2013 Lexus GX460 check engine light

5
When trouble arises
701
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
The tire pressure warning system may become inoperative in the following condi-
tions:
(When the condition becomes normal, the system will work properly.)
●If electronic devices or facilities using similar radio wave frequencies are nearby.
●If a radio set at similar frequencies is in use in the vehicle.
●If a window tint that affects the radio wave signals is installed.
●If there is a lot of snow or ice on the vehicle, in particular around the wheels or
wheel housings.
●If non-genuine Lexus wheels are used. (Even if you use genuine Lexus wheels,
the tire pressure warning system may not work properly with some types of
tires.)
●If tire chains are used.
●If the spare tire is in a location subj ect to poor radio wave signal reception.
● If a large metallic object which can interfere with signal reception is put in the
luggage compartment.
■If the tire pressure warning light comes on after blinking for 1 minute frequently
If the tire pressure warning light comes on after blinking for 1 minute frequently
when the engine switch is turned to the “ON” position, have it checked by your
Lexus dealer.

5
When trouble arises
715
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
Have the malfunction repaired immediately.After taking the specified steps to co rrect the suspected problem, check
that the warning message and light go off.
Interior
buzzerExterior buzzerWa r n i n g m e s s a g eDetailsCorrection
procedure
Sounds
once
(Flashes)
The electronic key
is not detected
when an attempt
is made to start
the engine.
Confirm the loca-
tion of the elec-
tronic key.

5
When trouble arises
747
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
■Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
■To prevent battery discharge
●Turn off the headlights and the audio system while the engine is off.
●Turn off any unnecessary electrical components when the vehicle is running at a
low speed for an extended period, such as in heavy traffic, etc.
■Charging the battery
The electricity stored in the battery will discharge gradually even when the vehicle
is not in use, due to natural discharge and the draining effects of certain electrical
appliances. If the vehicle is left for a long time, the battery may discharge, and the
engine may be unable to start. (The batt ery recharges automatically during driving.)
Start the engine of the second vehicle. Increase the engine
speed slightly and maintain at that level for approximately 5
minutes to recharge the battery of your vehicle.
Open and close any of the doors of your vehicle with the
“ENGINE START STOP” switch off.
Maintain the engine speed of the second vehicle and start the
engine of your vehicle by tu rning the “ENGINE START STOP”
switch to IGNITION ON mode.
Once your vehicle’s engine has started, remove the jumper
cables in the exact reverse ord er in which they were con-
nected.
Once the engine starts, have the ve hicle checked at your Lexus dealer
as soon as possible.STEP3
STEP4
STEP5
STEP6

764
6-1. Specifications
GX460_OM_OM60J63U_(U)
Electrical system
Front differential
*: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at thefactory.
Use Lexus approved “Toyota Genuine Differ ential Gear Oil” or an equivalent of
matching quality to satisfy the above specification. Please contact your Lexus
dealer for further details.
Battery
Open voltage* at
68 F (20 C):12.6  12.8 V Fully charged
12.2  12.4 V Half charged
11.8  12.0 V Discharged
(
*: Voltage is checked 20 minutes after the
engine and all the lights are turned off.)
Charging rates5A max.
Oil capacity1.48 qt. (1.40 L, 1.23 Imp.qt.)
Oil type and viscosity*Toyota Genuine Differential
Gear Oil LT 75W-85 GL5 or equivalent

829
Alphabetical index
GX460_OM_OM60J63U_(U)
Electronic keyIf the electronic key does not operate properly .............................744
Emergency, in case of If the electronic key does not operate properly .............................744
If the engine will not start ............... 740
If the shift lever cannot be shifted from P .................................... 742
If the vehicle has discharged battery.................................................. 746
If the warning buzzer sounds...... 693
If the warning light turns on .......... 693
If the warning message is displayed ............................................ 705
If you have a flat tire .........................726
If you lose your keys .........................743
If you think something is wrong.....................................................691
If your vehicle becomes stuck .....752
If your vehicle has to be stopped in an emergency ......... 754
If your vehicle needs to be towed ...................................................685
If your vehicle overheats................ 749
Emergency flashers Switch ...................................................... 684 Engine
Accessory mode................................. 183
Compartment....................................... 618
Engine switch ........................................ 183
Hood ..........................................................617
How to start the engine ................... 183
Identification number .......................759
If the engine will not start................740
Ignition switch ....................................... 183
Overheating ......................................... 749
Engine compartment cover .............. 619
Engine coolant Capacity ................................................. 763
Checking ...............................................624
Preparing and checking before winter ......................................371
Engine coolant temperature gauge....................................................... 199
Engine immobilizer system.................. 119
Engine oil Capacity ...................................................761
Checking .............................................. 620
Preparing and checking before winter ......................................371
Engine switch .......................................... 183
Engine switch light................................525
Event data recorder (EDR) ................. 23E
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.

835
Alphabetical index
GX460_OM_OM60J63U_(U)
Switch“ENGINE START STOP” switch .....................................................183
Engine switch ........................................183
“2nd STRT” switch .............................. 192
Center differential lock/unlock switch ....................................................327
“DAC” switch ...................................... 336
Emergency flasher Switch ............ 684
Fog light switch....................................237
Hazard light Switch .......................... 684
Heated steering wheel switch ....555
Height control off switch ............... 320
Ignition switch........................................183
Light switches.......................................223
Power door lock switch .....................52
Power window switch...................... 105
“RSCA OFF” switch ............................ 141
Rear window defogger switch
*.................................................. 417
Transmission shift switch ................. 193
Window lock switch ......................... 105
Wipers and washer switch........... 240
Tachometer .............................................. 199
Tail lights Replacing light bulbs ...................... 680
Switch .......................................................223
Talk switch
*.............................................496
Telephones switch
*.............................496
Theft deterrent system Alarm ........................................................... 121
Engine immobilizer system ..............119 Tire inflation pressure ......................... 643
Tire information
Glossary ................................................ 780
Size ............................................................ 776
Tire identification number.............. 775
Uniform Tire Quality Grading .... 778
Tires Chains .......................................................371
Checking .............................................. 636
If you have a flat tire .......................... 726
Inflation pressure ............................... 768
Information ............................................ 774
Pressure warning system.............. 636
Replacing ............................................... 726
Rotating tires ....................................... 636
Size........................................................... 768
Snow tires ................................................371
Spare tire ................................................ 726
Tire pressure warning system ................................................. 636
Tools ........................................................... 726
Total load capacity ...............................369
Towing Dinghy towing .....................................394
Emergency towing........................... 685
Trailer towing .......................................375
T
*: For vehicles with a navigation system, refer to the “Navigation System Owner’s Manual”.
