2013 Peugeot 807 driver seat adjustment

9
1
FAMILIARISATIO
N


Interior


13.
Battery / Fuse box.

14.
Passenger airbag.

15.
Passenger's lower glove box / Fuse
box / RCA sockets.

16.
Air conditioning controls.

17.
Lighter /
12 V accessories socket.

18.
Hazard warning lights switch.

19.
Storage compartment or additional
telematics control.

20.
Cooled compartment.

21.
Ashtray / Can holder.

22.
Seat adjustment control.

23.
Storage compartment.

24.
Handbrake - on the left.

1.
Electric mirror controls.


- Electric window controls.

- Deactivation of the rear electric
controls.

2.
Driver's upper glove box.

3.
Central adjustable vents.

4.
Audio equipment or GPS
multimedia audio equipment with
fl ap.

5.
Instrument panel / Large colour
display.

6.
Sunshine and passenger
compartment temperature sensor.

7.
Passenger's upper glove box.
25.
Bonnet release under cover - on
the left.

26.
Acoustic windscreen.





INTERIOR OVERVIEW

SETTING THE DATE AND
TIME
For more information about
this adjustment, refer to the
"Setting the date and time" section of
the "In-car technology" chapter.


ADDITIONAL HEATER

With the engine at idle
or when the vehicle is
stationary, it is normal
to notice a high-pitched
whistling and a slight emission of
smoke and odour.
Bluetooth.

8.
Windscreen demisting vents.

9.
Speaker (tweeter).

10.
Front window demisting vents.

11 .
Passenger airbag disarming switch,
if fi tted on your vehicle.

12.
Side adjustable vent.

4
12
Interior
86 Seat with manual
adjustment
Seat with electric
adjustment If your vehicle
is fi tted with a
version with a
rotating front
seat, pull the
button placed
at the end of
the handbrake
forwards.
The handbrake
lever lowers.
You can now rotate the seat. To return
to normal operation, pull the lever up
until it clicks.

1.

Forwards-backwards
adjustment.

2.
Angle.

3.
Height.

4.
Lumbar.

5.
Head restraint
height and angle.

Rotating the seat


SIT COMFORTABLY


Driver's seat

Steering wheel controls

EASE OF USE and COMFORT
3
45


Automatic "Follow-Me-Home"
lighting
With the ignition off, when you leave
your vehicle with the automatic
switching on of the lights function
activated
, the side lights and dipped
headlamps remain on for the selected
duration.
To deactivate or activate this
function, go to the display
confi guration menu.
The duration of the timed period must
also be set (15, 30, 60 seconds), via
the display confi guration menu.
Carry out these operations when the
vehicle is stationary.
HEADLAMPS BEAM
Depending on the load in your vehicle,
the beam setting must be adjusted.

0
- 1 or 2 people in the front seats.

1
- 5 people.

2
- 6 to 8 people.

3
- Driver + maximum authorised
loads.

Initial setting is position 0.
In foggy weather or in snow,
the brightness sensor can
detect suffi cient light. As a
consequence, the lights will not come
on automatically.

Automatic switching on of the lights

Deactivation
Turn the ring forwards or rearwards.
The deactivation of this function is
accompanied by a message on the
display.
The function is deactivated temporarily
when you use the manual lights stalk.

If the brightness sensor does not
function correctly
, the lights come on
accompanied by the service warning
light, an audible signal and a message
on the display.
Contact a PEUGEOT dealer.

Do not cover the brightness
sensor located in the centre of the
fascia. It is used for the automatic
switching on of the lights and for the
automatic wipers.



Activation
Turn the ring to the AUTO
position.
The activation of this function is
accompanied by a message on the
display.

AUTOMATIC ADJUSTMENT OF
THE XENON HEADLAMPS

On vehicles which are fi tted with xenon
headlamps, this system automatically
corrects the height of the light beam,
regardless of the load in the vehicle.
The driver is then guaranteed optimum
lighting without dazzling other road
users.
Cancelling:
- "fl ash" the headlamps,

-
get out of the vehicle and lock it.
If your vehicle is fi tted
with a brightness
sensor, the side lights
and dipped beam
headlamps switch on
automatically if the
light is poor, or during operation of the
windscreen wipers. They switch off
as soon as the light becomes bright
enough or the windscreen wipers stop.
This function is not compatible with the
daytime lights.

60


Seats


3 - Driver's seat height adjustment
Manoeuvre the handle upwards or
downwards until the desired position is
reached.

4 - Driver's seat lumbar adjustment
Move the lever up or down to obtain
the required position.
5 - Head restraint height and angle
adjustment
To raise or lower the restraint, pull it
forwards, then slide it.
The adjustment is correct when the
upper edge of the head restraint is
level with the top of the head.
To remove it, set it in the high position,
lift the tab using a coin and pull
upwards and forwards at the same
time.
To re-install, engage the head restraint
rods in the holes, making sure they are
aligned with the seat back.
Never drive with the head
restraints removed; they must be
in place and correctly adjusted.

EASE OF USE and COMFORT
3
61
Seats
FRONT SEATS WITH
ELECTRICAL ADJUSTMENT

2 - Driver's seat height adjustment

Push the rear part of the control
upwards or downwards to obtain the
required height.
1 - Forwards-backwards adjustment

Push the control forwards or
backwards to slide the seat.

62


Seats


3 - Seat back angle adjustment

Tilt the control to the front or the rear to
obtain the angle required.
The electrical functions of the seats
are cancelled one minute after the
ignition has been switched off.

4 - Driver's seat lumbar adjustment
(mechanical)

Raise or lower the lever to obtain the
correct position.
5 - Head restraint height and angle
adjustment (manual)

To raise or lower the head restraint,
pull it forwards, then slide it.
Never drive with the head
restraints removed; they must be
in place and correctly adjusted.
6 - Rotating of seats (mechanical)

Place the seat back in the upright
position.
Place the seat in the highest
intermediate longitudinal position.
On the driver's side, push the steering
wheel, apply the handbrake. To
allow rotation of the seat, lower the
handbrake handle pulling on the end.
Pull the control upwards and rotate the
seat inwards.
This rotating operation must
be carried out with the engine
switched off. The handbrake,
the lever of which is now in the lower
position, remains applied. Do not forget
to raise the lever and release the brake
before setting off.
Driving with a passenger seated facing
the rear is prohibited. For further information regarding
the disengaging of the handbrake,
refer to the "Driving safety" section
of chapter 4. The setting is correct when the upper
edge of the head restraint is level with
the top of the head.
To remove the head restraint, place it
in the high position, lift the tab using a
coin and pull upwards and forwards at
the same time.
To re-install, engage the head restraint
rods in the holes, making sure they are
aligned with the seat back.
