201
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)
■The meters and display illuminate when
The “ENGINE START STOP” switch is in IGNITION ON mode.
■Instrument cluster brightness adjustment
The instrument cluster brightness levels when the tail lights are on and off can be
adjusted.
■The brightness of the instrument cluster lights
When the tail lights are on, the brightness will change. However, when the sur-
roundings are bright (daytime, etc.) turning on the tail lights will not change the
instrument cluster brightness.
In addition, the brightness of the instrument cluster lights is automatically adjusted
based on the light sensor detecting how bright the surroundings are.
■When disconnecting and reconnecting battery terminals
The trip meter data will be reset.
If the trip meter was displayed last, the ODO screen will be displayed after reset-
ting.
■Customization
Setting of sensitivity of the ambient ligh t sensor used for dimming the meter lights
can be changed. (Customizable features P. 7 8 8 )
NOTICE
■To prevent damage to the engine and its components
●Do not let the indicator needle of the tachometer enter the red zone, which indi-
cates the maximum engine speed.
●The engine may be overheating if the engine coolant temperature gauge is in the
red zone (H). In this case, immediately stop the vehicle in a safe place, and check
the engine after it has cooled completely. ( P. 74 9 )

205
2-2. Instrument cluster
2
When driving
GX460_OM_OM60J63U_(U)
*1: These lights turn on when the “ENGINE START STOP” switch is turnedto IGNITION ON mode to indicate that a system check is being per-
formed. They will turn off after the en gine is on, or after a few seconds.
There may be a malfunction in a system if the lights do not turn on, or turn
off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate that the system is operating.
*3: The light turns on when the system is turned off. The light flashes quickly
to indicate that the system is operating.
(if equipped)
Crawl Control indicator
( P. 3 3 2 )AIR BAG ON/OFF
indicator ( P. 1 4 3 )
(if equipped)
Downhill assist control
system indicator
( P. 3 3 6 )
(if equipped)
Intuitive parking assist
indicator ( P. 2 7 0 )
“2nd STRT” indicator
( P. 1 9 2 )
(if equipped)
“AFS OFF” indicator
(P. 2 2 7 )
Low speed four-wheel
drive indicator light
(P. 3 2 6 )“RSCA OFF” indicator
(P. 1 4 1 )
Center differential lock
indicator ( P. 3 2 7 )
(if equipped)
“PCS” warning
( P. 3 4 7 )
*1
*1
*1
*1
*1, 3

206
2-2. Instrument cluster
GX460_OM_OM60J63U_(U)
■Warning lights
Warning lights inform the driver of malfunctions in the indicated
vehicle’s systems. ( P. 693, 705)
*1: These lights turn on when the “ENGINE START STOP” switch is turned
to IGNITION ON mode to indicate that a system check is being per-
formed. They will turn off after the en gine is on, or after a few seconds.
There may be a malfunction in a system if a light does not turn on, or if the
lights do not turn off. Have the vehicle inspected by your Lexus dealer.
*2: The light flashes to indicate a malfunction.
(U.S.A.)(Canada)(U.S.A.)(Canada)
(U.S.A.)(Canada)(for driver)(for front
passenger)(if equipped)
(if equipped)(if equipped)(if equipped)(if equipped)
(if equipped)
*1*1*1*1*1*1
*1*1*1*1*1, 2*1
*1*2*2*2*1, 2*2*2*2
*2

248
2-3. Operating the lights and windshield wipers
GX460_OM_OM60J63U_(U)
■The rear window wiper and washer can be operated when
●The “ENGINE START STOP” switch is in IGNITION ON mode.
●The glass hatch is closed.
■If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the wind-
shield washer fluid reservoir.
NOTICE
■When the rear window is dry
Do not use the wiper, as it may damage the rear window.
■When the washer fluid tank is empty
Do not operate the switch continually as the washer fluid pump may overheat.

293
2-4. Using other driving systems
2
When driving
GX460_OM_OM60J63U_(U)
■The wide view front & side monitor can be operated when
●The “ENGINE START STOP” switch is in IGNITION ON mode.
●The vehicle speed is less than approximately 6 mph (10km/h).
■Automatic system cancelation
In the following situations, the system is canceled automatically.
●When the vehicle speed exceeds approximately 7 mph (12 km/h).
●When the shift lever is in P or R.
■When the outside rear view mirrors have been folded
The side monitor screen can be displayed even if the outside rear view mirrors have
been folded. In this case, there will be a slight difference between the image dis-
played when the outside rear view mirrors are extended and when the outside rear
view mirrors have been folded.
If the side monitor is displayed while the outside rear view mirrors are folded, you
cannot check the area near the front edge of the vehicle as the base of the outside
rear view mirrors will be in the way.

Maintenance and care4
595
GX460_OM_OM60J63U_(U)
4-1. Maintenance and careCleaning and protecting the vehicle exterior............. 596
Cleaning and protecting the vehicle interior ............... 601 4-2. Maintenance
Maintenance requirements........................ 604
General maintenance .......... 607
Emission inspection and maintenance (I/M)
programs .................................. 611
4-3. Do-it-yourself maintenance Do-it-yourself service precautions ............................. 612
Hood ............................................ 617
Engine compartment ............ 618
Tires............................................ 636
Tire inflation pressure........... 643
Wheels ....................................... 647
Air conditioning filter ........... 650
Electronic key battery.......... 652
Checking and replacing fuses ........................................ 655
Headlight aim (vehicles with low beam
halogen bulbs)...................... 668
Light bulbs ................................. 670

670
4-3. Do-it-yourself maintenance
GX460_OM_OM60J63U_(U)
Light bulbs
You may replace the following bulbs by yourself. The difficulty level of
replacement varies depending on the bulb. If necessary bulb replacement
seems difficult to perform, contact your Lexus dealer.
For more information about replacing other light bulbs, contact your Lexus
dealer.
■ Prepare a replacement light bulb
Check the wattage and color of the light bulb being replaced.
( P. 76 9 )
■ Remove the engine compartment cover
 P. 6 1 9
■ Front bulb locations
Headlight low beam
(halogen bulb)
Headlight high beam
and daytime running lights
Parking/front side marker light
Front turn signal light
Fog light

698
5-2. Steps to take in an emergency
GX460_OM_OM60J63U_(U)
*1: Open door warning buzzer:
The open door warning buzzer sounds to alert one or more of the doors is not
fully closed (with the vehicle having reached a speed of 3 mph [5 km/h]).
( P. 7 0 9 )
*2: Driver’s and front passenger’s seat belt reminder buzzer:
The driver’s and front passenger’s seat belts reminder buzzer sounds to alert
the driver and front passenger that his/he r seat belt is not fastened. Once the
“ENGINE START STOP” switch is turned to IGNITION ON mode, the buzzer
sounds for 4 to 8 seconds. If the vehi cle reaches a speed of 12 mph (20 km/h),
the buzzer sounds intermittently for 10 seconds. Then, if the seat belt is still
unfastened, the buzzer will sound in a different tone for 20 more seconds.
Warning lightWarning light/DetailsCorrection procedure
Master warning light
A buzzer sounds and the
warning light comes on and
flashes to indicate that the
master warning system has
detected a malfunction.
 P. 7 0 5
Tire pressure warning light
When the light comes on:
Low tire inflation pressure.Adjust the tire inflation pres-
sure.
When the light comes on after
blinking for 1 minute:
Malfunction in the tire pres-
sure warning system.
Have the system checked by
your Lexus dealer.
