport experience. The first

is ‘Launch Control’, which can be used on the track to achieve the best possible
standing start – a racing start.
The second function is the ‘motorsport
­
derived gearshif t strategy’. Using this,
Porsche Doppelkupplung (PDK) is geared
up for extremely short shift times and
optimum shift points for the maximum acceleration available. This combination
of uncompromising and involving perfor
­
mance is ideal for the racetrack.
A key component of the Sport Chrono
Package is the stopwatch mounted on
the dashboard. In conjunction with the
standard PCM, a special performance
display enables you to view, store and
evaluate lap times or other driving
times. It shows the total driving time,
lap distance, lap number and lap times
re c o rde d s o f a r.
A feature of the Sport Chrono Package
borrowed from motorsport is the dynamic
engine mounts. These exploit the laws

of physics for your own driving pleasure.
Dynamic engine mounts.
You don’t have to take the 911 onto the
racetrack. But you can, more so than
ever, because dynamic engine mounts
are now included as part of the Sport
Chrono Package.
The electronically controlled system mini­
mises the oscillations and vibrations of the
entire drivetrain, especially the engine, and
combines the benefits of a hard or soft
engine mounting arrangement.
A hard engine mounting delivers optimum
dynamic performance because it offers
the highest degree of handling precision
possible. Soft engine mounts, on the
other hand, minimise oscillations and
vibrations. While comfort is improved on
uneven road surfaces, this comes at

the expense of dynamic performance.
Our engineers have solved this problem
by enabling the engine mounts to adapt
their stiffness and damping properties to
changes in driving st yle and road surface
conditions. This has been achieved by
use of a fluid with magnetic properties in
interaction with an electrically generated field. For the driver, the results are tangi
­
ble. Handling is perceptibly more stable
under load change conditions and in
fast corners. Whenever a less assertive
driving st yle is adopted, the dynamic
engine mounts provide a higher level of
comfort.

7879
From the start, Porsche has been
synonymous with motorsport. Ever since
1948, when we found our identit y on
the racetrack, we have taken the experi ­
ence we have gained and applied it to
the road. The optional Porsche Ceramic
Composite Brake (PCCB) is a fine example.
This brake system has already had to
cope with the harshest requirements of
Composure | Safet y
motor racing and is fit ted in cars that
compete in demanding events such as
the Porsche Mobil 1 Supercup.
The cross ­drilled PCCB ceramic brake
discs for the 911 Carrera have a diame ­
ter of 350 mm front and rear for even
more formidable braking performance. What we’ve discovered from over 30,000 racing victories:
Brake later, finish sooner.

Porsche Ceramic Composite Brake (PCCB).The use of six ­piston aluminium monobloc
brake calipers on the front axle and four ­
piston units at the rear – all finished in
yellow – ensures extremely high brake
forces which, crucially, are exceptionally
consistent.
PCCB enables shorter braking distances
in even the toughest road and race condi ­
tions. Excellent fade resistance ensures
greater balance when slowing from race ­
track speeds.
The key advantage of PCCB is the extreme ­
ly low weight of the ceramic brake
discs,
which are approximately 50 % lighter than
standard discs of similar design and size.
As well as enhancing performance and fuel economy, this represents a major
reduction in unsprung and rotating mass
­
es. The consequence of this is bet ter
road holding and increased comfort, par ­
ticularly on uneven roads, as well as
greater agility and improved handling.
Please note that circuit racing, track
day use and other forms of performance
driving can significantly reduce the
service life of even the most durable
brake pads and discs.
As with conventional high ­performance
braking systems, we recommend that
all brake components be professionally
inspected and replaced where necessary
after every track event.
For fuel consumption and CO
2 emissions, please refer to pages 143/145.

9293
Composure
| Comfor t
Climate control.
The 911 models feature t wo
­zone auto ­
matic climate control as standard with
an enhanced ventilation effect and sepa ­
rate temperature controls for the driver
and front passenger. The available air
conditioning modes are gentle, normal
and strong.
An active carbon filter traps particles,
pollen and odours and an automatic
air ­recirculation function permanently
monitors air quality, reduces humidity

and switches from fresh to recirculated
air when required. A demister function keeps the windows
clear in cold weather. In warmer weather,
a solar sensor helps the climate control

to detect strong sunlight and automatically
compensate for the comfort of both the
driver and front passenger.
HomeLink® (programmable garage
door opener).
As an option, it is possible to have
a programmable garage door opener
integrated into the overhead console.
At the push of a but ton, it controls up
to three different garage doors, lighting
systems or alarm systems.
Many things have practical qualities.
Even more have a sporty function.
And some are just extremely convenient.

Additional comfort and convenience features.
Cruise control.
This automatic speed control function is
available as an option. For greater driver
comfort on long stretches of road, cruise
control operates in the 18–149 mph
speed range and is activated using a but ­
ton on the steering column control stalk.
Light design package.
The optional light design package is both
practical and aesthetically appealing.
It comprises dimmable LEDs in the over ­
head console and in the areas of the
door pulls, door storage compartments,
front foot wells and rear seats.
‘Welcome Home’ lighting.
For convenience, particularly at night,
the ‘Welcome Home’ lighting function
automatically switches on the LED day
­
time running lights for a defined period
whenever the vehicle is opened or
closed using the key remote.
A customisable delayed switch ­of f timer
keeps the daytime running lights, the

taillights and, where applicable, the
courtesy lights switched on until you
reach your front door.
Adaptive cruise control with Porsche
Active Safe (PAS).
Available as an option, this cruise control
function regulates your speed according
to the distance bet ween your vehicle and
the vehicle in front. A radar sensor moni ­
tors the road ahead up to a distance of
200 m. If you have set a cruising speed but have begun to gain on the vehicle in
front because it is driving more slowly,
this is detected by the radar sensor.
The system now reduces the speed

of your vehicle at a maximum rate of
3.5 m/sec
2 by restricting the throt tle
or by applying the brakes appropriate
to the prevailing situation until the dis ­
tance that you have preset is maintained. Your vehicle will now continue at a
reduced speed. If the other vehicle

decelerates further, adaptive cruise
control will continue to reduce your
cruising speed – even down to a halt. For additional safet y, if the system detects
that the distance from the vehicle in front
is decreasing, it will also prepare your
vehicle for braking by precharging the braking system so that the brake pads
are already in light contact with the
brake discs. However, drivers still have
to perform heavier braking themselves.
As soon as the road ahead clears again,
your vehicle will accelerate back up to
the cruising speed originally set.
If your vehicle approaches the vehicle

in front too quickly, Porsche Active Safe
(PAS) will issue audible and visual warn ­
ings. In addition, the system briefly jerks
the brakes and if necessary initiates
target braking, with any braking pressure
applied by the driver being increased
within certain system limits.
Adaptive cruise control display
Radar sensor of adaptive cruise control

9697
Composure
| Comfor t
Anti-theft protection.
All 911 Carrera models are equipped as
standard with an immobiliser with in
­key
transponder and an alarm system with
radar ­based interior surveillance. The
system secures the doors, luggage com ­
partment, passenger compartment and
ignition lock.
Preparation for Porsche Vehicle
Tracking System (PVTS).
Available as an option, this preparation
enables future installation of the Porsche
Vehicle Tracking System (PV TS) available
from Porsche Tequipment. The system
makes it possible to locate a stolen
vehicle across most of the countries
of Europe. The preparation package
includes a special wiring loom and a

tilt sensor for the alarm system.
Luggage compartment.
The luggage compartment volume in the
911 models is 145 litres – 125 litres on
the 911 Carrera all ­wheel ­drive models.
The luggage compartment is fully trimmed
in scratch ­resistant materials.
Roof transport system.
Available as an option for the Coupé
models, the roof transport system in
aluminium is aerodynamically efficient,
very light weight and easy to fit. A range
of at tachments is available, such as a
roof box, a bike carrier or a ski/snowboard
carrier. Maximum roof load is 75 kg.
Porsche Entry & Drive.
With the optional Porsche Entry & Drive,
you can leave your car key in your pocket.
As soon as you grab the door handle
or approach the luggage compartment,
the system automatically checks the
encrypted access code on the key. Once
the key is validated, the door or the luggage compartment lid unlocks. The
engine can then be started and switched
off using the electronic ignition switch.
To lock the vehicle, you simply press the
but ton on the outside of the door handle.
Porsche Entry & Drive then locks the
vehicle and activates the engine immobi
­
liser and steering column lock.
